Barcode Scanner
Operation Manual
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
condition: (1) This device may not cause harmful
interface, and (2) This device must accept any
interface received, including Interface that may
cause undesired operation.
This equipment has been tested and found comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interface when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interface to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interface in which case the user will be required
to correct the interface at his own expense.
Advertisement
Table of Contents
Related Manuals for Canmax CM-880
Summary of Contents for Canmax CM-880
- Page 1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two condition: (1) This device may not cause harmful Barcode Scanner interface, and (2) This device must accept any interface received, including Interface that may cause undesired operation.
-
Page 2: Table Of Contents
Index Installation Installation..........2 Comment ..........3 Installation Frequency Question......7 1) First of all, you must make sure that the power is Interface..........9 disconnected form your equipment before connecting Keyboard ..........10 the scanner. Beside, you also have to check the RS-232C.......... -
Page 3: Installation
Comment Comment Numeric Key Position Response Delay (Set value) This function is only available for IBM PC/AT, PS/2,IBM The time out is a pre-defined delay time for serial 5576 series personal computers and compatible communication of scanner to wait for handshaking, machines. - Page 4 Comment Comment ISBN/ISSN Translation Code Length Transmission The ISBN (International Standard Book Number) and The length of data characters can be transmitted before ISSN (International Standard Serial Number) are two the code data when the enable is selected. The total kinds of barcode bookend label.
-
Page 5: Frequent Question
Frequent Question Frequent Question Q: Why scanner block the keyboard operation? Q: If scanner dosen't need an Enter character A: Check the cable connection with your equipment, or addition after each barcode label transmission. re-plug in calbe with your reader. Then turn power on A: Refer to postamble transmission at 33, then set again. -
Page 6: Interface
Interface Keyboard Wedge *DFA* Keyboard Type */$%C00* *DFB* IBM AT,PS/2 *DFC* Keyboard IBM XT */$%C01* *DFD* Macintosh ADB. *DFE* RS-232C IBM PS/2 25,30 */$%C02* *DFF* NEC 9801 *DFG* Wand Emulation (Option) IBM PS/2 55 */$%C03* *DFH* IBM 5550 *DFI* OCIA (Option) KT-106 */$%C04* *DFJ*... -
Page 7: Keyboard Wedge
Keyboard Wedge RS-232C *DAA* *DLA* Numeric Key Position Handshaking Protocol *DAB* *DLB* Alphabetic-key None *DLC* Keypad RTS/CTS *DBA* Function Key Simulation *DLD* CTS/RTS *DBB* Disable *DLE* Scanner Ready Enable *DGA* *DLF* Data Ready Keyboard Layout *DGB* *DLG* USA (US) X-on/X-off *DGC* *DLH* Belgium (BE) -
Page 8: Wand Emulation
RS-232C Wand Emulation *DJA* *DMA* Data Length Active Level *DJB* *DMB* 7 Bits Bar High Space High 8 Bits *DIA* *DNA* Stop Length Normal Level *DIB* *DNB* One Bit Two Bits High *BAL* *DOA* Specific Adjustments Output Speed *BAM* *DOB* Inter-char. -
Page 9: Ocia
