- Page 1 Specific Information Manual 200 Sundeck Manual Part Number: MRP 1902268...
-
Page 3: Table Of Contents
15. Water Sports Tower ..........10 16. Electrical Schematic ..........10 Information in this publication is based upon the latest product specifications available at printing. Sea Ray ® Boats, Inc. reserves the right to make changes at any time, without notice, in the colors, equipment, specifications, materials and prices of all models, or to discontinue models. - Page 4 THIS PAGE INTENTIONALLY LEFT BLANK 200 Sundeck Manual Part Number: MRP 1902268...
-
Page 5: Load Capacity
PERSONS OR LBS. 1200 POUNDS, PERSONS, GEAR THIS BOAT COMPLIES WITH U.S. COAST GUARD SAFETY STANDARDS IN EFFECT ON THE DATE OF CERTIFICATION SEA RAY BOATS, INC. MANUFACTURER: DANGER VONORE, TN MODEL: 200SD Rotating propellers can injure or kill you. -
Page 6: Safety Label Locations
200 S UNDECK WNERS ANUAL 3. S AFETY ABEL OCATIONS AFETY ABEL OCATIONS . 2.1) Manual Part Number: MRP 1902268 200 Sundeck... - Page 7 “Garbage” does not MATERIALS THAT FLOAT washbasin, and does not include fresh fish or fish include drainage from OUTSIDE 25 MILES parts, dishwasher and toilets, urinals, hospitals gray water. PLASTICS and cargo spaces. 200 Sundeck Manual Part Number: MRP 1902268...
-
Page 8: Basic Boat Dimensions And Clearances
*MINIMUM WATER DEPTH TO PREVENT RUNNING AGROUND (Stern Drive Up)....20” 50.8cm Dry Weight ........3,550 lbs. 1,610.3 kg. Fuel Capacity ......... 40 gal. 151.4 liters Useable Fuel ......... 38 gal. 143.8 liters Dead Rise ........20 Manual Part Number: MRP 1902268 200 Sundeck... -
Page 9: Function And Location Of Through-Hull Cutouts
200 S UNDECK WNERS ANUAL 5. F UNCTION AND OCATION OF HROUGH UTOUTS HROUGH UTOUTS .5.1) BILGE PUMP OUTLET ARBOARD RAIN . 5.3) ILGE HROUGH UTOUTS . 5.2) DEPTH SOUNDER TRANSDUCER 200 Sundeck Manual Part Number: MRP 1902268... -
Page 10: Helm, Gauge & Switch Layout
AND VERIFY BLOWER OPERATION. RUN BLOWER WHEN VESSEL LIGHT OFF - UNIT DISCHARGED IS OPERATING BELOW CRUISING SPEED. IF SYSTEM DISCHARGES, SHUTDOWN ENGINE, BLOWER AND ELECTRICAL SYSTEM PORT SWITCH PANEL STARBOARD SWITCH PANEL Manual Part Number: MRP 1902268 200 Sundeck... -
Page 11: Deck Layout
KNEEBOARD STORAGE BELOW STERN LIGHT HOLDER AFT PORT AFT STARBOARD CLEAT CLEAT FUEL FILL ENGINE BOX (UNDER SEAT) TRANSOM STERN DRIVE TILT CONTROL FOLDING SWIM LADDER TRANSOM STEREO REMOTE SKI TOW SWIM PLATFORM 200 Sundeck Manual Part Number: MRP 1902268... -
Page 12: Cleats
(VISIBLE 2- NAUTICAL MILES) 11. F YSTEM The 200 Sundeck standard gasoline fuel system consists of a 40 gallon (151 liter) fuel tank, fuel tank vent, anti-siphon valve, engine fuel supply line and fuel fill. The fuel tank vent serves as a pressure/vacuum release and safety overflow. -
Page 13: Entertainment System
The standard canvas set for the 200SD consists of a bimini top with boot. The following canvas options are available. Bimini Aft Curtain Side Curtains Canvas Storage Bag Front Curtains Cockpit Cover Tonneau Cover 200 Sundeck Manual Part Number: MRP 1902268... -
Page 14: Water Sports Tower
Instead, WARNING we recommend that you take your boat to your authorized Sea Ray dealer for service. Sea Ray ® ® DO NOT USE WATER SPORTS TOWER FOR TOWING ANOTHER BOAT OR BEING TOWED. TOWER COULD reserves the right to change or update the electrical COLLAPSE AND CAUSE INJURY. - Page 21 Dimensions ..............4 Through-Hull Cutouts ..........5 Trailer Trim Switch ............9 Electrical Schematics ..........10 Water Sports Tower ........... 10 Fuel System ..............8 Gauge Layout .............. 6 Helm Layout..............6 Index i 200 Sundeck Manual Part Number: MRP 1902268...
- Page 22 THIS PAGE LEFT INTENTIONALLY BLANK Manual Part Number: MRP 1902268...
