Page 2: Table Of Contents
Index Chapter 1: Import Notice ................19 1-1 Regulations ..................20 1-2 TECHNICAL REGULATIONS CONFORMITY FOR SPECIFIED RADIO EQUIPMENT IN JAPAN ............. 20 1-3 NATIONAL COMMUNICATION COMMISSION ......21 1-4 RoHS DIRECTIVE ................21 1-5 SAFETY PRECAUTION ..............22 Chapter 2: Introduction ................23 2-1 PRODUCT FEATURES ..............
Page 3 Index Chapter 5: Bluetooth Connection Mode Instruction ......... 47 5-1 Slave mode Connection (For Third party Bluetooth devices) ..48 5-2 Master mode Connection (For Third party Bluetooth Devices) . 53 5-3 HID mode Connection (For Third party Bluetooth devices) ..58 5-4 iOS mode Connection ..............
Page 4 Index 6-1-30 CodeId Position ..............88 6-1-31 Tx Code Length ..............88 6-1-32 ForceCase ................ 89 6-1-33 Tx Delimiter ............... 89 6-1-34 DelimiterChar ..............90 6-1-35 Tx Control Code ..............90 6-1-36 WaitKeyTime ..............91 6-1-37 Date & Time Transmission ..........91 6-1-38 Date/Time Position ............
Page 5 Index 6-2-29 Tx CodeId ............... 110 6-2-30 CodeId Position .............. 110 6-2-31 Tx Code Length .............. 110 6-2-32 ForceCase ..............111 6-2-33 Tx Delimiter ..............111 6-2-34 DelimiterChar ..............112 6-2-35 Tx Control Code .............. 112 6-2-36 Date & Time Transmission ..........113 6-2-37 Date/Time Position ............
Page 6 Index 6-3-30 ForceCase ..............129 6-3-31 Tx Delimiter ..............130 6-3-32 DelimiterChar ..............130 6-3-33 Tx Control Code .............. 131 6-3-34 Date & Time Transmission ..........131 6-3-35 Date/Time Position ............131 6-3-36 DateTimeSpareChar ............132 6-4 Scanner Confuguration by Software .......... 133 6-4-1 Firmware Update ..............
Page 7 Index 7-2-2-10 Transmission Record Gap Time ....... 157 Bluetooth Mode .................. 158 7-2-3 Bluetooth HID Type ............158 7-2-3-1 Caps lock ..............158 7-2-3-2 Num Lock ..............158 7-2-3-3 Shift Release Caps Lock ..........159 7-2-3-4 Bluetooth HID Layout Settiing ........159 7-2-3-5 Transmission Timeout ..........
Page 8 Index 7-2-6-6 Transmission Timeout ..........175 7-2-6-7 Transmission Char Delay ........... 176 7-2-6-8 Transmission Char Gap Time ........176 7-2-6-9 Transmission Record Gap Time ......... 177 7-3 System Control................178 7-3-1 Mode ................. 178 7-3-2 System Beep Volume ............178 7-3-3 DcPlug Cable Mode ............
Page 9 Index 8-2-6 Addon Separator ............... 195 8-2-7 Coupon Gs1DataBar Output ..........196 8-2-8 ExtendedCouponCode ............. 196 8-2-9 Wait Addon Time .............. 197 8-2-10 ConvertUpcaToEan13 ............. 197 8-2-11 TruncateLeading ............. 198 8-2-12 TruncateEnding ............... 198 8-2-13 TruncateZero ..............199 8-2-14 Insertion1DataPosition ............ 199 8-2-15 Insertion1Data ..............
Page 10 Index 8-4-12 Insertion1DataPosition ............ 213 8-4-13 Insertion1Data ..............214 8-4-14 Insertion2DataPosition ............ 214 8-4-15 Insertion2Data ..............215 8-5 EAN-8 .................... 216 8-5-1 Read ................. 216 8-5-2 CheckDigit ................ 216 8-5-3 Addon2 ................216 8-5-4 Addon5 ................217 8-5-5 Wait addon ................ 217 8-5-6 Addon Separator ...............
Page 11 Index 8-7-9 Insertion1DataPosition ............234 8-7-10 Insertion1Data ..............235 8-7-11 Insertion2DataPosition ............ 236 8-7-12 Insertion2Data ..............237 8-8 Gs1 Composite ................238 8-8-1 Read ................. 238 8-8-2 Upc/EanVersion ..............238 8-8-3 Gs1Emulation ..............239 8-8-4 Min Code Length .............. 240 8-8-5 Max Code Length .............
Page 12 Index 8-10-11 Insertion1Data ............... 256 8-10-12 Insertion2DataPosition ..........256 8-10-13 Insertion2Data .............. 257 8-11 Tlc39 .................... 258 8-11-1 Read ................258 8-11-2 TruncateLeading ............. 258 8-11-3 TruncateEnding ............... 259 8-11-4 TruncateZero ..............259 8-11-5 Insertion1DataPosition ............ 260 8-11-6 Insertion1Data ..............260 8-11-7 Insertion2DataPosition ............
Page 13 Index 8-14-5 TruncateEnding ............... 275 8-14-6 TruncateZero ..............275 8-14-7 Insertion1DataPosition ............ 276 8-14-8 Insertion1Data ..............276 8-14-9 Insertion2DataPosition ............ 277 8-14-10 Insertion2Data .............. 277 8-15 Aztec.................... 278 8-15-1 Read ................278 8-15-2 Append ................278 8-15-3 Min Code Length ............279 8-15-4 Max Code Length ............
Page 14 Index 8-17-11 TruncateZero ..............294 8-17-12 Insertion1DataPosition ..........294 8-17-13 Insertion1Data .............. 295 8-17-14 Insertion2DataPosition ..........295 8-17-15 Insertion2Data .............. 296 8-18 Code39 ..................297 8-18-1 Read ................297 8-18-2 Chksum Verification ............297 8-18-3 Start/End Transmission ........... 298 8-18-4 Type ................298 8-18-5 Min Code Length ............
Page 15 Index 8-20-6 TruncateEnding ............... 313 8-20-7 TruncateZero ..............314 8-20-8 Insertion1DataPosition ............ 314 8-20-9 Insertion1Data ..............315 8-20-10 Insertion2DataPosition ..........315 8-20-11 Insertion2Data ............... 316 8-21 Code93 ..................317 8-21-1 Read ................317 8-21-2 Append ................317 8-21-3 Min Code Length ............318 8-21-4 Max Code Length ............
Page 16 Index 8-23-10 Insertion2Data .............. 333 8-24 Code11 ..................334 8-24-1 Read ................334 8-24-2 Chksum Digit ..............334 8-24-3 Min Code Length ............335 8-24-4 Max Code Length ............335 8-24-5 TruncateLeading ............. 336 8-24-6 TruncateEnding ............... 336 8-24-7 TruncateZero ..............337 8-24-8 Insertion1DataPosition ............
Page 17 Index 8-27-3 Planet Tx CheckDigit ............352 8-27-4 AustralianPostInterpretation ..........353 8-27-5 TruncateLeading ............. 354 8-27-6 TruncateEnding ............... 355 8-27-7 TruncateZero ..............356 8-27-8 Insertion1DataPosition ............ 357 8-27-9 Insertion1Data ..............358 8-27-10 Insertion2DataPosition ..........359 8-27-11 Insertion2Data ............... 360 8-28 ChinaPost(HongKong2of5) ............361 8-28-1 Read ................
Page 18 Index Appendix:Hexadecimal / Decimal TABLE ..........377 Appendix:ASCII Code Table ..............378 Appendix:A-303 Dongle Layout Setting ........... 379...
Page 19: Chapter 1: Import Notice
1. Important Notice Chapter 1: important Notice 1-1 Regulations 1-2 TECHNICAL REGULATIONS CONFORMITY FOR SPECIFIED RADIO EQUIPMENT IN JAPAN 1-3 NATIONAL COMMUNICATION COMMISSION 1-4 RoHS DIRECTIVE 1-5 SAFETY PRECAUTION...
Page 20: Regulations
1. Important Notice 1. Important Notice: 1-1 Regulations 1-1 REGULATIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 21: National Communication Commission
1. Important Notice 1-3 NATIONAL COMMUNICATION COMMISSION 1-3 NATIONAL COMMUNICATION COMMISSION NCC Registration Number: NCC-RCB-12 Qualified serials number on device: 1-4 RoHS DIRECTIVE 1-4 RoHS DIRECTIVE The RoHS directive (European Parliament Directive 2002/95/EC) mandates that producers of electrical or electronic equipment sold into Europe must minimize or eliminate the following materials from their design, as they are considered health risks: 1.
Page 22: Safety Precaution
1. Important Notice 1-5 SAFETY PRECAUTION 1-5 SAFETY PRECAUTION Do not stare the scanning light source beam. Do not touch the device transparent window, reading performance might decrease if transparent window is dirty or scratch. Do not disassemble or modify the internal components from the scanner.
Page 23: Chapter 2: Introduction
2. Introduction Chapter 2: Introduction 2-1 PRODUCT FEATURES 2-2 PRODUCT SPECIFICATION 2-3 PACKAGE INFORMATION 2-4 DEFAULT SYMBOLOGIES 2-5 FUNCTION KEYS AND LED INDICATOR...
Page 24: Product Features
2. Introduction 2. Introduction 2-1 PRODUCT FEATURES 2-1 PRODUCT FEATURES Ergonomic and lightweight Three in one functions (Bluetooth/ Memory/ Cabled) USB cable can be used as cabled scanner, data transferring from flash memory, and battery charging cable. Six different Bluetooth mode (Master, Slave, USB HID, iPad mode, A-303 Dongle and A-302 Dongle) to communicate between PC, mobile phone , PDA ,A-303 Dongle and A-302 Dongle.
Page 25: Product Specification
2. Introduction 2-2 PRODUCT SPECIFICATION 2-2 PRODUCT SPECIFICATION Model No. CM-2D601W Under cabled mode interface USB COM , USB HID Readable barcode type 1D : EAN/UPC, RSS, Code 39, Code 128, UCC/EAN 128, ISBN, ISBT, Interleaved, Matrix, Industrial and Standard 2 of 5, Codabar, Code 93/93i, Code 11, MSI, Plessey, Telepen, Postal Codes, GS1 databar 2D : Codablock A, Codablock F, PDF417, MicroPDF417, Aztec Code, Data Matrix, MaxiCode, QR Code, Chinese Sensible(Han Xin) code...
Page 26 2. Introduction Safety Standard FCC & CE Class B, VCCI Battery Rechargeable Li-Polymer battery ( 3.7V, 1100mAH ) and charge via USB port Ambient light Works in any lighting conditions from 0 to 100,000 lux Power Consumption Under 400mA ( operation ) , 25mA ( standby ) Remark We also offer CM-2D601M as 2 in 1 function without wireless Symbology...
Page 27: Package Information
Inside the package contain the following items: CM-2D601 Barcode Scanner Quick Start Jelly Case Barcode Scanner Hand Strap...
Page 28: Default Symbologies
2. Introduction 2-4 DEFAULT SYMBOLOGIES 2-4 DEFAULT SYMBOLOGIES Symbologies Default setting UPC-A Enabled UPC-E Enabled EAN-8 Enabled EAN-13 Enabled Disabled Gs1 Databar Omnidirectional Enabled Limited Enabled Expanded Enabled Gs1 Composite Disabled Codablock CodablockA Disabled CodablockF Disabled PDF417 PDF417 Enabled MacroPdf417 Enabled MicroPdf417 Disabled...
Page 29 2. Introduction Straight2of5(Industrial2of5) Straight2of5 Disabled (Industrial2of5) Straight2of5IATA Disabled Matrix2of5 Disabled Code11 Disabled Code-128 Enabled Gs1-128 Disabled 2DPostal Disabled ChinaPost(HongKong2of5) Disabled KoreaPost Disabled...
Page 30: Function Keys And Led Indicator
2. Introduction 2-5 FUNCTION KEYS AND LED INDICATOR 2-5 FUNCTION KEYS AND LED INDICATOR Press down Scan Button to decode or store the barcode. ○ Press down Small Trigger to perform versatile supplementary functions. For ○ instance, pressing the key will lead to erasing barcode data which have been previously decoded in Memory Mode;...
Page 31: Chapter 3: Scanner Configuration
3. Scanner Configuration Chapter 3: Scanner Configuration 3-1 CONFIGURATION BY USER MANUAL 3-2 CONFIGURATION BY SOFTWARE...
Page 32: Configuration By User Manual
3. Scanner Configuration 3. Scanner Configuration 3-1 CONFIGURATION BY USER MANUAL 3-1 Configuration by USER MANUAL In the user manual, print out the related topics of setting page, simply use the scanner to scan the barcode for configuration. For example: ENTER */$%ENTR* (Enter configuration)
Page 33: Configuration By Software
3-2 CONFIGURATION BY SOFTWARE In the product CD, you can find configuration software “Normal command setting” to configure the parameters. Scanner general settings: (CM-2D601\Software\Normal command setting\Scanner Setting.exe) Note: Please refer to the related configuration chapters or additional manual for how to use the software.
Page 34: Chapter 4 Memory / Bluetooth Mode
4. Memory / Bluetooth Mode Chapter 4: Memory / Bluetooth Mode 4-1 Memory Mode 4-1-1 Function Switch (Bluetooth mode to Memory mode) 4-1-2 Transmitting barcode data in memory mode 4-1-3 Erase barcode data (Single data/ All data) 4-2 Bluetooth Mode 4-2-1 Function switch (Memory Mode to Bluetooth mode) 4-2-2 LED indication under Bluetooth Mode 4-2-3 Bluetooth mode selection Code Table...
Page 35: Memory Mode
4. Memory / Bluetooth Mode 4. Memory / Bluetooth Mode This chapter explains the different functions between Memory function and Bluetooth function. Note: If user only purchase Memory scanner model, switching to Bluetooth mode is not applicable. 4-1 Mmory Mode 4-1 Memory Mode 4-1-1 Function switch (Bluetooth mode to Memory mode) 4-1-1 Function switch (Bluetooth mode to Memory mode)
Page 36: Erase Barcode Data (Single Data/ All Data)
4. Memory / Bluetooth Mode 2) Connect the USB cable between scanner and PC, and scan the below barcode. */$%ENTR* (1).Enter: (Enter setting) *ZMTX* (2).Send Data 4-1-3 Erase barcode data (Single data / All data) 4-1-3 Erase barcode data (single data/ all data) Erase single data: While holding Small Trigger and point to the scanned barcode, this action will erase the last previous saved barcode data in the memory.
Page 37: Bluetooth Mode
4. Memory / Bluetooth Mode 4-2 Bluetooth Mode 4-2 Bluetooth Mode User can configure different Bluetooth connection mode in different Bluetooth environment. 1. Slave Mode (For third party Bluetooth devices) 2. Master Mode (For third party Bluetooth devices) 3. HID Mode (Third party Bluetooth devices with USB HID mode) 4.
Page 38: Led Indication Under Bluetooth Mode
4. Memory / Bluetooth Mode 4-2-2 LED indication under Bluetooth Mode 4-2-2 LED indication under Bluetooth Mode Description Indicates the charge status. When the battery is running low, red LED light will be on to show a poor charge level. Once the charging process is completed, red LED will flash slowly to show a full battery charge.