OCIA System Control *DSA* *CBA* Protocol Type Power-on Music *DSB* *CBB* Disable *DSC* Enable *CCA* Power-on Auto Trigger *DSD* ASCII *CCB* Disable *DSE* NCR+ASCII Enable *CDA* DTS+ASCII Good-read LED *DTA* Data Parity *CDB* Disable *DTB* Even Enable *DTC* *CEA* Good-read Beep *DTD* *CEB* Space... -
Page 10: System Control
System Control System Control *CAB* *IOA* Scanning Mode Money Testing *CAC* *IOB* Good-read Off None *CAD* *IOC* Momentary Right Bottom *CAE* Alternate Left Bottom *BAC* Specific Adjustments *CAF* Timeout Off *BAE* Beep Loudness (01-10) *CAG* Timeout Flash *BAF* Beep Duration(01-99*10ms) *CAA* Continue *BAG*... -
Page 11: Upc-A
UPC-A UPC-E *DVA* *ECA* Code Read Code Read *DVB* *ECB* Disable Disable Enable Enable *DWA* *EDA* Add-on Read Add-on Read *DWB* *EDB* Disable Disable *DWC* *EDC* Add-on 2 Only Add-on 2 Only *DWD* *EDD* Add-on 5 Only Add-on 5 Only Add-on 2+5 Add-on 2+ 5 *DZA*... -
Page 12: Ean-13
EAN-13 EAN-8 *EKA* *ESA* Code Read Code Read *EKB* *ESB* Disable Disable Enable Enable *ELA* *ETA* Add-on Read Add-on Read *ELB* *ETB* Disable Disable *ELC* *ETC* Add-on 2 Only Add-on 2 Only *ELD* *ETD* Add-on 5 Only Add-on 5 Only Add-on 2+5 Add-on 2+5 *EPA*... -
Page 13: Code-39
Code-39 Interleaved 2 of 5 *FAA* *FKA* Code Read Code Read *FAB* *FKB* Disable Disable Enable Enable *FBA* *FLA* Format Format *FBB* *FLB* Standard Standard Full ASCII Odd S-code *FCA* *FNA* Code-32 Translation Checksum Verification *FCC* *FNB* Disable Disable *FCD* Without Leading 'A' Enable *FOA*... -
Page 14: Industrial 2 Of 5
Industrial 2 of 5 Matrix 2 of 5 *FQA* *FVA* Code Read Code Read *FQB* *FVB* Disable Disable Enable Enable *FSA* *FXA* Checksum Verification Checksum Verification *FSB* *FXB* Disable Disable Enable Enable *FTA* *FYA* Checksum Transmission Checksum Transmission *FTB* *FYB* Disable Disable Enable... -
Page 15: Codabar/Nw7
Codabar/NW7 Codabar/NW7 *GFA* *BBS* Code Read Specific Adjustments *GFB* *BBT* Disable Truncate Leading (00-15) *BBQ* Enable Truncate Ending (00-15) *GGA* Start/End Symbol Type *BBR* Min. Code Length (00-48) *GGB* ABCD/ABCD *AAL* Max. Code Length (00-48) *GGC* abcd/abcd Code ID (ASCII) *GGD* ABCD/TN*E abcd/tn*e... -
Page 16: Code-128
Code-128 Code-93 *GMA* *GTA* Code Read Code Read *GMB* *GTB* Disable Disable Enable Enable *CNA* *GWA* Format Checksum Verification *GNB* *GWC* Standard Disable *GWD* UCC/EAN-128 One Digit *GQA* Checksum Verification Two Digits *GQB* *GXA* Disable Checksum Transmission *GXB* Enable Disable *GRA* Checksum Transmission Enable... -
Page 17: Code-11
Code-11 MSI/Plessey *GZA* *HEA* Code Read Code Read *GZB* *HEB* Disable Disable Enable Enable *HBA* *HGA* Checksum Verification Checksum Verification *HBC* *HGB* Disable Disable *HBD* *HGC* One Digit Mod 10 *HGD* Two Digits Mod 10/10 *HCA* Checksum Transmission Mod 11/10 *HCB* *HHA* Disable... -
Page 18: Preamble/Postamble
Preamble/Postamble Appendix *IEA* Preamble Transmission *IEB* Disable Enable *AAZ* Preamble Data *ABA* Data0 (ASCII) Data1 (ASCII) *IFA* Postamble Transmission *IFB* Disable Enable *ABB* Postamble Data *ABC* Data0 (ASCII) Data1 (ASCII) *IGA* Prefix Transmission *IGB* Disable *IMA* Enable Clear All Data *ABF* Prefix Data 15 Bytes Data (ASCII) -
Page 19: Ascii Code Table
ASCII Code Table Hexdecimal/Decimal Table Null *%00* Down *%01* Left *%02* Right PgUp *%03* PgDn *%04* *%05* *%06* *%07* Enter *%08* Insert Ctrl+ Delete Alt+ *%09* For keyboard wedge only. *%0A* *%0B* *%0C* “ *%0D* *%0E* & *%0F* ‘ *%OK* <...
