USER'S INFORMATION MANUAL
WARNING:
If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
-
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
-
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
81416892R1 - X/15
SERIES 8H / 8HE
Gas - Fired Boiler
AVERTISSEMENT.
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
-
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflam-mables
dans le voisinage de cet appareil ou de tout
autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
•
Ne pas tenter d'allumer d'appareils.
•
Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones dans le
bâtiment où vous vous trouvez.
•
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
•
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
-
L'installation et I'entretien doivent être
assuréx par un installateur ou un service
d'entretien qualifié ou par le fournisseur de
gaz.
BOILER NOT FOR INSTALLATION ON COMBUSTIBLE
FLOORS UNLESS FLOOR SHIELD OR NATIONAL BUILDING
CODE APPROVED MATERIALS ARE INSTALLED BETWEEN
BOILER AND FLOOR.
Commercial Boilers
www.burnhamcommercial.com
Assurez-vous de bien
Advertisement
Table of Contents
Related Manuals for Burnham 8H Series
Summary of Contents for Burnham 8H Series
- Page 1 USER'S INFORMATION MANUAL SERIES 8H / 8HE Gas - Fired Boiler AVERTISSEMENT. Assurez-vous de bien WARNING: If the information in this suivre les instructions données dans cette manual is not followed exactly, a fire or notice pour réduire au minimum le risque explosion may result causing property d'incendie ou d'explosion ou pour éviter damage, personal injury or loss of life.