Page 39: Bluetooth Mode Selection Code Table
4. Memory / Bluetooth Mode 4-2-3 Bluetooth mode selection Code Table 4-2-3 Bluetooth mode selection Code Table Bluetooth mode selection code Table Mode Description Mode selection Code Slave Mode Applied to third party Bluetooth dongle, or build-in Bluetooth devices Master Mode Applied to third party Bluetooth dongle, or build-in Bluetooth...
Page 40: Bluetooth Mode Configuration By User Manual
4. Memory / Bluetooth Mode 4-2-4 Bluetooth mode configuration by user manual 4-2-4 Bluetooth mode configuration by user manual 4-2-4-1 Slave Mode : Third party Bluetooth devices ( Mode selection code: This mode is for user to configure with third party Bluetooth dongle, or build-in Bluetooth device.
Page 41: Hid Mode - Third Party Bluetooth Devices (Mode Selection Code: 3)
4. Memory / Bluetooth Mode 4-2-4-3 HID Mode - Third party Bluetooth devices (Mode selection code: This mode is for user to configure with third party Bluetooth dongle, or build-in Bluetooth device with USB HID. For HID mode Configuration, please scan below barcodes step by step. Procedure: */$%ENTR* (1)Enter: (Enter setting)
Page 42: Dongle Mode (Mode Selection Code: 5)
4. Memory / Bluetooth Mode 4-2-4-5 A-303 dongle Mode (Mode selection code: 5) This mode is for user to configure with purchased original factory dongle, and it is USB-HID / USB-COM configurable. For A-303 Dongle mode configuration, please scan below barcodes step by step.
Page 43: Bluetooth Parameter Configuration By User Manual
4. Memory / Bluetooth Mode 4-2-5 Bluetooth parameter configuration by user manual 4-2-5 Bluetooth parameter configuration by user manual 4-2-5-1 BT Local name For Slave, Master, HID Dongle, iOS Device Mode This option enables to assign Bluetooth the scanner name. Please refer to the HEX ASCII table (Form 0~9, A~F).
Page 44: Remote Mac Address
4. Memory / Bluetooth Mode 4-2-5-2 Remote Mac Address. 1. Master Mode Mac address configuration, total of 12 digits, Please refer to the HEX ASCII table (From 0~9, A~F). Configuration Max. Configurable Length Default Setting Hexadecimal / 12 digits 000000000000 decimal barcode table Procedure:...
Page 45 4. Memory / Bluetooth Mode 2. A-303 , A302 Dongle Mode Mac address configuration, total of 12 digits, Please refer to the HEX ASCII table (From 0~9, A~F). Configuration Max. Configurable Length Default Setting Hexadecimal / 12 digits 000000000000 decimal barcode table Procedure: */$%ENTR*...
Page 46: Pin Code
4. Memory / Bluetooth Mode 4-2-5-3 Pin Code When the scanner and Bluetooth device is in the pairing process, user will need to enter the pin code for pairing confirmation. This pin code might be generate by Bluetooth devices or preconfigured by user depends on different mode setting.
Page 47: Chapter 5: Bluetooth Connection Mode Instruction
5. Bluetooth Connection Mode Instruction Chapter 5 : Bluetooth Connection Mode Instruction 5-1 Slave mode Connection (For Third party Bluetooth devices) 5-2 Master mode Connection (For Third party Bluetooth Devices) 5-3 HID mode Connection (For Third party Bluetooth devices) 5-4 iOS mode Connection 5-5 A-303 Dongle Mode Connection (USB-HID / USB COM) 5-3-1 HID mode: 5-3-2 USB-COM mode...
Page 48: Slave Mode Connection (For Third Party Bluetooth Devices)
5. Bluetooth Connection Mode Instruction 5. Bluetooth Connection Mode Instruction 5-1 Slave mode Connection (For Third party Bluetooth devices) 5-1 Slave mode Connection (For Third party Bluetooth devices) Make sure the scanner is in Bluetooth mode; please refer to chapter 4-2-1 for how to configure in Bluetooth mode.
Page 49 5. Bluetooth Connection Mode Instruction 2. Make the scanner into pairing mode, if it can search available connecting Bluetooth device, it will show the screen below: From all the finding devices, search the pairing Bluetooth device and click the left button of the mouse on finding devices.
Page 50 5. Bluetooth Connection Mode Instruction Please key in Pin Code with 1234 in this screen. After key in Pin code, press ”Next” then it will start to do verification of Pin code. After pass the verification, it will go to pairing mode. After it pairs successfully, the screen will show like down below:...
Page 51 5. Bluetooth Connection Mode Instruction 3. After it pairs successfully, click the right button of the mouse on Bluetooth sign in the system display. It will show screen below: 4. Choose ”Open Settings” function and switch to the page of ”COM Ports.” It will show screen below: From this screen can know the current using COM Port of Bluetooth device.
Page 52 5. Bluetooth Connection Mode Instruction 5. Turn on terminal software, and set COM Port as ”COM15”. It will show screen below: After select COM port, click ”Connect” button to connect. After connect successfully, it can start to scan barcode, and scan result will show in terminal screen.
Page 53: Master Mode Connection (For Third Party Bluetooth Devices)
5. Bluetooth Connection Mode Instruction 5-2 Master mode Connection (For Third party Bluetooth devices) 5-2 Master mode Connection (For Third party Bluetooth Devices) Make sure the scanner is in Bluetooth mode; please refer to chapter 4-2-1 for how to configure in Bluetooth mode. Make sure the Mode selection code is configured as “2”.
Page 54 5. Bluetooth Connection Mode Instruction Switch to ”COM ports” page. It will show screen below: In this page, click ”Add” button to create new COM port. It will show screen below: In this screen, click ”Incoming(device initiates the connection)”, and click ”OK”.
Page 55 5. Bluetooth Connection Mode Instruction Click ”OK” to finish setting Turn on terminal software, set COM Port as Incoming port, and click ”Connect” to start connect with this COM Port. It will show screen below:...
Page 56 5. Bluetooth Connection Mode Instruction Make the scanner into pairing mode. When the scanner find the PC, it will show the information in system display to let user key Pin Code. It will show screen below: Click this information and it will show screen below to let user to key Pin Code.
Page 57 5. Bluetooth Connection Mode Instruction In this time, it can start to scan barcode, scanned result will show up in the terminal screen. It will show screen below:...
Page 58: Hid Mode Connection (For Third Party Bluetooth Devices)
5. Bluetooth Connection Mode Instruction 5-3 HID mode Connection (For Third party Bluetooth devices) 5-3 HID mode Connection (For Third party Bluetooth devices) Make sure the scanner is in Bluetooth mode; please refer to chapter 4-2-1 for how to configure in Bluetooth mode. Make sure the Mode selection code is configured as “3”.
Page 59 5. Bluetooth Connection Mode Instruction In the meantime, user can use the scanner to scan corresponding barcode in order. After finished scanning, scan “OK” barcode to finish Pin Code input. In this time, it will start to verify the Pin Code. After verified the Pin Code, it will start to connect Bluetooth connection.
Page 60 5. Bluetooth Connection Mode Instruction...
Page 61: Ios Mode Connection
5. Bluetooth Connection Mode Instruction 5-4 iOS mode Connection 5-4 iOS mode Connection Make sure the scanner is in Bluetooth mode; please refer to chapter 4-2-1 for how to configure in Bluetooth mode. Make sure the Mode selection code is configured as “4”. Please refer to chapter 4-2-4-4 Please turn on iPad and select “settings”...
Page 62 5. Bluetooth Connection Mode Instruction From the scanner, press and hold pairing key(small trigger) till the blue LED light starts flashing rapidly, press down Scan Button at the same time and then release both buttons for Bluetooth pairing with your device.
Page 63 5. Bluetooth Connection Mode Instruction From the scanner, scan the digits appear on iPad to complete the pairing process. (Note: please print out the “Hexadecimal / Decimal table(page: 377)” and scan the digits, for example: “scan 4,8,3,7 –> OK.) When the pairing processes succeed, on the iPad Bluetooth devices, it will appear as Connected.
Page 64 5. Bluetooth Connection Mode Instruction Additional Function: press the small button from the scanner once, iPad will wake up the virtual keyboard for information editing.
Page 65: A-303 Dongle Mode Connection(Usb-Hid / Usb Com)
5. Bluetooth Connection Mode Instruction 5-5 A-303 Dongle mode Connection(USB-HID / USB COM) 5-5 A-303 Dongle mode Connection(USB-HID / USB COM) 5-5-1 HID mode 5-5-1 HID mode Make sure the scanner is in Bluetooth mode; please refer to chapter 4-2-1 for how to configure in Bluetooth mode. Make sure the Mode selection code is configured as “5”.
Page 66: Usb-Com Mode
5. Bluetooth Connection Mode Instruction 5-5-2 USB-COM mode 5-5-2 USB COM mode Make sure the scanner is in Bluetooth mode; please refer to chapter 4-2-1 for how to configure in Bluetooth mode. Make sure the Mode selection code is configured as “5”. Please refer to chapter 4-2-4-5.
Page 67 5. Bluetooth Connection Mode Instruction When under “USB COM” mode, please check device manager. You will know which COM port is available, then use Terminal program to receive scan data.
Page 68: A-302 Dongle Mode Connection (Usb-Hid Only)
5. Bluetooth Connection Mode Instruction 5-6 A302 Dongle mode Connection (USB-HID only) 5-6 Bluetooth HID Dongle mode Connection (USB-HID only) Make sure the scanner is in Bluetooth mode. Please refer to chapter 4-2-1 for how to configure in Bluetooth mode. Make sure the Mode selection code is configured as “6”.
Page 69: Chapter 6: Memory / Bluetooth / Cable General Setting
6. Memory / Bluetooth / Cable General Setting Chapter 6: Memory / Bluetooth / Cable General Setting 6-1 General Memory Mode Setting 6-1-1 Mode 6-1-2 Output Interface 6-1-3 App Type 6-1-4 Composite Triggers Functionality 6-1-5 Small Trigger Functionality 6-1-6 Dcplug Charge 6-1-7 GoodRead Beep Volume 6-1-8 Event Beep Volume 6-1-9 Warning Beep Volume...
Page 70 6. Memory / Bluetooth / Cable General Setting 6-1-31 Tx Code Length 6-1-32 ForceCase 6-1-33 Tx Delimiter 6-1-34 DelimiterChar 6-1-35 Tx Control Code 6-1-36 WaitKeyTime 6-1-37 Date & Time Transmission 6-1-38 Date/Time Position 6-1-39 DateTimeSpareChar 6-1-40 Reject Same 6-2 General Bluetooth Mode Setting 6-2-1 Mode 6-2-2 Output Interface 6-2-3 App Type...
Page 71: Tx Codeid
6. Memory / Bluetooth / Cable General Setting 6-2-29 Tx CodeId 6-2-30 CodeId Position 6-2-31 Tx Code Length 6-2-32 ForceCase 6-2-33 Tx Delimiter 6-2-34 DelimiterChar 6-2-35 Tx Control Code 6-2-36 Date & Time Transmission 6-2-37 Date/Time Position 6-2-38 DateTimeSpareChar 6-3 General Cable Mode Setting 6-3-1 Mode 6-3-2 Output Interface 6-3-3 App Type...
Page 72: Forcecase
6. Memory / Bluetooth / Cable General Setting 6-3-29 Tx Code Length 6-3-30 ForceCase 6-3-31 Tx Delimiter 6-3-32 DelimiterChar 6-3-33 Tx Control Code 6-3-34 Date & Time Transmission 6-3-35 Date/Time Position 6-3-36 DateTimeSpareChar 6-4 Scanner Configuration by Software 6-4-1 Firmware update 6-4-2 Scanner Configuration...
Page 73: Mode
6. Memory / Bluetooth / Cable General Setting 6. Memory / Bluetooth/ Cable General 6-1 General Memory Mode Setting 6-1 General Memory Mode Setting 6-1-1 Mode 6-1-1 Mode This function to set operation Mode: (1) Good Read Off: When pressing “Scan” key, turning on scanning light, scanning barcode correctly or over loading time to make barcode scanning incorrectly, the light will be turned off.
Page 74: Output Interface
6. Memory / Bluetooth / Cable General Setting 6-1-2 Output Interface 6-1-2 Output Interface Please scan the appropriate barcode to specify the output interface *0LF0* *0LF1* Cable Usb-Keyboard *0LF2* *0LF5* Usb-Spp Usb-Mass 6-1-3 App Type 6-1-3 App Type Whether to enable special setting Normal: Do not enable Normal Normal...
Page 75: Composite Triggers Functionality
6. Memory / Bluetooth / Cable General Setting 6-1-4 Composite Triggers Functionality ctionality 6-1-4 Composite Triggers Functionality Some supplementary functions are necessarily executed by using composite triggers though Scan Button primarily serves to scan barcodes, and Small Trigger to initiate data transmission. In Memory mode, all the scanned barcode data will be deleted by pressing small trigger and Scan button in a specified sequence described below: while holding the small key till the orange LED light starts flashing rapidly, press down Scan key at the same time and then release...
Page 76: Dcplug Charge
6. Memory / Bluetooth / Cable General Setting 6-1-6 Dcplug Charge 6-1-6 Dcplug Charge Scan the appropriate barcode to determine whether to initiate battery charge whenever the device is well connected to host PC using an interface cable. *3LI0* *3LI1* Disable Enable 6-1-7 GoodRead Beep Volume...
Page 77: Event Beep Volume
6. Memory / Bluetooth / Cable General Setting 6-1-8 Event Beep Volume 6-1-8 Event Beep Volume Scan the appropriate barcode to specify the volume of Normal Event Buzzer when certain operations, such as switching operation modes, entering data transmission mode, and deleting all saved barcodes, are initiated by using Scan Key or Small Key.
Page 78: Tx Style
6. Memory / Bluetooth / Cable General Setting 6-1-10 Tx Style 6-1-10 Tx Style Scan the appropriate barcode to specify data transmission unit which will determine how the scanned barcodes will be sent out from the barcode reader in data transit. By default, barcode data will be transmitted in batches; alternatively, scan 1By1 label to transmit single barcode data at a time by giving Scan Button a press.
Page 79: Goodread Vibrator
6. Memory / Bluetooth / Cable General Setting 6-1-12 Tx Header 6-1-12 Tx Header Scan the appropriate barcode to determine whether or not to transmit header information as part of transmitted data in Memory mode. *6LU0* *6LU1* Disable Enable 6-1-13 Tx Footer 6-1-13 Tx Footer Scan the appropriate barcode to determine whether or not to transmit footer information as part of transmitted data in Memory mode.
Page 80: Event Vibrator
6. Memory / Bluetooth / Cable General Setting 6-1-15 Event Vibrator 6-1-15 Event Vibrator Mode Event Vibrator is used to give a vibration signal whenever certain operations, such as switching operation modes, entering data transmission mode, and deleting all saved barcodes, are initiated by using Scan Button or Small Trigger.
Page 81: Scan Time
6. Memory / Bluetooth / Cable General Setting 6-1-17 Scan Time 6-1-17 Scan Time Definition : 1. The duration from user’s action to the next operation step of barcode scanner. ( E.g. Default setting : 10 Secs. To switch the operation mode, hold “Scan”...
Page 82: Scan Idle Time
6. Memory / Bluetooth / Cable General Setting 6-1-18 Scan Idle Time 6-1-18 Scan Idle Time The device will switch to power-saving mode after remaining idle for a while. This parameter is thus used to specify the length of time allocated for the scanner to elapse before power-saving mode is initiated.
Page 83: Standbytime
6. Memory / Bluetooth / Cable General Setting 6-1-19 StandbyTime 6-1-19 StandbyTime After lengthy idleness, the device will first be put into standby state in which the machine is still able to react to the emergent request yet running in lower power consumption.
Page 84: Preamble Data
6. Memory / Bluetooth / Cable General Setting 6-1-21 Preamble data 6-1-21 Preamble data Setting Preamble code content *1WW+* Configuration Length Default Setting NULL Procedure (A) Scan “Enter” barcode (B) Scan “Preamble data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 85: Postamble Data
6. Memory / Bluetooth / Cable General Setting 6-1-23 Postamble data 6-1-23 Postamble data Setting Postamblecode content *1X4+* Configuration Length Default Setting <CR><LF>(0x0D0x0A) Procedure (A) Scan “Enter” barcode (B) Scan “Postamble data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 86: Prefix Data
6. Memory / Bluetooth / Cable General Setting 6-1-25 Prefix data 6-1-25 Prefix data Setting Prefix content *0XC+* Configuration Length Default Setting NULL Procedure (A) Scan “Enter” barcode (B) Scan “Prefix data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 87: Suffix Data
6. Memory / Bluetooth / Cable General Setting 6-1-27 Suffix data 6-1-27 Suffix data Setting Suffix content *8XK+* Configuration Length Default Setting NULL Procedure (A) Scan “Enter” barcode (B) Scan “Suffix data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 88: Tx Codeid
6. Memory / Bluetooth / Cable General Setting 6-1-29 Tx CodeId 6-1-29 Tx CodeId When scanning the barcode, User might want to know the symbology of the barcode ID, This configuration enables to display the Code ID. *1W50* *1W51* Disable Enable 6-1-30 CodeId Position 6-1-30 CodeId Position...
Page 89: Forcecase
6. Memory / Bluetooth / Cable General Setting 6-1-32 ForceCase 6-1-32 ForceCase This configuration enables to convert all output digits to be same printing-case; even one barcode may have two kinds of case. *3WG0* *3WG1* None Inverse *3WG2* *3WG3* Lower Upper 6-1-33 Tx Delimiter 6-1-33 Tx Delimiter...
Page 90: Delimiterchar
6. Memory / Bluetooth / Cable General Setting 6-1-34 DelimiterChar 6-1-34 DelimiterChar Setting Delimiter content *2WO+* Configuration Length Default Setting “ “ Procedure (A) Scan “Enter” barcode (B) Scan “DelimiterChar” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 91: Waitkeytime
6. Memory / Bluetooth / Cable General Setting 6-1-36 WaitKeyTime 6-1-36 WaitKeyTime When “Tx Style” is set as “1By1”, to define the time that barcode scanner stands by until “Scan” key is pressed. *4WQ+* Configuration Range Unit Default Setting 0 ~ 255 Secs 1 Sec 30 Secs Procedure...
Page 92: Date/Time Position
6. Memory / Bluetooth / Cable General Setting 6-1-38 Date/Time Position 6-1-38 Date/Time Position If you want to display data from Memory, you can use this function to set Date/Time position. “Date & Time Transmission” must be enabled and configure the following formats:. *7WB0* *7WB1* Before...
Page 93: Mode
6. Memory / Bluetooth / Cable General Setting 6-2 General Bluetooth Mode Setting 6-2 General Bluetooth Mode Setting 6-2-1 Mode 6-2-1 Mode This function to set operation Mode: (1) Good Read Off: When pressing “Scan” key, turning on scanning light, scanning barcode correctly or over loading time to make barcode scanning incorrectly, the light will be turned off.
Page 94: Output Interface
6. Memory / Bluetooth / Cable General Setting 6-2-2 Output Interface 6-2-2 Output Interface Please scan the appropriate barcode to specify the output interface *5OZ1* *5OZ2* Spp-Slave Spp-Master *5OZ3* *5OZ4* *5OZ5* *5OZ6* A303-Dongle A302-Dongle 6-2-3 App Type 6-2-3 App type Whether to enable special setting Normal: Do not enable Normal...
Page 95: Composite Triggers Functionality
6. Memory / Bluetooth / Cable General Setting 6-2-4 Composite Triggers Functionality 6-2-4 Composite Triggers Functionality ctionality Some supplementary functions are necessarily executed by using composite triggers though Scan Button primarily serves to scan barcodes, and Small Trigger to initiate data transmission. In Bluetooth mode, Bluetooth paring is an extra function which can be initiated by pressing Small Trigger and Scan Button in a specified sequence described below: while holding Small Trigger till the blue LED light starts flashing rapidly, press down Scan Button at the same...
Page 96: Dcplug Charge
6. Memory / Bluetooth / Cable General Setting 6-2-6 Dcplug Charge 6-2-6 Dcplug Charge Scan the appropriate barcode to determine whether to initiate battery charge whenever the device is well secured into host PC using an interface cable. *0P20* *0P21* Disable Enable 6-2-7 GoodRead Beep Volume...
Page 97: Event Beep Volume
6. Memory / Bluetooth / Cable General Setting 6-2-8 Event Beep Volume 6-2-8 Event Beep Volume Scan the appropriate barcode to specify the volume of Normal Event Buzzer when certain operations, such as switching operation modes, entering data transmission mode, and deleting all saved barcodes, are initiated by using Scan Key or Small Key.
Page 98: Goodread Vibrator
6. Memory / Bluetooth / Cable General Setting 6-2-10 GoodRead Vibrator 6-2-10 GoodRead Vibrator Scan the appropriate barcode to enable or disable Good Read Vibrator when a barcode is successfully decoded. *2P40* *2P41* Disable Enable 6-2-11 Event Vibrator 6-2-11 Event Vibrator Mode Event Vibrator is used to give a vibration signal whenever certain operations, such as switching operation modes, entering data transmission mode, and deleting all saved barcodes, are initiated by using Scan Button or...
Page 99: Pairing Time
6. Memory / Bluetooth / Cable General Setting 6-2-13 Pairing Time 6-2-13 Pairing Time When timeout period expires yet the Bluetooth connection is not established, the pairing process will terminate due to the failed attempt. *1QK+* Configuration Range Unit Default Setting 1 ~ 255 Secs 1 Sec 90 Secs...
Page 100: Good Read Beep Freq
6. Memory / Bluetooth / Cable General Setting 6-2-14 Good Read Beep Freq 6-2-14 Good Read Beep Freq Please follow the below steps to specify the buzzer frequency when a barcode is decoded successfully. *8PS+* Configuration Range Unit Default Setting 100 ~ 3500 Hz 100Hz 2700 Hz...
Page 101: Good Read Beep Time
6. Memory / Bluetooth / Cable General Setting 6-2-15 Good Read Beep Time 6-2-15 Good Read Beep Time Please follow the below steps to specify buzzer duration when a barcode is decoded successfully. *0PT+* Configuration Range Unit Default Setting 10 ~ 2550 ms 10 ms 100 ms Procedure...
Page 102: Good Read Vibrator Time
6. Memory / Bluetooth / Cable General Setting 6-2-16 Good Read Vibrator time 6-2-16 Good Read Vibrator time Please follow the below steps to specify vibrator duration when a barcode is decoded successfully. *1PU+* Configuration Range Unit Default Setting 10 ~ 2550 ms 10 ms 50 ms Procedure...
Page 103: Scan Time
6. Memory / Bluetooth / Cable General Setting 6-2-17 Scan Time 6-2-17 Scan Time Definition : 1. The duration from user’s action to the next operation step of barcode scanner. ( E.g. Default setting : 10 Secs. To switch the operation mode, hold “Scan”...
Page 104: Scan Idle Time
6. Memory / Bluetooth / Cable General Setting 6-2-18 Scan Idle Time 6-2-18Scan Idle Time The device will switch to power-saving mode after remaining idle for a while. This parameter is thus used to specify the length of time allocated for the scanner to elapse before power-saving mode is initiated.
Page 105: Tx Preamble
6. Memory / Bluetooth / Cable General Setting 6-2-19 StandbyTime 6-2-19 StandbyTime After lengthy idleness, the device will first be put into standby state in which the machine is still able to react to the emergent request yet running in lower power consumption.
Page 106: Tx Postamble
6. Memory / Bluetooth / Cable General Setting 6-2-21 Preamble data 6-2-21 Preamble data Setting Preamble code content *H0G+* Configuration Length Default Setting NULL Procedure (A) Scan “Enter” barcode (B) Scan “Preamble data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 107: Tx Prefix
6. Memory / Bluetooth / Cable General Setting 6-2-23 Postamble data 6-2-23 Postamble data Setting Postamble code content *G0O+* Configuration Length Default Setting <CR><LF>(0x0D0x0A) Procedure (A) Scan “Enter” barcode (B) Scan “Postamble data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 108: Tx Suffix
6. Memory / Bluetooth / Cable General Setting 6-2-25 Prefix data 6-2-25 Prefix data Setting Prefix content *F0W+* Configuration Length Default Setting NULL Procedure (A) Scan “Enter” barcode (B) Scan “Prefix data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 109: Tx Codename
6. Memory / Bluetooth / Cable General Setting 6-2-27 Suffix data 6-2-27 Suffix data Setting Suffix content *F14+* Configuration Length Default Setting NULL Procedure (A) Scan “Enter” barcode (B) Scan “Suffix data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 110: Tx Codeid
6. Memory / Bluetooth / Cable General Setting 6-2-29 Tx CodeId 6-2-29 Tx CodeId When scanning the barcode, User might want to know the symbology of the barcode ID, This configuration enables to display the Code ID. *6ZP0* *6ZP1* Disable Enable 6-2-30 CodeId Position 6-2-30 CodeId Position...
Page 111: Forcecase
6. Memory / Bluetooth / Cable General Setting 6-2-32 ForceCase 6-2-32 ForceCase This configuration enables to convert all output digits to be same printing-case; even one barcode may have two kinds of case. *A000* *A001* None Inverse *A002* *A003* Lower Upper 6-2-33 Tx Delimiter 6-2-33 Tx Delimiter...
Page 112: Delimiterchar
6. Memory / Bluetooth / Cable General Setting 6-2-34 DelimiterChar 6-2-34 DelimiterChar Setting Delimiter content *908+* Configuration Length Default Setting “ “ Procedure (A) Scan “Enter” barcode (B) Scan “DelimiterChar” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 113: Date & Time Transmission
6. Memory / Bluetooth / Cable General Setting 6-2-36 Date & Time Transmission 6-2-36 Date & Time Transmission Whether or not to transmit Date or Time information Date Time *1ZT0* *2ZU0* Disable Disable *1ZT1* *2ZU1* Enable Enable 6-2-37 Date/Time Position 6-2-37 Date/Time Position The parameter is to use for setting Date/Time position (before or after the barcode)
Page 114: Datetimesparechar
6. Memory / Bluetooth / Cable General Setting 6-2-38 DateTimeSpareChar 6-2-38 DateTimeSpareChar Set separated symbol to distinguish date and time *A09+* Configuration Length Default Setting “ “ Procedure (A) Scan “Enter” barcode (B) Scan “ DateTimeSpareChar ” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 115: Mode
6. Memory / Bluetooth / Cable General Setting 6-3 General Cable Mode Setting 6-3 General Bluetooth Mode Setting 6-3-1 Mode 6-3-1 Mode This function to set operation Mode: (1) Good Read Off: When pressing “Scan” key, turning on scanning light, scanning barcode correctly or over loading time to make barcode scanning incorrectly, the light will be turned off.
Page 116: Output Interface
6. Memory / Bluetooth / Cable General Setting 6-3-2 Output Interface 6-3-2 Output Interface Please scan the appropriate barcode to specify the output interface *3HV1* Usb-Keyboard *3HV2* Usb-Spp 6-3-3 App Type 6-3-3 App Type Whether to enable special setting Normal: Do not enable Normal Normal Normal...
Page 117: Composite Triggers Functionality
6. Memory / Bluetooth / Cable General Setting 6-3-4 Composite Triggers Functionality ctionality 6-3-4 Composite Triggers Functionality Some supplementary functions are necessarily executed by using composite triggers though Scan Button primarily serves to scan barcodes and Small Trigger to initiate data transmission. In Cable mode, battery charge is an extra function which can be initiated by pressing Small Trigger and Scan Button in a specified sequence described below: while holding Small Trigger till the green LED light starts flashing rapidly, press down Scan Button at the same time and...
Page 118: Dcplug Charge
6. Memory / Bluetooth / Cable General Setting 6-3-6 Dcplug Charge 6-3-6 Dcplug Charge Scan the appropriate barcode to determine whether to initiate battery charge whenever the device is well connected to host PC using an interface cable. *6HY0* Disable *6HY1* Enable 6-3-7 GoodRead Beep Volume...
Page 119: Event Beep Volume
6. Memory / Bluetooth / Cable General Setting 6-3-8 Event Beep Volume 6-3-8 Event Beep Volume Scan the appropriate barcode to specify the volume of Normal Event Buzzer when certain operations, such as switching operation modes, entering data transmission mode, and deleting all saved barcodes, are initiated by using Scan Key or Small Key.
Page 120: Goodread Vibrator
6. Memory / Bluetooth / Cable General Setting 6-3-10 GoodRead Vibrator 6-3-10 GoodRead Vibrator Scan the appropriate barcode to enable or disable Good Read Vibrator when a barcode is successfully decoded. *0I00* *0I01* Disable Enable 6-3-11 Event Vibrator 6-3-11 Event Vibrator Mode Event Vibrator is used to give a vibration signal whenever certain operations, such as switching operation modes, entering data transmission mode, and deleting all saved barcodes, are initiated by using Scan Button or...
Page 121 6. Memory / Bluetooth / Cable General Setting 6-3-13 Power on light 6-3-13 Power on light On Cable mode, when the scanner is on, whether to turn on the scanning light automatically. *5I50* Disable *5I51* Enable 6-3-14 Good Read Beep Freq 6-3-14 Good Read Beep Freq When decoding successfully, it will make a sound, and you can use this setting to set Beep Frequency.
Page 122: Good Read Beep Time
6. Memory / Bluetooth / Cable General Setting 6-3-15 Good Read Beep Time 6-3-15 Good Read Beep Time When decoding successfully, it will make a sound, you can use this setting to set the duration of Beep Time. *7IP+* Configuration Range Unit Default Setting 10 ~ 2550ms...
Page 123: Scan Time
6. Memory / Bluetooth / Cable General Setting 6-3-17 Scan Time 6-3-17 Scan Time Definition : 1. The duration from user’s action to the next operation step of barcode scanner. ( E.g. Default setting : 10 Secs. To switch the operation mode, hold “Scan”...
Page 124: Tx Preamble
6. Memory / Bluetooth / Cable General Setting 6-3-18 Tx Preamble 6-3-18 Tx Preamble Preamble Code refers to a sequence of characters which precedes both Prefix Code and barcode data during data transmission. Scan the appropriate barcode to enable or disable Preamble Code. *8SG0* *8SG1* Disable...
Page 125: Tx Postamble
6. Memory / Bluetooth / Cable General Setting 6-3-20 Tx Postamble 6-3-20 Tx Postamble Postamble Code refers to a sequence of characters which appends to both barcode data and Suffix Code during data transmission. Scan the appropriate barcode to enable or disable Postamble Code. *0SH0* *0SH1* Disable...
Page 126: Tx Prefix
6. Memory / Bluetooth / Cable General Setting 6-3-22 Tx Prefix 6-3-22 Tx Prefix Prefix Code is a sequence of characters interposed between Preamble Code and barcode data during data transmission. Scan the appropriate barcode to enable or disable Prefix Code. *1SI0* *1SI1* Disable...
Page 127: Tx Suffix
6. Memory / Bluetooth / Cable General Setting 6-3-24 Tx Suffix 6-3-24Tx Suffix Suffix Code is a sequence of characters interposed between barcode data and Postamble Code during data transmission. Scan the appropriate barcode to enable or disable Suffix Code. *2SJ0* *2SJ1* Disable...
Page 128: Tx Codename
6. Memory / Bluetooth / Cable General Setting 6-3-26 Tx CodeName 6-3-26 Tx CodeName This configuration enables to show the barcode symbology name. Symbology name will be showing in front of barcode data. *3SK0* *3SK1* Disable Enable 6-3-27 Tx CodeId 6-3-27 Tx CodeId When scanning the barcode, User might want to know the symbology of the barcode ID, This configuration enables to display the Code ID.
Page 129: Tx Code Length
6. Memory / Bluetooth / Cable General Setting 6-3-29 Tx Code Length 6-3-29 Tx Code Length If user needs to know the length of the barcode data, this configuration enables to indicate the barcode length in front of barcode data. *7SO0* *7SO1* Disable...
Page 130: Tx Delimiter
6. Memory / Bluetooth / Cable General Setting 6-3-31 Tx Delimiter 6-3-31 Tx Delimiter Scan the appropriate barcode to determine whether or not to interpose the delimiter parameter between the decoded message and timestamps. *2SS0* *2SS1* Disable Enable 6-3-32 DelimiterChar 6-3-32 DelimiterChar Setting Delimiter content *6T4+*...
Page 131: Tx Control Code
6. Memory / Bluetooth / Cable General Setting 6-3-33 Tx Control Code 6-3-33 Tx Control Code Scan the appropriate barcode to determine whether or not to transmit control code info along with the decoded message if the scanned barcode contains the special ASCII code.
Page 132: Datetimesparechar
6. Memory / Bluetooth / Cable General Setting 6-3-36 DateTimeSpareChar 6-3-36 DateTimeSpareChar Set separated symbol to distinguish date and time *7T5+* Configuration Length Default Setting “ “ Procedure (A) Scan “Enter” barcode (B) Scan “ DateTimeSpareChar ” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 133: Firmware Update
6-4-1 Firmware Update Open the software” Normal command setting”, the file is located in the CD (CM-2D601\Software\Normal command setting\Scanner Setting.exe) Connect scanner with PC by USB cable, and set the scanner to ISP mode. Scan below barcodes to set the scanner to ISP mode.
Page 134 6. Memory / Bluetooth / Cable General Setting When the scanner is in ISP mode, the PC might request for driver installation, the driver is located in the CD (CM-2D601\driver\ C0801b.inf). After the scanner scan Enter. ISP barcode, LED indicator will be flashing, then proceed to “Device Manager”...
Page 135 6. Memory / Bluetooth / Cable General Setting And select the COM port (for example:COM6, Note: Baud rate is 115200) Select ”OK” for software synchronization. Under “Communication Download Kernel File” Select the kernel file ( for example: 0001-0001.Bin) Enter */$%ENTR* *ZEND*...
Page 136 6. Memory / Bluetooth / Cable General Setting Select ”Open” for firmware update After firmware updated, please exit the software. The scanner will reboot. Enter */$%ENTR* *ZEND*...
Page 137 -4-2 Scanner Configuration Open software” Normal command setting”, the file is located in the CD (CM-2D601\Software\Normal command setting\Scanner Setting.exe) Connect scanner with PC by USB cable, and Set the scanner to ISP mode. Scan below barcodes step by step to set the scanner to ISP mode.
Page 138 6. Memory / Bluetooth / Cable General Setting After the scanner scan Enter. ISP barcode, the “green” LED indicator will be flashing, then proceed to “Device Manager” to check COM Port For example: The COM Port used by scanner is COM6 In Normal command setting software, Sync Properties And select the COM port (for example:COM6, Note: Baud rate is 115200)
Page 139 6. Memory / Bluetooth / Cable General Setting Select ”OK” for software synchronization. User can change the settings of scanner (For example, enable Msi) Save the “configure content” and specified a file name in your local drive. Enter */$%ENTR* *ZEND*...
Page 140 Exit the software will exit the Normal command setting configuration and scanner will reboot. Note: For detail configuration, please refer to additional manual “barcode scanner user manual”(CM-2D601\Manuals\User manual for setting software on wireless barcode scanner.pdf) Enter */$%ENTR* *ZEND*...
Page 141: Chapter 7: General Configuration Setting
7. General Configuration Setting Chapter 7: General configuration setting 7-1 Host Interface 7-1-1 Version 7-1-2 Abort Setting 7-1-3 Enter ISP Mode 7-1-4 Barcode Default 7-1-5 All Default 7-1-6 Mode Switch 7-2 Output Interface Cable 7-2-1 USB-HID Keyboard Type 7-2-1-1 Caps Lock 7-2-1-2 Num Lock 7-2-1-3 Shift Release Caps Lock 7-2-1-4 Transmission Timeout...
Page 142 7. General Configuration Setting Bluetooth Mode 7-2-3 Bluetooth-HID Type 7-2-3-1 Caps Lock 7-2-3-2 Num Lock 7-2-3-3 Shift Release Caps Lock 7-2-3-4 Bluetooth HID Layout Settiing 7-2-3-5 Transmission Timeout 7-2-3-6 Transmission Char Delay 7-2-3-7 Transmission Char Gap Time 7-2-3-8 Transmission Record Gap Time 7-2-3-9 Output Language 7-2-4 Bluetooth-SPP Type 7-2-4-1 Communication Protocol...
Page 143 7. General Configuration Setting 7-2-6-5 ACK Timeout 7-2-6-6 Transmission Timeout 7-2-6-7 Transmission Char Delay 7-2-6-8 Transmission Char Gap Time 7-2-6-9 Transmission Record Gap Time 7-3 System Control 7-3-1 Mode 7-3-2 System Beep Volume 7-3-3 DcPlug Cable Mode 7-3-4 Date format 7-3-5 Time format 7-3-6 System Virbator 7-3-7 Show Header Str...
Page 144: Host Interface
7. General Configuration Setting 7. General Configuration Setting 7-1 Host Interface 7-1 Host Interface 7-1-1 Version 7-1-1 Version Firmware information listing, the scanner firmware information included the ISP Version, the firmware version,2D Engine Version and Bluetooth module version (if scanner Bluetooth function is available). *ZVER* Procedure: (1) Scan “Enter”...
Page 145: Enter Isp Mode
7. General Configuration Setting 7-1-3 Enter ISP Mode 7-1-3 Enter ISP Mode For software configuration, User must connect the scanner with PC via USB cable, and scan “Enter “, “ISP” to enter the ISP mode. (PC might request for Driver installation, please find the driver file “C0801b.inf ” in the CD) *ZISP* Procedure: (1) Scan “Enter”...
Page 146: Mode Switch
7. General Configuration Setting 7-1-6 Mode Switch 7-1-6 Mode Switch After reading ENTER label, scan the below appropriate barcode to switch to the desired operation mode. To Cable Mode *ZTOS* To Memory Mode *ZTOM* To BT Mode *ZTOB* Procedure: (1) Scan “Enter” Barcode (2) Scan “To Cable Mode”...
Page 147: Output Interface
7. General Configuration Setting 7- 2 Output Interface 7-2 Output Interface Cable Mode User can connect the scanner with PC via USB cable to upload the saved barcode data, or it can be used as real time USB scanner. There are two different output Interfaces: (1) USB-HID (Keyboard) Type: With USB HID type, user can use Word, Excel or any word processing software to receive barcode data.
Page 148: Usb-Hid Keyboard Type
7. General Configuration Setting 7-2-1 USB-HID Keyboard Type 7-2-1 USB-HID Keyboard Type 7-2-1-1 Caps lock Caps lock setting for the barcode data display. *3750* *3751* Auto LowerCase *3752* *3753* UpperCase Alt+ Example Barcode data "ABCdef" Status Caps Lock On Caps Lock Off Selection UpperCase ABCdef...
Page 149: Transmission Timeout
7. General Configuration Setting 7-2-1-3 Shift Release Caps Lock Scan the following barcode can let the user to press ”Shift” to release the status of Caps Lock. *5770* Disable *5771* Enable 7-2-1-4 Transmission Timeout After sending the information, how long time did not respond will start timeout *27V+* Configuration Range Unit...
Page 150: Transmission Char Delay
7. General Configuration Setting 7-2-1-5 Transmission Char Delay After setting the number of characters sent into the Delay time *37W+* Configuration Range Default Setting 0 ~ 255 Procedure (A) Scan “Enter” barcode (B) Scan “Transmission Char Delay” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 151: Usb Hid Layout Setting
7. General Configuration Setting 7-2-1-7 Transmission Record Gap Time This function can set Delay Time between 2 records. *57Y+* Configuration Range Unit Default Setting 0~2550 ms 10 ms 0 ms Procedure: Example: (A) Scan “Enter” barcode If configuration is 200 ms, the (B) Scan “Transmission Record Gap parameter value is 200 ms / 10 ms = Time”...
Page 152: Output Language
7. General Configuration Setting *6785* *6786* *6787* *6788* *6789* *678A* 7-2-1-9 Output Language To set up the target barcode encoding *7790* *7791* Big5 *7792* Gb2312 *7793* Sjis Enter */$%ENTR* *ZEND*...
Page 153: Usb-Spp(Virtual Com) Type
7. General Configuration Setting 7-2-2 USB-SPP(Virtual COM) Type 7-2-2 USB-SPP (Virtual COM) Type 7-2-2-1 Communication Protocol Whether to enable ” Ack/Nak” responese function *4850* None *4851* “Ack/Nak” 7-2-2-2 <STX> & <ETX> Characters Scan below barcodes to set if need to add STX data(before the output barcode data) &...
Page 154: Command Mode
7. General Configuration Setting 7-2-2-3 <CMD> & <BAR> Characters Scan the appropriate barcode to enable or disable <BAR> and <CMD> escape characters *6870* Disable *6871* Enable 7-2-2-4 Command Mode Scan the appropriate barcode to enable or disable Command mode for SPP *7880* Disable *7881*...
Page 155: Retransmission Count
7. General Configuration Setting 7-2-2-5 Retransmission Count To avoid data transmission loss, messages sometimes have to be resent due to a failure to receive ACK signal; When the amount of resending is out of range and STILL not yet received ACK, which means Timeout *58O+* Configuration Range Default Setting...
Page 156: Transmission Timeout
7. General Configuration Setting 7-2-2-7 Transmission Timeout After sending the information, how long time did not respond will start timeout *88R+* Configuration Range Unit Default Setting 2 ~ 255 secs 1 sec 3 secs Procedure: Example: (A) Scan “Enter” barcode If configuration is.2 sec, the (B) Scan “Transmission Timeout”...
Page 157: Transmission Char Gap Time
7. General Configuration Setting 7-2-2-9 Transmission Char Gap Time To set up the length of Delay time between character *18T+* Configuration Range Unit Default Setting 0 ~ 255 ms 1 ms 0 ms Procedure: Example: (A) Scan “Enter” barcode If configuration is. 2 ms, the (B) Scan “Transmission Char Gap parameter value is 2 ms / 1 ms = 2 Time”...
Page 158: Bluetooth Hid Type
7. General Configuration Setting Bluetooth Mode 7-2-3 Bluetooth HID Type 7-2-3 Bluetooth HID Type 7-2-3-1 Caps Lock Caps lock setting for the barcode data display. *5E91* *5E93* Alt+ LowerCase *5E92* UpperCase Example Barcode data "ABCdef" Status Caps Lock On Caps Lock Off Selection UpperCase ABCdef...
Page 159: Shift Release Caps Lock
7. General Configuration Setting 7-2-3-3 Shift Release Caps Lock Scan the following barcode can let the user to press ”Shift” to release the status of Caps Lock. *7EB0* Disable *7EB1* Enable 7-2-3-4 Bluetooth HID Layout Setting The function enables the user to specify HID keyboard language *8EC0* *8EC6* *8EC1*...
Page 160: Transmission Timeout
7. General Configuration Setting 7-2-3-5 Transmission Timeout After sending the information, how long time did not respond will start timeout *4EZ+* Configuration Range Unit Default Setting 2 ~ 255 secs 1 sec 3 secs Procedure: Example: (A) Scan “Enter” barcode If configuration is 2 sec, the (B) Scan “Transmission Timeout”...
Page 161: Transmission Char Gap Time
7. General Configuration Setting 7-2-3-7 Transmission Char Gap Time To set up the length of Delay time between character *7F1+* Configuration Range Unit Default Setting 0 ~ 255 ms 0 ms Procedure: Example: (A) Scan “Enter” barcode If configuration is 2 ms, the (B) Scan “Transmission Char Gap parameter value is 2 ms / 1 ms = 2 Time”...
Page 162: Output Language
7. General Configuration Setting 7-2-3-9 Output Language To set up the target barcode encoding *0ED0* *0ED1* Big5 *0ED2* GB2312 *0ED3* Sjis Enter */$%ENTR* *ZEND*...
Page 163: Bluetooth-Spp Type
7. General Configuration Setting 7-2-4 Bluetooth-SPP Type 7-2-4 Bluetooth-SPP Type 7-2-4-1 Communication Protocol Whether to enable ” Ack/Nak” responese function *6F90* None *6F91* “Ack”/”Nak” 7-2-4-2 <STX> & <ETX> Characters Scan below barcodes to set if need to add STX data(before the output barcode data) &...
Page 164: Cmd> & Characters
7. General Configuration Setting 7-2-4-3 <CMD> & <BAR> Characters Scan the appropriate barcode to enable or disable <BAR> and <CMD> escape characters *8FB0* Disable *8FB1* Enable 7-2-4-4 Command Mode Scan the appropriate barcode to enable or disable Command mode for SPP *0FC0* Disable *0FC1*...
Page 165: Retransmission Count
7. General Configuration Setting 7-2-4-5 Retransmission Count To avoid data transmission loss, messages sometimes have to be resent due to a failure to receive ACK signal; When the amount of resending is out of range and STILL not yet received ACK, which means Timeout *7FS+* Configuration Range Default Setting...
Page 166: Transmission Timeout
7. General Configuration Setting 7-2-4-7 Transmission Timeout After sending the information, how long time did not respond will start timeout *1FV+* Configuration Range Unit Default Setting 2 ~ 255 secs 1 sec 3 secs Procedure: Example: (A) Scan “Enter” barcode If configuration is.2 sec, the (B) Scan “Transmission Timeout”...
Page 167: Transmission Char Gap Time
7. General Configuration Setting 7-2-4-9 Transmission Char Gap Time To set up the length of Delay time between character *3FX+* Configuration Range Unit Default Setting 0 ~ 255 ms 1 ms 0 ms Procedure: Example: (A) Scan “Enter” barcode If configuration is. 2 ms, the (B) Scan “Transmission Char Gap parameter value is 2 ms / 1 ms = 2 Time”...
Page 168: Memory Hid Type
7. General Configuration Setting Memory Mode 7-2-5 Memory HID Type 7-2-5 Memory HID Type 7-2-5-1 Caps Lock Caps lock setting for the barcode data display. *8AP0* *8AP1* LowerCase Auto *8AP2* *8AP3* UpperCase Alt+ Example Barcode data "ABCdef" Status Caps Lock On Caps Lock Off Selection UpperCase ABCdef...
Page 169: Shift Release Caps Lock
7. General Configuration Setting 7-2-5-3 Shift Release Caps Lock Scan the following barcode can let the user to press ”Shift” to release the status of Caps Lock. *1AR0* Disable *1AR1* Enable 7-2-5-4 Memory HID Layout Setting The function enables the user to specify HID keyboard language *2AS0* *2AS6* *2AS1*...
Page 170: Transmission Timeout
7. General Configuration Setting 7-2-5-5 Transmission Timeout After sending the information, how long time did not respond will start timeout *8BF+* Configuration Range Unit Default Setting 2 ~ 255 secs 1 sec 3 secs Procedure: Example: (A) Scan “Enter” barcode If configuration is 2 sec, the (B) Scan “Transmission Timeout”...
Page 171: Transmission Char Gap Time
7. General Configuration Setting 7-2-5-7 Transmission Char Gap Time To set up the length of Delay time between character *1BH+* Configuration Range Unit Default Setting 0 ~ 255 ms 0 ms Procedure: Example: (A) Scan “Enter” barcode If configuration is 2 ms, the (B) Scan “Transmission Char Gap parameter value is 2 ms / 1 ms = 2 Time”...
Page 172: Output Language
7. General Configuration Setting 7-2-5-9 Output Language To set up the target barcode encoding *3AT0* *3AT1* Big5 *3AT2* GB2312 *3AT3* Sjis Enter */$%ENTR* *ZEND*...
Page 173: Memory-Spp Type
7. General Configuration Setting 7-2-6 Memory-SPP Type 7-2-6 Memory-SPP Type 7-2-6-1 Communication Protocol Whether to enable ” Ack/Nak” responese function *0BP0* None *0BP1* “Ack”/”Nak” 7-2-6-2 <STX> & <ETX> Characters Scan below barcodes to set if need to add STX data(before the output barcode data) &...
Page 174: Cmd> & Characters
7. General Configuration Setting 7-2-6-3 <CMD> & <BAR> Characters Scan the appropriate barcode to enable or disable <BAR> and <CMD> escape characters *2BR0* Disable *2BR1* Enable 7-2-6-4 Retransmission Count To avoid data transmission loss, messages sometimes have to be resent due to a failure to receive ACK signal;...
Page 175: Ack Timeout
7. General Configuration Setting 7-2-6-5 ACK Timeout To set up the period of time to receive ACK after sending data *3C9+* Configuration Range Unit Default Setting 2 ~ 255 secs 1 sec 3 secs Procedure: Example: (A) Scan “Enter” barcode If configuration is.2 sec, the (B) Scan “ACK Timeout”...
Page 176: Transmission Char Delay
7. General Configuration Setting 7-2-6-7 Transmission Char Delay After setting the number of characters sent into the Delay time *6CC+* Configuration Range Default Setting 0 ~ 255 Procedure (A) Scan “Enter” barcode (B) Scan “Transmission Char Delay” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 177: Transmission Record Gap Time
7. General Configuration Setting 7-2-6-9 Transmission Record Gap Time This function can set Delay Time between 2 records. *8CE+* Configuration Range Unit Default Setting 0~2550 ms 10 ms 0 ms Procedure: Example: (A) Scan “Enter” barcode If configuration is 200 ms, the (B) Scan “Transmission Record Gap parameter value is 200 ms / 10 ms = Time”...
Page 178: System Control
7. General Configuration Setting 7-3 System Control 7-3 System Control 7-3-1 Mode 7-3-1 Mode Set the controlling mode *53K0* *53K4* Cable Cable & Bluetooth *53K1* *53K5* Memory Memory & Bluetooth *53K2* *53K6* Cable & Memory Cable & Memory & Bluetooth *53K3* Bluetooth 7-3-2 System Beep Volume...
Page 179: Dcplug Cable Mode
7. General Configuration Setting 7-3-3 DcPlug Cable Mode 7-3-3 DcPlug Cable Mode The scanner connects PC with cable, it is forced back to Cable mode, and it is no way to switch to other mode. When the machine does not connect with cable, it will go back to previous operating mode.
Page 180: Date Format
7. General Configuration Setting 7-3-4 Date Format 7-3-4 Date Format Setting the date display format *63U0* YYYYMMDD *63U1* MMDDYYYY *63U2* DDMMYYYY *63U3* YYMMDD *63U4* MMDDYY *63U5* DDMMYY 7-3-5 Time Format 7-3-5 Time Format Setting the Time display format *73V0* HHMMSS *73V1* HHMM *73V2*...
Page 181: System Virbator
7. General Configuration Setting 7-3-6 System Vibrator 7-3-6 System Virbator Whether it needs to activate warning vibration of system category *23Q0* Disable *23Q1* Enable 7-3-7 Show Header Str 7-3-7 Show Header Str When it is during MemTx, whether send out the data of Header. *83W0* Disable *83W1*...
Page 182: Show Header Sernum
7. General Configuration Setting 7-3-9 Show Header SerNum 7-3-9 Show Header SerNum When it shows Header data, whether shows SerNum *03X0* Disable *03X1* Enable 7-3-10 Show Footer SerNum 7-3-10 Show Footer SerNum When it shows Footer data, whether shows SerNum. *6420* Disable *6421*...
Page 183: Show Footer Date & Time
7. General Configuration Setting 7-3-12 Show Footer Date & Time 7-3-12 Show Footer Date & Time When it shows Footer data, whether shows date and time The footer Date & Time is defined as the time when the previous all data was deleted. Show date Show Time *7430*...
Page 184: Date Separator
7. General Configuration Setting 7-3-15 Date Separator 7-3-15 Date Separator Set separation sign of date *24G+* Configuration length Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “Date Separator” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 185: Dle Escape Characters
7. General Configuration Setting 7-3-17 DLE Escape Characters 7-3-17 DLE Escape Characters Set Escape digits *44I+* Configuration Length Default Setting 0x10 Procedure: (A) Scan “Enter” barcode (B) Scan “DLE Escape Characters” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 186: Bar Escape Characters
7. General Configuration Setting 7-3-19 BAR Escape Characters 7-3-19 BAR Escape Characters Set Bar digits in Record Packed Format *64K+* Configuration Length Default Setting 0x11 Procedure: (A) Scan “Enter” barcode (B) Scan “BAR Escape Characters” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 187: Stx Escape Characters
7. General Configuration Setting 7-3-21 STX Escape Characters 7-3-21 STX Escape Characters Set Stx digits *74L+* Configuration Length Default Setting 0x02 Procedure: (A) Scan “Enter” barcode (B) Scan “STX Escape Characters” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 188: Set Date & Time
7. General Configuration Setting 7-3-23 Set Date & Time 7-3-23 Set Date & Time I t i s a b l e t o r e a d b e l o w b a r c o d e s t o s e t t h e Y e a r / M o n t h / D a t e / T i m e ( Y Y M M D D h h m m s s ) *ZCLK* Configuration Length...
Page 189: All Memory Data Transmission
7. General Configuration Setting 7-3-25 All Memory Data Transmission 7-3-25 All Memory Data Transmission When scan this barcode, it is able to output the data in the memory. *ZMTX* Procedure: (A) Scan “Enter” Barcode (B) Scan “All Memory Data Transmission” Barcode 7-3-26 Footer Characters 7-3-26 Footer Characters When output the barcode data from memory, the Footer is able to change to...
Page 190 7. General Configuration Setting 7-3-27 Header Characters 7-3-27 Header Characters When output the barcode data from memory, the Header is able to change to what the string you need, max is 16 characters. *H34+* Configuration Length Default Setting <Header> Procedure: (A) Scan “Enter”...
Page 191: Chapter 8: Symbology Settings
8. Symbology Settings Chapter 8: Symbology Settings 8-1 Barcode Symbologies Default setting chart 8-2 UPC-A 8-3 UPC-E 8-4 EAN-13 8-5 EAN-8 8-6 Msi 8-7 Gs1 Databar 8-8 Gs1 Composite 8-9 Codablock 8-10 PDF417 8-11 Tlc39 8-12 QR Code 8-13 DataMatrix 8-14 MaxiCode 8-15 Aztec 8-16 ChineseSensible(HanXinCode)
Page 192: Barcode Symbologies Default Setting Chart
8. Symbology Settings 8. Symbology Settings 8-1 Barcode Symbologies Default setting Chart 8-1 Barcode Symbologies Default Setting Chart Barcode type Read Length Truncate Min. Lead Enable －－－－－－－－ UPC-A UPC-E Enable －－－－－...
Page 193 8. Symbology Settings ChinaPost(HongKon Disable g2of5) KoreaPost Disable Enter */$%ENTR* *ZEND*...
Page 194: Upc-A
8. Symbology Settings 8-2 UPC-A 8-2 UPC-A 8-2-1 Read 8-2-1 Read Whether the barcode can be scanned *QVB0* Disable *QVB1* Enable 8-2-2 CheckDigit 8-2-2 CheckDigit Whether to send Check Digit *KV50* Disable *KV51* Enable 8-2-3 Addon2 8-2-3 Addon2 Whether able to read 2 digit additional code *MV70* Disable *MV71*...
Page 195: Addon5
8. Symbology Settings 8-2-4 Addon5 8-2-4 Addon5 Whether able to read 5 digit additional code *NV80* Disable *NV81* Enable 8-2-5 Wait Add-on 8-2-5 Wait Add-on Whether only to read barcode with additional code *OV90* Disable *OV91* Enable 8-2-6 Addon Separator 8-2-6 Addon Separator Whether use space to distinguish barcode and additional code *PVA0*...
Page 196: Coupon Gs1Databar Output
8. Symbology Settings 8-2-7 Coupon Gs1DataBar Output 8-2-7 Coupon Gs1DataBar Output When scanning the barcode data of UPC and GS1 Databar at the same time, whether to only indicate the content of GS1 Databar *JVD0* Disable *JVD1* Enable 8-2-8 ExtendedCouponCode 8-2-8 ExtendedCouponCode Use the following codes to enable or disable UPC-A and EAN-13with Extended coupon code:...
Page 197: Wait Addon Time
8. Symbology Settings 8-2-9 Wait Addon Time 8-2-9 Wait Addon Time Wait for decoding additional code, need to use” Wait Add-on” ; If to get the additional code in a specified decoding time, then indicate, otherwise do not indicate *KVE+* Configuration Range Unit Default Setting...
Page 198: Truncateleading
8. Symbology Settings 8-2-11 TruncateLeading 8-2-11 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *I0Y+* Configuration Range Default Setting 0~12 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 199: Truncatezero
8. Symbology Settings 8-2-13 TruncateZero 8-2-13 TruncateZero Whether to omit 0 from the beginning of the barcode *N120* Disable *N121* Enable Insertion1DataPosition 8-2-14 8-2-14 Insertion1DataPosition To set up the position to insert data1 *P14+* Configuration Range Default Setting 0~12 Procedure: (A) Scan “Enter”...
Page 200: Insertion1Data
8. Symbology Settings Insertion1Data 8-2-15 8-2-15 Insertion1Data To set up data1 to be inserted *I16+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 201: Insertion2Data
8. Symbology Settings Insertion2Data 8-2-17 8-2-17 Insertion2Data To set up data2 to be inserted *M1A+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 202: Read
8. Symbology Settings 8-3 UPC-E 8-3 UPC-E 8-3-1 Read 8-3-1 Read Whether the barcode can be scanned *MVG0* Disable *MVG1* Enable 8-3-2 Expansion 8-3-2 Expansion This expansion function is for UPC-E only. It will extend the barcode to be 12-digits by “0“. *OVI0* Disable *OVI1*...
Page 203: Checkdigit
8. Symbology Settings 8-3-3 CheckDigit 8-3-3 CheckDigit Whether to send Check Digit *PVJ0* Disable *PVJ1* Enable 8-3-4 Addon2 8-3-4 Addon2 Whether able to read 2 digit additional code *IVL0* Disable *IVL1* Enable 8-3-5 Addon5 8-3-5 Addon5 Whether able to read 5 digit additional code *JVM0* Disable *JVM1*...
Page 204: Wait Addon
8. Symbology Settings 8-3-6 Wait addon 8-3-6 Wait addon Whether only to read barcode with additional code *KVN0* Disable *KVN1* Enable 8-3-7 Addon Separator 8-3-7 Addon Separator Whether use space to distinguish barcode and additional code *LVO0* Disable *LVO1* Enable Enter */$%ENTR* *ZEND*...
Page 205: Wait Addon Time
8. Symbology Settings 8-3-8 Wait Addon Time 8-3-8 Wait Addon Time Wait for decoding additional code, need to use ” Wait Add-on” ;If to get the additional code in a specified decoding time, then indicate, otherwise do not indicate *KVE+* Configuration Range Unit Default Setting...
Page 206: Truncateending
8. Symbology Settings 8-3-10 TruncateEnding 8-3-10 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *EUS+* Configuration Range Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 207: Insertion1Dataposition
8. Symbology Settings 8-3-12 Insertion1DataPosition 8-3-12 Insertion1DataPosition To set up the position to insert data1 *9UW+* Configuration Range Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 208: Insertion2Dataposition
8. Symbology Settings Insertion2DataPosition 8-3-14 Insertion2DataPosition 8-3-14 To set up the position to insert data2 *EV0+* Configuration Range Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 209: Read
8. Symbology Settings 8-4 EAN-13 8-4 EAN-13 8-4-1 Read 8-4-1 Read Whether the barcode can be scanned *MVP0* Disable *MVP1* Enable 8-4-2 CheckDigit 8-4-2 CheckDigit Whether to send Check Digit *NVQ0* Disable *NVQ1* Enable 8-4-3 Addon2 8-4-3 Addon2 Whether able to read 2 digit additional code *OVR0* Disable *OVR1*...
Page 210: Addon5
8. Symbology Settings 8-4-4 Addon5 8-4-4 Addon5 Whether able to read 5 digit additional code *PVS0* Disable *PVS1* Enable 8-4-5 Wait addon 8-4-5 Wait addon Whether only to read barcode with additional code *QVT0* Disable *QVT1* Enable 8-4-6 Addon Separator 8-4-6 Addon Separator Whether use space to distinguish barcode and additional code *IVU0*...
Page 211: Isbn Conversion
8. Symbology Settings 8-4-7 ISBN Conversion 8-4-7 ISBN Conversion If the barcode meets ”ISBN” regulation, whether to convert the scanning result to ISBN coding *JVV0* Disable *JVV1* Enable 8-4-8 Wait Addon Time 8-4-8 Wait Addon Time Wait for decoding additional code, need to use ” Wait Add-on”; If to get the additional code in a specified decoding time, then indicate, otherwise do not indicate *KVE+* Configuration Range...
Page 212: Truncateleading
8. Symbology Settings 8-4-9 TruncateLeading 8-4-9 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *O1C+* Configuration Range Default Setting 0~13 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 213: Truncatezero
8. Symbology Settings 8-4-11 TruncateZero 8-4-11 TruncateZero Whether to omit 0 from the beginning of the barcode *J1G0* Disable *J1G1* Enable 8-4-12 Insertion1DataPosition 8-4-12 Insertion1DataPosition To set up the position to insert data1 *L1I+* Configuration Range Default Setting 0~13 Procedure: (A) Scan “Enter”...
Page 214: Insertion1Data
8. Symbology Settings 8-4-13 Insertion1Data Insertion1Data 8-4-13 To set up data1 to be inserted *N1K+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 215: Insertion2Data
8. Symbology Settings Insertion2Data 8-4-15 Insertion2Data 8-4-15 To set up data2 to be inserted *I1O+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 216: Read
8. Symbology Settings 8-5 EAN-8 8-5 EAN-8 8-5-1 Read 8-5-1 Read Whether the barcode can be scanned *KVW0* Disable *KVW1* Enable 8-5-2 CheckDigit 8-5-2 CheckDigit Whether to send Check Digit *LVX0* Disable *LVX1* Enable 8-5-3 Addon2 8-5-3 Addon2 Whether able to read 2 digit additional code. *MVY0* Disable *MVY1*...
Page 217: Addon5
8. Symbology Settings 8-5-4 Addon5 8-5-4 Addon5 Whether able to read 5 digit additional code *NVZ0* Disable *NVZ1* Enable 8-5-5 Wait addon 8-5-5 Wait addon Whether only to read barcode with additional code *PW00* Disable *PW01* Enable 8-5-6 Addon Separator 8-5-6 Addon Separator Whether use space to distinguish barcode and additional code *QW10*...
Page 218: Wait Addon Time
8. Symbology Settings 8-5-7 Wait Addon Time 8-5-7 Wait Addon Time Wait for decoding additional code, need to use” Wait Add-on” ; If to get the additional code in a specified decoding time, then indicate, otherwise do not indicate *KVE+* Configuration Range Unit Default Setting...
Page 219: Truncateending
8. Symbology Settings 8-5-9 TruncateEnding 8-5-9 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *9UE+* Configuration Range Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 220: Insertion1Dataposition
8. Symbology Settings 8-5-11 Insertion1DataPosition 8-5-11 Insertion1DataPosition To set up the position to insert data1 *DUI+* Configuration Range Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 221: Insertion2Dataposition
8. Symbology Settings 8-5-13 Insertion2DataPosition Insertion2DataPosition 8-5-13 To set up the position to insert data2 *HUM+* Configuration Range Default Setting Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 222: Read
8. Symbology Settings 8-6 Msi 8-6 Msi 8-6-1 Read 8-6-1 Read Whether the barcode can be scanned. *IW20* Disable *IW21* Enable 8-6-2 Chksum Verification 8-6-2 Chksum Verification To set up the regulation of check digit, only barcode meet the regulation can be scanned *JW30* *JW31*...
Page 223: Min Code Length
8. Symbology Settings 8-6-3 Min Code Length 8-6-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *KW4+* Configuration Range Default Setting 4~48 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 224: Truncateleading
8. Symbology Settings 8-6-5 TruncateLeading 8-6-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *M2I+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 225: Truncatezero
8. Symbology Settings 8-6-7 TruncateZero 8-6-7 TruncateZero Whether to omit 0 from the beginning of the barcode *Q2M0* Disable *Q2M1* Enable 8-6-8 Insertion1DataPosition 8-6-8 Insertion1DataPosition To set up the position to insert data1 *J2O+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter”...
Page 226: Insertion1Data
8. Symbology Settings 8-6-9 Insertion1Data 8-6-9 Insertion1Data To set up data1 to be inserted *L2Q+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 227: Insertion2Data
8. Symbology Settings 8-6-11 Insertion2Data 8-6-11 Insertion2Data To set up data2 to be inserted *P2U+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 228: Omnidirectionalread
8. Symbology Settings 8-7 Gs1Databar 8-7 Gs1Databar 8-7-1 OmnidirectionalRead 8-7-1 OmnidirectionalRead Whether the barcode can be scanned *MW60* Disable *MW61* Enable 8-7-2 LimitedRead 8-7-2 LimitedRead Whether the barcode can be scanned *NW70* Disable *NW71* Enable Enter */$%ENTR* *ZEND*...
Page 229: Expanded Read
8. Symbology Settings 8-7-3 Expanded Read 8-7-3 Expanded Read Whether the barcode can be scanned *OW80* Disable *OW81* Enable 8-7-4 Min Code Length 8-7-4 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *PW9+* Configuration Range...
Page 230: Max Code Length
8. Symbology Settings 6-7-5 Max Code Length 8-7-5 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *QWA+* Configuration Range Default Setting 4~74 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 231: Truncateleading
8. Symbology Settings 8-7-6 TruncateLeading 8-7-6 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *O76+* *P7Y+* *M8C+* Gs1DataBar Gs1DataBar Limited Gs1DataBar Expanded Type Configuration Range Default Setting Gs1DataBar 0-2435 Gs1DataBar Limited 0-74 Gs1DataBar Expanded 0-74...
Page 232: Truncateending
8. Symbology Settings 8-7-7 TruncateEnding 8-7-7 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *Q78+* *J80+* *O8E+* Gs1DataBar Gs1DataBar Limited Gs1DataBar Expanded Type Configuration Range Default Setting Gs1DataBar 0-2435 Gs1DataBar Limited 0-74 Gs1DataBar Expanded 0-74...
Page 233: Truncatezero
8. Symbology Settings 8-7-8 TruncateZero 8-7-8 TruncateZero Whether to omit 0 from the beginning of the barcode Gs1DataBar: *J7A0* Disable *J7A1* Enable Gs1DataBar Limited: *L820* Disable *L821* Enable Gs1DataBar Expanded: *Q8G0* Disable *Q8G1* Enable Enter */$%ENTR* *ZEND*...
Page 234: Insertion1Dataposition
8. Symbology Settings 8-7-9 Insertion1DataPosition 8-7-9 Insertion1DataPosition To set up the position to insert data1 *L7C+* *N84+* *J8I+* Gs1DataBar Gs1DataBar Limited Gs1DataBar Expanded Type Configuration Range Default Setting Gs1DataBar 0-2435 Gs1DataBar Limited 0-74 Gs1DataBar Expanded 0-74 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition”...
Page 235: Insertion1Data
8. Symbology Settings 8-7-10 Insertion1Data 8-7-10 Insertion1Data To set up data1 to be inserted *N7E+* *P86+* *L8K+* Gs1DataBar Gs1DataBar Limited Gs1DataBar Expanded Type Configuration Length Default Setting Gs1DataBar NULL Gs1DataBar Limited NULL Gs1DataBar Expanded NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data”...
Page 236: Insertion2Dataposition
8. Symbology Settings 8-7-11 Insertion2DataPosition 8-7-11 Insertion2DataPosition To set up the position to insert data2 *P7G+* *I88+* *N8M+* Gs1DataBar Gs1DataBar Limited Gs1DataBar Expanded Type Configuration Range Default Setting Gs1DataBar 0-2435 Gs1DataBar Limited 0-74 Gs1DataBar Expanded 0-74 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition”...
Page 237: Insertion2Data
8. Symbology Settings 8-7-12 Insertion2Data 8-7-12 Insertion2Data To set up data2 to be inserted *I7I+* *K8A+* *P8O+* Gs1DataBar Gs1DataBar Limited Gs1DataBar Expanded Type Configuration Length Default Setting Gs1DataBar NULL Gs1DataBar Limited NULL Gs1DataBar Expanded NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data”...
Page 238: Read
8. Symbology Settings 8-8 Gs1 Composite 8-8 Gs1 Compsite 8-8-1 Read 8-8-1 Read Whether the barcode can be scanned. *IX10* Disable *IX11* Enable 8-8-2 Upc/EanVersion 8-8-2 Upc/EanVersion Scan the UPC/EAN Version on bar code to decode GS1 Composite symbols that have a U.P.C.
Page 239: Gs1Emulation
8. Symbology Settings 8-8-3 Gs1Emulation 8-8-3 Gs1Emulation The scanner can automatically format the output from GS1 data carrier to emulate what would be encoded in an equivalent GS1-128 or GS1 Databar cmbol. Gs1-128: It GS1-128 Emulation is scanned, all retail codes(U.P.C., UPC-E, EAN8, EAN13) are expanded out to 16 digits.
Page 240: Min Code Length
8. Symbology Settings 8-8-4 Min Code Length 8-8-4 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *KX3+* Configuration Range Default Setting 1~2435 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 241: Truncateleading
8. Symbology Settings 8-8-6 TruncateLeading 8-8-6 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *O76+* Configuration Range Default Setting 0~2435 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 242: Truncatezero
8. Symbology Settings 8-8-8 TruncateZero 8-8-8 TruncateZero Whether to omit 0 from the beginning of the barcode *J7A0* Disable *J7A1* Enable 8-8-9 Insertion1DataPosition 8-8-9 Insertion1DataPosition To set up the position to insert data1 *L7C+* Configuration Range Default Setting 0~2435 Procedure: (A) Scan “Enter”...
Page 243: Insertion1Data
8. Symbology Settings 8-8-10 Insertion1Data 8-8-10 Insertion1Data To set up data1 to be inserted *N7E+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 244: Insertion2Data
8. Symbology Settings 8-8-12 Insertion2Data 8-8-12 Insertion2Data To set up data2 to be inserted *I7I+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 245: Codablockaread
8. Symbology Settings 8-9 Codablock 8-9 Codeblock 8-9-1 CodablockARead 8-9-1 CodeblockARead Whether the barcode can be scanned *IWB0* Disable *IWB1* Enable 8-9-2 CodablockFRead 8-9-2 CodablockFRead Whether the barcode can be scanned *NWG0* Disable *NWG1* Enable Enter */$%ENTR* *ZEND*...
Page 246: Min Code Length
8. Symbology Settings 8-9-3 Min Code Length 8-9-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *JWC+* *OWH+* CodablocA CodablocF Type Configuration Range Default Setting CodablocA 1~600 CodablocF 1~2048 Procedure: (A) Scan “Enter”...
Page 247: Truncateleading
8. Symbology Settings 8-9-5 TruncateLeading 8-9-5 TruncateLeading To set up the number of digits to be omitted from the beginning the barcode *EZE+* *I4U+* CodablocA CodablocF Type Configuration Range Default Setting CodablocA 1~600 CodablocF 1~2048 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading”...
Page 248: Truncatezero
8. Symbology Settings 8-9-7 TruncateZero 8-9-7 TruncateZero Whether to omit 0 from the beginning of the barcode CodablocA CodablocF *9ZI0* *M4Y0* Disable Disable *9ZI1* *M4Y1* Enable Enable 8-9-8 Insertion1DataPosition 8-9-8 Insertion1DataPosition To set up the position to insert data1 *BZK+* *P50+* CodablocA CodablocF...
Page 249: Insertion1Data
8. Symbology Settings 8-9-9 Insertion1Data 8-9-9 Insertion1Data To set up data1 to be inserted *DZM+* *I52+* CodablocA CodablocF Type Configuration Length Default Setting CodablocA NULL CodablocF NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 250: Insertion2Data
8. Symbology Settings 8-9-11 Insertion2Data 8-9-11 Insertion2Data To set up data2 to be inserted *HZQ+* *M56+* CodablocA CodablocF Type Configuration Length Default Setting CodablocA NULL CodablocF NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 251: Pdf417 Read
8. Symbology Settings 8-10 Pdf417 8-10 Pdf417 8-10-1 Pdf417 Read 8-10-1 Pdf417 Read Whether the barcode can be scanned *JWL0* Disable *JWL1* Enable 8-10-2 MacroPdf417 Read 8-10-2 MacroPdf417 Read MacroPDF417 is an implementation of PDF417 capable of encoding very large amounts of data into multiple PDF417 bar codes.
Page 252: Poorquality Pdfcodes Read
8. Symbology Settings 8-10-3 PoorQuality PDFCodes Read 8-10-3 PoorQuality PDFCodes Read This setting improves the scanner's ability to read damaged or badly printed PDF codes by combining information from multiple images. When Poor Quality PDF On is scanned, poor quality PDF code reading is improved, but the scanner's snappiness is decreased, making it less aggressive when reading good quality bar codes.
Page 253: Min Code Length
8. Symbology Settings 8-10-5 Min Code Length 8-10-5 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *LWN+* *KWV+* Pdf417 MicroPdf417 Type Configuration Range Default Setting Pdf417 1~2750 MicroPdf417 1~366 Procedure: (A) Scan “Enter”...
Page 254: Truncateleading
8. Symbology Settings 8-10-7 TruncateLeading 8-10-7 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *O58+* *CYM+* Pdf417 MicroPdf417 Type Configuration Range Default Setting Pdf417 0~2750 MicroPdf417 0~366 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading”...
Page 255: Truncatezero
8. Symbology Settings 8-10-9 TruncateZero 8-10-9 TruncateZero Whether to omit 0 from the beginning of the barcode Pdf417 MicroPdf417 *J5C0* *GYQ0* Disable Disable *J5C1* *GYQ1* Enable Enable 8-10-10 Insertion1DataPosition 8-10-10 Insertion1DataPosition To set up the position to insert data1 *L5E+* *9YS+* Pdf417 MicroPdf417...
Page 256: Insertion1Data
8. Symbology Settings 8-10-11 Insertion1Data 8-10-11 Insertion1Data To set up data1 to be inserted *N5G+* *BYU+* Pdf417 MicroPdf417 Type Configuration Length Default Setting Pdf417 NULL MicroPdf417 NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 257: Insertion2Data
8. Symbology Settings 8-10-13 Insertion2Data 8-10-13 Insertion2Data To set up data2 to be inserted *I5K+* *FYY+* Pdf417 MicroPdf417 Type Configuration Length Default Setting Pdf417 NULL MicroPdf417 NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 258: Tlc39
8. Symbology Settings 8-11 Tlc39 8-11 Tlc39 8-11-1 Read 8-11-1 Read Whether the barcode can be scanned *PX80* Disable *PX81* Enable 8-11-2 TruncateLeading 8-11-2 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *9Z0+* Configuration Range Default Setting...
Page 259: Truncateending
8. Symbology Settings 8-11-3 TruncateEnding 8-11-3 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *BZ2+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 260: Insertion1Dataposition
8. Symbology Settings 8-11-5 Insertion1DataPosition 8-11-5 Insertion1DataPosition To set up the positon to insert data1 *FZ6+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 261: Insertion2Dataposition
8. Symbology Settings 8-11-7 Insertion2DataPosition 8-11-7 Insertion2DataPosition To set up the position to insert data2 *AZA+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 262: Qr Code
8. Symbology Settings 8-12 QRCode 8-12 QRCode 8-12-1 Read 8-12-1 Read Whether the barcode can be scanned. *QX90* Disable *QX91* Enable 8-12-2 Append 8-12-2 Append To set up whether able to scan multiple related barcodes, and decode them into a complete QR Code barcode Off: Disable this function On: Enable this function ;...
Page 263: Min Code Length
8. Symbology Settings 8-12-3 Min Code Length 8-12-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *IXA+* Configuration Range Default Setting 1~7089 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 264: Truncateleading
8. Symbology Settings 8-12-5 TruncateLeading 8-12-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *K5M+* Configuration Range Default Setting 0~7089 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 265: Truncatezero
8. Symbology Settings 8-12-7 TruncateZero 8-12-7 TruncateZero Whether to omit 0 from the beginning of the barcode *O5Q0* Disable *O5Q1* Enable 8-12-8 Insertion1DataPosition 8-12-8Insertion1DataPosition To set up the position to insert data1 *Q5S+* Configuration Range Default Setting 0~7089 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition”...
Page 266: Insertion1Data
8. Symbology Settings 8-12-9 Insertion1Data 8-12-9 Insertion1Data To set up data1 to be inserted *J5U+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 267: Insertion2Data
8. Symbology Settings 8-12-11 Insertion2Data 8-12-11 Insertion2Data To set up data2 to be inserted *N5Y+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 268: Datamatrix
8. Symbology Settings 8-13 DataMatrix 8-13 DataMatrix 8-13-1 Read 8-13-1 Read Whether the barcode can be scanned *OXG0* Disable *OXG1* Enable 8-13-2 Min Code Length 8-13-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *PXH+* Configuration Range...
Page 269: Max Code Length
8. Symbology Settings 8-13-3 Max Code Length 8-13-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *IXJ+* Configuration Range Default Setting 1~3116 3116 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length”...
Page 270: Truncateending
8. Symbology Settings 8-13-5 TruncateEnding 8-13-5 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *O6G+* Configuration Range Default Setting 0~3116 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 271: Insertion1Dataposition
8. Symbology Settings 8-13-7 Insertion1DataPosition 8-13-7 Insertion1DataPosition To set up the position to insert data1 *J6K+* Configuration Range Default Setting 0~3116 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 272: Insertion2Dataposition
8. Symbology Settings 8-13-9 Insertion2DataPosition 8-13-9 Insertion2DataPosition To set up the position to insert data2 *N6O+* Configuration Range Default Setting 0~3116 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 273: Maxicode
8. Symbology Settings 8-14 MaxiCode 8-14 MaxiCode 8-14-1 Read 8-14-1 Read Whether the barcode can be scanned *LXM0* Disable *LXM1* Enable 8-14-2 Min Code Length 8-14-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *MXN+* Configuration Range...
Page 274: Max Code Length
8. Symbology Settings 8-14-3 Max Code Length 8-14-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *NXO+* Configuration Range Default Setting 1~150 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 275: Truncateending
8. Symbology Settings 8-14-5 TruncateEnding 8-14-5 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *K6U+* Configuration Range Default Setting 0~150 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 276: Insertion1Dataposition
8. Symbology Settings 8-14-7 Insertion1DataPosition 8-14-7 Insertion1DataPosition To set up the position to insert data1 *O6Y+* Configuration Range Default Setting 0~150 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 277: Insertion2Dataposition
8. Symbology Settings 8-14-9 Insertion2DataPosition 8-14-9 Insertion2DataPosition To set up the position to insert data2 *K72+* Configuration Range Default Setting 0~150 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 278: Read
8. Symbology Settings 8-15 Aztec 8-15 Aztec 8-15-1 Read 8-15-1 Read Whether the barcode can be scanned *OXP0* Disable *OXP1* Enable 8-15-2 Append 8-15-2 Append To set up whether able to scan multiple related barcodes, and decode them into a complete Aztec barcode Off: Disable this function On: Enable this function ;...
Page 279: Min Code Length
8. Symbology Settings 8-15-3 Min Code Length 8-15-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *PXQ+* Configuration Range Default Setting 1~3832 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 280: Truncateleading
8. Symbology Settings 8-15-5 TruncateLeading 8-15-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *K7K+* Configuration Range Default Setting 0~3832 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 281: Truncatezero
8. Symbology Settings 8-15-7 TruncateZero 8-15-7 TruncateZero Whether to omit 0 from the beginning of the barcode *O7O0* Disable *O7O1* Enable 8-15-8 Insertion1DataPosition 8-15-8 Insertion1DataPosition To set up the position to insert data1 *Q7Q+* Configuration Range Default Setting 0~3832 Procedure: (A) Scan “Enter”...
Page 282: Insertion1Data
8. Symbology Settings 8-15-9 Insertion1Data 8-15-9 Insertion1Data To set up data1 to be inserted *J7S+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 283: Insertion2Data
8. Symbology Settings 8-15-11 Insertion2Data 8-15-11 Insertion2Data To set up data2 to be inserted *N7W+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 284: Read
8. Symbology Settings 8-16 ChineseSensible(HanXinCode) 8-16 ChineseSensible(HanXinCode) 8-16-1 Read 8-16-1 Read Whether the barcode can be scanned *NXX0* Disable *NXX1* Enable 8-16-2 Min Code Length 8-16-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *OXY+* Configuration Range...
Page 285: Max Code Length
8. Symbology Settings 8-16-3 Max Code Length 8-16-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *IY0+* Configuration Range Default Setting 1~7833 7833 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length”...
Page 286: Truncateending
8. Symbology Settings 8-16-5 TruncateEnding 8-16-5 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *BV6+* Configuration Range Default Setting 0~7833 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 287: Insertion1Dataposition
8. Symbology Settings 8-16-7 Insertion1DataPosition 8-16-7 Insertion1DataPosition To set up the position to insert data1 *FVA+* Configuration Range Default Setting 0~7833 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 288: Insertion2Dataposition
8. Symbology Settings 8-16-9 Insertion2DataPosition 8-16-9 Insertion2DataPosition To set up the position to insert data2 *AVE+* Configuration Range Default Setting 0~7833 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 289: Read
8. Symbology Settings 8-17 Codabar (Nw7) 8-17 Codabar(Nw7) 8-17-1 Read 8-17-1 Read Whether the barcode can be scanned *KY20* Disable *KY21* Enable 8-17-2 Start/End Transmission 8-17-2 Start/End Transmission Whether to send the start code and end code of the barcode *LY30* Disable *LY31*...
Page 290: Chksum Digit
8. Symbology Settings 8-17-3 Chksum Digit 8-17-3 Chksum Digit To set up the regulation of check digit, and whether to send the check digit *MY40* Disable *MY41* Modulo 16 *MY42* Modulo 16,Transmit 8-17-4 Concatenation 8-17-4 Concatenation Codabar supports symbol concatenation. When you enable concatenation, the scanner looks for a Codabar symbol having a “D”...
Page 291: Min Code Length
8. Symbology Settings 8-17-5 Min Code Length 8-17-5 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *OY6+* Configuration Range Default Setting 2~60 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 292: Dblconfirm
8. Symbology Settings 8-17-7 DblConFirm 8-17-7 DblConFirm To decode the barcode multiple times. If the result of each decoding is the same, it means that the barcode decoding is successful *QY8+* Configuration Range Default Setting 0~10 Procedure: (A) Scan “Enter” barcode (B) Scan “DblConFirm”...
Page 293: Truncateleading
8. Symbology Settings 8-17-9 TruncateLeading 8-17-9 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *Q06+* Configuration Range Default Setting 0~60 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 294: Truncatezero
8. Symbology Settings 8-17-11 TruncateZero 8-17-11 TruncateZero Whether to omit 0 from the beginning of the barcode *L0A0* Disable *L0A1* Enable 8-17-12 Insertion1DataPosition 8-17-12 Insertion1DataPosition To set up the position to insert data1 *N0C+* Configuration Range Default Setting 0~60 Procedure: (A) Scan “Enter”...
Page 295: Insertion1Data
8. Symbology Settings 8-17-13 Insertion1Data 8-17-13 Insertion1Data To set up the data1 to be inserted *P0E+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 296: Insertion2Data
8. Symbology Settings 8-17-15 Insertion2Data 8-17-15 Insertion2Data To set up the data2 to be inserted *K0I+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 297: Read
8. Symbology Settings 8-18 Code39 8-18 Code39 8-18-1 Read 8-18-1 Read Whether the barcode can be scanned *DC00* Disable *DC01* Enable 8-18-2 Chksum Verification 8-18-2 Chksum Verification To set up the regulation of check digit, and whether to send the check digit *FC20* Disable *FC21*...
Page 298: Start/End Transmission
8. Symbology Settings 8-18-3 Start/End Transmission 8-18-3 Start/End Transmission Whether to indicate ”*” in the beginning and the end of the barcode *EC10* Disable *EC11* Enable 8-18-4 Type 8-18-4 Type To set up whether able to decode the Code39 of Full ASCII, to indicate lowercase and special symbologies *GC30* Standard...
Page 299: Min Code Length
8. Symbology Settings 8-18-5 Min Code Length 8-18-5 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *HC4+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 300: Dblconfirm
8. Symbology Settings 8-18-7 DblConFirm 8-18-7 DblConFirm To decode the barcode multiple times. If the result of each decoding is the same, it means that the barcode decoding is successful *BC7+* Configuration Range Default Setting 0~10 Procedure: (A) Scan “Enter” barcode (B) Scan “DblConFirm”...
Page 301: Truncateleading
8. Symbology Settings 8-18-9 TruncateLeading 8-18-9 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *M0K+* *GSE+* Code39 Code32 Type Configuration Range Default Setting Code39 0~48 Code32 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading”...
Page 302: Truncatezero
8. Symbology Settings 8-18-11 TruncateZero 8-18-11 TruncateZero Whether to omit 0 from the beginning of the barcode Code39 Code32 *Q0O0* *BSI0* Disable Disable *Q0O1* *BSI1* Enable Enable 8-18-12 Insertion1DataPosition 8-18-12 Insertion1DataPosition To set up the position to insert data1 *J0Q+* *DSK+* Code39 Code32...
Page 303: Insertion1Data
8. Symbology Settings 8-18-13 Insertion1Data 8-18-13 Insertion1Data To set up data1 to be inserted *L0S+* *FSM+* Code39 Code32 Type Configuration Length Default Setting Code39 NULL Code32 NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 304: Insertion2Data
8. Symbology Settings 8-18-15 Insertion2Data 8-18-15 Insertion2Data To set up data2 to be inserted *P0W+* *ASQ+* Code39 Code32 Type Configuration Length Default Setting Code39 NULL Code32 NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 305: Read
8. Symbology Settings 8-19 Interleaved2of5 8-19 Interleaved2of5 6-19-1 Read 6-19-1 Read Whether the barcode can be scanned *OYO0* Disable *OYO1* Enable 6-19-2 Chksum Digit 6-19-2 Chksum Digit To set up the regulation of check digit, and whether to send the check digit *PYP0* Disable *PYP1*...
Page 306: Min Code Length
8. Symbology Settings 8-19-3 Min Code Length 8-19-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *QYQ+* Configuration Range Default Setting 2~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 307: Dblconfirm
8. Symbology Settings 8-19-5 DblConFirm 8-19-5 DblConFirm To decode the barcode multiple times. If the result of each decoding is the same, it means that the barcode decoding is successful *JYS+* Configuration Range Default Setting 0~10 Procedure: (A) Scan “Enter” barcode (B) Scan “DblConFirm”...
Page 308: Truncateending
8. Symbology Settings 8-19-7 TruncateEnding 8-19-7 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *M1S+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 309: Insertion1Dataposition
8. Symbology Settings 8-19-9 Insertion1DataPosition 8-19-9 Insertion1DataPosition To set up the position to insert data1 *Q1W+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 310: Insertion2Dataposition
8. Symbology Settings 8-19-11 Insertion2DataPosition 8-19-11 Insertion2DataPosition To set up the position to insert data2 *M20+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 311: Read
8. Symbology Settings 8-20 Nec2of5 8-20 Nec2of5 6-20-1 Read 6-20-1 Read Whether the barcode can be scanned *KYT0* Disable *KYT1* Enable 6-20-2 Chksum Digit 6-20-2 Chksum Digit To set up the regulation of check digit, and whether to send the check digit *LYU0* Disable *LYU1*...
Page 312: Min Code Length
8. Symbology Settings 8-20-3 Min Code Length 8-20-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *MYV+* Configuration Range Default Setting 2~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 313: Truncateleading
8. Symbology Settings 8-20-5 TruncateLeading 8-20-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *AZS+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 314: Truncatezero
8. Symbology Settings 8-20-7 TruncateZero 8-20-7 TruncateZero Whether to omit 0 from the beginning of the barcode *EZW0* Disable *EZW1* Enable 8-20-8 Insertion1DataPosition 8-20-8 Insertion1DataPosition To set up the position to insert data1 *GZY+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter”...
Page 315: Insertion1Data
8. Symbology Settings 8-20-9 Insertion1Data 8-20-9 Insertion1Data To set up data1 to be inserted *K00+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 316: Insertion2Data
8. Symbology Settings 8-20-11 Insertion2Data 8-20-11 Insertion2Data To set up data2 to be inserted *O04+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 317: Read
8. Symbology Settings 8-21 Code93 8-21 Code93 8-21-1 Read 8-21-1 Read Whether the barcode can be scanned *OYX0* Disable *OYX1* Enable 8-21-2 Append 8-21-2 Append To set up whether able to scan multiple related barcodes, and decode them in to a complete Code93 barcode *KZ10* Disable...
Page 318: Min Code Length
8. Symbology Settings 8-21-3 Min Code Length 8-21-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *PYY+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 319: Truncateleading
8. Symbology Settings 8-21-5 TruncateLeading 8-21-5 TruncateLeading To set up the number of digits to be omitted from the beginning the barcode *O3A+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 320: Truncatezero
8. Symbology Settings 8-21-7 TruncateZero 8-21-7 TruncateZero Whether to omit 0 from the beginning of the barcode *J3E0* Disable *J3E1* Enable 8-21-8 Insertion1DataPosition 8-21-8 Insertion1DataPosition To set up the position to insert data1 *L3G+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter”...
Page 321: Insertion1Data
8. Symbology Settings 8-21-9 Insertion1Data 8-21-9 Insertion1Data To set up data1 to be insert *N3I+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 322: Insertion2Data
8. Symbology Settings 8-21-11 Insertion2Data 8-21-11 Insertion2Data To set up data2 to be inserted *I3M+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 323: Read
8. Symbology Settings 8-22 Straight2of5 (Industrial2of5) 8-22 Straight2of5 (Industrial2of5) 8-22-1 Read 8-22-1 Read Whether the barcode can be scanned Straight2of5 Straight2of5IATA *LZ20* *OZ50* Disable Disable *LZ21* *OZ51* Enable Enable 8-22-2 Min Code Length 8-22-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *MZ3+* *PZ6+*...
Page 324: Max Code Length
8. Symbology Settings 8-22-3 Max Code Length 8-22-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *NZ4+* *QZ7+* Straight2of5 Straight2of5IATA Type Configuration Range Default Setting Straight2of5 1~48 Straight2of5IATA 1~48 Procedure: (A) Scan “Enter”...
Page 325: Truncateleading
8. Symbology Settings 8-22-5 TruncateLeading 8-22-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *Q24+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 326: Truncatezero
8. Symbology Settings 8-22-7 TruncateZero 8-22-7 TruncateZero Whether to omit 0 from the beginning of the barcode *L280* Disable *L281* Enable 8-22-8 Insertion1DataPosition 8-22-8 Insertion1DataPosition To set up the position to insert data1 *N2A+* Configuration Range Default Setting 0~48 Procedure: (A) Scan “Enter”...
Page 327: Insertion1Data
8. Symbology Settings 8-22-9 Insertion1Data 8-22-9 Insertion1Data To set up data1 to be inserted *P2C+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 328: Insertion2Data
8. Symbology Settings 8-22-11 Insertion2Data Insertion2Data 8-22-11 To set up data2 to be inserted *K2G+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 329: Read
8. Symbology Settings 8-23 Matrix2of5 8-23 Matrix2of5 8-23-1 Read 8-23-1 Read Whether the barcode can be scanned *JZ90* Disable *JZ91* Enable 8-23-2 Min Code Length 8-23-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *KZA+* Configuration Range...
Page 330: Max Code Length
8. Symbology Settings 8-23-3 Max Code Length 8-23-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *LZB+* Configuration Range Default Setting 1~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 331: Truncateending
8. Symbology Settings 8-23-5 TruncateEnding 8-23-5 TruncateEnding To set up the number of digit to be omitted from the end of the barcode *O4I+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 332: Insertion1Dataposition
8. Symbology Settings 8-23-7 Insertion1DataPosition 8-23-7 Insertion1DataPosition To set up the position to insert data1 *J4M+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 333: Insertion2Dataposition
8. Symbology Settings 8-23-9 Insertion2DataPosition 8-23-9 Insertion2DataPosition To set up the position to insert data2 *N4Q+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 334: Code11
8. Symbology Settings 8-24 Code11 8-24 Code11 8-24-1 Read 8-24-1 Read Whether the barcode can be scanned *MZC0* Disable *MZC1* Enable 8-24-2 Chksum Digit 8-24-2 Chksum Digit To choose how many digits to use for the check digit. *PZF0* 1Checkdigit *PZF1* 2Checkdigit Enter...
Page 335: Min Code Length
8. Symbology Settings 8-24-3 Min Code Length 8-24-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *NZD+* Configuration Range Default Setting 1~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 336: Truncateleading
8. Symbology Settings 8-24-5 TruncateLeading 8-24-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *I2W+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 337: Truncatezero
8. Symbology Settings 8-24-7 TruncateZero 8-24-7 TruncateZero Whether to omit 0 from the beginning of the barcode *N300* Disable *N301* Enable 8-24-8 Insertion1DataPosition 8-24-8 Insertion1DataPosition To set up the position to insert data1 *P32+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter”...
Page 338: Insertion1Data
8. Symbology Settings 8-24-9 Insertion1Data 8-24-9 Insertion1Data To set up data1 to be inserted *I34+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 339: Insertion2Data
8. Symbology Settings 8-24-11 Insertion2Data 8-24-11 Insertion2Data To set up data2 to be inserted *M38+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 340: Code-128
8. Symbology Settings 8-25 Code128 8-25 Code128 8-25-1 Read 8-25-1 Read Whether the barcode can be scanned *QZG0* Disable *QZG1* Enable 8-25-2 Append 8-25-2 Append To set up whether able to scan multiple related barcodes, and decode them into a complete Code128 barcode *MZL0* Disable...
Page 341: Isbtconcatenation
8. Symbology Settings 8-25-3 ISBTConcatenation 8-25-3 ISBTConcatenation Whether able to read ISBT128 barcode *NZM0* Disable *NZM1* Enable 8-25-4 Min Code Length 8-25-4 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *IZH+* Configuration Range...
Page 342: Max Code Length
8. Symbology Settings 8-25-5 Max Code Length 8-25-5 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *JZI+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 343: Truncateending
8. Symbology Settings 8-25-7 TruncateEnding 8-25-7 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *M3Q+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 344: Insertion1Dataposition
8. Symbology Settings 8-25-9 Insertion1DataPosition 8-25-9 Insertion1DataPosition To set up the position to insert data1 *Q3U+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 345: Insertion2Dataposition
8. Symbology Settings 8-25-11 Insertion2DataPosition 8-25-11 Insertion2DataPosition To set up the position to insert data2 *L3Y+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 346: Gs1-128
8. Symbology Settings 8-26 Gs1-128 8-26 Gs1-128 8-26-1 Read 8-26-1 Read Whether the barcode can be scanned *OZN0* Disable *OZN1* Enable 8-26-2 Min Code Length 8-26-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *PZO+* Configuration Range...
Page 347: Max Code Length
8. Symbology Settings 8-26-3 Max Code Length 8-26-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *QZP+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 348: Truncateending
8. Symbology Settings 8-26-5 TruncateEnding 8-26-5 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *GVK+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 349: Insertion1Dataposition
8. Symbology Settings 8-26-7 Insertion1DataPosition 8-26-7 Insertion1DataPosition To set up the position to insert data1 *BVO+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 350: Insertion2Dataposition
8. Symbology Settings 8-26-9 Insertion2DataPosition 8-26-9 Insertion2DataPosition To set up the position to insert data2 *FVS+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 351: Dpostal
8. Symbology Settings 8-27 2D Postal 8-27 2D Postal 8-27-1 Read 8-27-1 Read To set up the 2D Postal barcode can be scanned *IZQ0* *IZQ1* *IZQ2* AustralianPost InfoMail *IZQ3* *IZQ4* *IZQ5* JapanesePost KIXPost(NetherlandsPost) PlanetCode(PLA) *IZQ6* *IZQ7* *IZQ8* Postnet(POS) BritishPost InfoMail/BritishPost *IZQ9* *IZQA* *IZQB*...
Page 352: Postnet Tx Checkdigit
8. Symbology Settings *IZQU* CanadianPost 8-27-2 Postnet Tx CheckDigit 8-27-2 Postnet Tx CheckDigit Whether to send the check digit of Postnet barcode *JZR0* Disable *JZR1* Enable 8-27-3 Planet Tx CheckDigit 8-27-3 Planet Tx CheckDigit Whether to send the check digit of Planet *KZS0* Disable *KZS1*...
Page 353: Australianpostinterpretation
8. Symbology Settings 8-27-4 AustralianPostInterpretation 8-27-4 AustralianPostInterpretation This option controls what interpretation is applied to customer fields in Australian 4-State symbols BarOutput: Bar Output lists the bar patterns in “0123” format NumericN: Numeric N Table causes that field to be interpreted as numeric data using the N Table AlphanumericC: Alphanumeric C Table causes the field to be interpreted as alphanumeric data using the C Table.
Page 354: Truncateleading
8. Symbology Settings 8-27-5 TruncateLeading 8-27-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *9T6+* *BS0+* *AVW+* AustralianPost InfoMail JapanesePost *CWO+* *AXU+* *ETK+* PlanetCode Postnet BritishPost *EXG+* *9X2+* *ATY+* Postal4i IntelligentMail CanadianPost *GWA+* NetherlandsPost...
Page 355: Truncateending
8. Symbology Settings 8-27-6 TruncateEnding 8-27-6 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *BT8+* *DS2+* *CVY+* AustralianPost InfoMail JapanesePost *EWQ+* *CXW+* *GTM+* PlanetCode Postnet BritishPost *GXI+* *BX4+* *DU0+* Postal4i IntelligentMail CanadianPost *9WC+* NetherlandsPost...
Page 356: Truncatezero
8. Symbology Settings 8-27-7 TruncateZero 8-27-7 TruncateZero Whether to omit 0 from the beginning of the barcode AustralianPost InfoMail JapanesePost *DTA0* *FS40* *FW00* Disable Disable Disable *DTA1* *FS41* *FW01* Enable Enable Enable PlanetCode Postnet BritishPost *GWS0* *EXY0* *9TO0* Disable Disable Disable *GWS1* *EXY1*...
Page 357: Insertion1Dataposition
8. Symbology Settings 8-27-8 Insertion1DataPosition 8-27-8 Insertion1DataPosition To set up the position to insert data1 *FTC+* *HS6+* *HW2+* AustralianPost InfoMail JapanesePost *9WU+* *HY0+* *BTQ+* PlanetCode Postnet BritishPost *BXM+* *FX8+* *HU4+* Postal4i IntelligentMail CanadianPost *DWG+* NetherlandsPost Type Configuration Range Default Setting AustralianPost 0~80 InfoMail...
Page 358: Insertion1Data
8. Symbology Settings 8-27-9 Insertion1Data 8-27-9 Insertion1Data To set up data1 to be inserted *HTE+* *AS8+* *AW4+* AustralianPost InfoMail JapanesePost *BWW+* *AY2+* *DTS+* PlanetCode Postnet BritishPost *DXO+* *HXA+* *AU6+* Postal4i IntelligentMail CanadianPost *FWI+* NetherlandsPost Type Configuration Length Default Setting AustralianPost NULL InfoMail NULL...
Page 359: Insertion2Dataposition
8. Symbology Settings Insertion2DataPosition 8-27-10 Insertion2DataPosition 8-27-10 To set up the position to insert data2 *ATG+* *CSA+* *CW6+* AustralianPost InfoMail JapanesePost *DWY+* *CY4+* *FTU+* PlanetCode Postnet BritishPost *FXQ+* *AXC+* *CU8+* Postal4i IntelligentMail CanadianPost *HWK+* NetherlandsPost Type Configuration Range Default Setting AustralianPost 0~80 InfoMail...
Page 360: Insertion2Data
8. Symbology Settings 8-27-11 Insertion2Data Insertion2Data 8-27-11 To set up data2 to be inserted *CTI+* *ESC+* *EW8+* AustralianPost InfoMail JapanesePost *GX0+* *EY6+* *HTW+* PlanetCode Postnet BritishPost *HXS+* *CXE+* *EUA+* Postal4i IntelligentMail CanadianPost *AWM+* NetherlandsPost Type Configuration Length Default Setting AustralianPost NULL InfoMail NULL...
Page 361: Chinapost(Hongkong2Of5)
8. Symbology Settings 8-28 ChinaPost (HongKong2of5) 8-28 ChinaPost (HongKong2of5) 8-28-1 Read 8-28-1 Read Whether the barcode can be scanned *PZX0* Disable *PZX1* Enable 8-28-2 Min Code Length 8-28-2 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *QZY+* Configuration Range...
Page 362: Max Code Length
8. Symbology Settings 8-28-3 Max Code Length 8-28-3 Max Code Length To set up the maximum length of the barcode, longer than this length barcode cannot be scanned *IZZ+* Configuration Range Default Setting 2~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Max Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 363: Truncateending
8. Symbology Settings 8-28-5 TruncateEnding 8-28-5 TruncateEnding To set up the number of digits to be omitted from the end of the barcode *9YA+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateEnding” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 364: Insertion1Dataposition
8. Symbology Settings 8-28-7 Insertion1DataPosition 8-28-7 Insertion1DataPosition To set up the position to insert data1 *DYE+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 365: Insertion2Dataposition
8. Symbology Settings 8-28-9 Insertion2DataPosition 8-28-9 Insertion2DataPosition To set up the position to insert data2 *HYI+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2DataPosition” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 366: Koreapost
8. Symbology Settings 8-29 KoreaPost 8-29 KoreaPost 8-29-1 Read 8-29-1 Read Whether the barcode can be scanned *U000* Disable *U001* Enable 8-29-2 Tx Checkdigit 8-29-2 Tx Checkdigit Whether to send check digit *X030* Disable *X031* Enable Enter */$%ENTR* *ZEND*...
Page 367: Min Code Length
8. Symbology Settings 8-29-3 Min Code Length 8-29-3 Min Code Length To set up the minimum length of the barcode, less than this length barcode cannot be scanned *V01+* Configuration Range Default Setting 2~80 Procedure: (A) Scan “Enter” barcode (B) Scan “Min Code Length” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 368: Truncateleading
8. Symbology Settings 8-29-5 TruncateLeading 8-29-5 TruncateLeading To set up the number of digits to be omitted from the beginning of the barcode *CSS+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter” barcode (B) Scan “TruncateLeading” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“...
Page 369: Truncatezero
8. Symbology Settings 8-29-7 TruncateZero 8-29-7 TruncateZero Whether to omit 0 from the beginning of the barcode *GSW0* Disable *GSW1* Enable 8-29-8 Insertion1DataPosition 8-29-8 Insertion1DataPosition To set up the position to insert data1 *9SY+* Configuration Range Default Setting 0~80 Procedure: (A) Scan “Enter”...
Page 370: Insertion1Data
8. Symbology Settings 8-29-9 Insertion1Data 8-29-9 Insertion1Data To set up data1 to be inserted *CT0+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion1Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 371: Insertion2Data
8. Symbology Settings 8-29-11 Insertion2Data 8-29-11 Insertion2Data To set up data2 to be inserted *GT4+* Configuration Length Default Setting NULL Procedure: (A) Scan “Enter” barcode (B) Scan “Insertion2Data” barcode (C) Scan parameters from Hexadecimal / Decimal table (D) Scan “OK“ barcode (E) Scan “End”...
Page 372: Appid
8. Symbology Settings 8-30 AppID 8-30 AppID 8-30-1 AppIDSw 8-30-1 AppIDSw Whether AppID will be delimit by Conchar in GS1 code *BCG0* Disable *BCG1* Enable 8-30-2 AppIDConChar 8-30-2 AppIDConChar The Conchar will be assigned to delimit AppID *CCH+* Configuration Length Default Setting Procedure: (A) Scan “Enter”...
Page 373: Barcodeid
8. Symbology Settings 8-31 BarcodeID 8-31 BarcodeID 8-31-1 BarcodeID Default 8-31-1 BarcodeID Default Type Configuration Length Default Setting UPCA UPCE EAN13 EAN8 Gs1DataBar Gs1DataBarLimited Gs1DataBarExpanded CodablockA CodablockF Pdf417 MicroPdf417 Tlc39 QRCode DataMatrix MaxiCode AztecCode ChineseSensible(HanXinCode) Codabar Code39 Code32 < Interleaved2of5 Nec2of5 Code93 Straight2of5...
Page 374 8. Symbology Settings Type Configuration Length Default Setting InfoMail JapanesePost KIXPost(NetherlandsPost) PlanetCode Postnet BritishPost Postal4i IntelligentMail CanadianPost ChinaPost2of5 KoreaPost Enter */$%ENTR* *ZEND*...
Page 375: Barcodeid Setting
8. Symbology Settings 8-31-2 BarcodeID Setting 8-31-2 BarcodeID Setting This page is for setting Barcode ID. When”Tx CodeId Tx CodeId”is set as ”Enable Enable”, the Tx CodeId Tx CodeId Enable Enable barcode ID will be indicated according to the setting position by ” Code Position Code Position”...
Page 376 8. Symbology Settings *G8G+* *A90+* *C92+* InfoMail JapanesePost KIXPost(NetherlandsPost) *E94+* *B9A+* *F8O+* PlanetCode Postnet BritishPost *998+* *G96+* *H8Q+* Postal4i IntelligentMail CanadianPost *D9C+* *B8K+* ChinaPost2of5 KoreaPost Enter */$%ENTR* *ZEND*...
Page 377: Appendix:hexadecimal / Decimal Table
Appendix: Hexadecimal / Decimal table Appendix: Hexadecimal / Decimal Table Hexadecimal / Decimal TABLE Hexadecimal / Decimal TABLE *%00* *%09* *%01* *%0A* *%02* *%0B* *%03* *%0C* *%04* *%0D* *%05* *%0E* *%06* *%0F* *%07* *%OK* *%08* Enter */$%ENTR* *ZEND*...
Page 378: Appendix:ascii Code Table
Appendix: ASCII code table Appendix: ASCII Code Table ASCII Code Table 0 (*) 1 (*) Null Down “ Left Right PgUp PgDn & ‘ Home < Enter F12 Insert Ctrl+ > Delete Alt+ o DEL (*) For keyboard wedge only. Enter */$%ENTR* *ZEND*...
Page 379: Appendix:a-303 Dongle Layout Setting
Appendix:A-303 Dongle layout Appendix: A-303 Dongle Layout Setting A-303 Dongle Layout Setting */$%PROG* Enter */$%1DC0* */$%1DC1* */$%1DC2* */$%1DC3* Layout */$%1DC4* */$%1DC5* */$%1DC6* */$%1DC7* */$%ZEND* Note: To make this setting, the product must be connected with A-303 Dongle, then scan "Enter", "Layout", "End" Enter */$%ENTR* *ZEND*...
