X8000 USER MANUAL

Advertisement

loading

Related Manuals for Carcam X8000

Summary of Contents for Carcam X8000

  • Page 1 X8000 USER MANUAL...
  • Page 2 Thanks for choosing our car data recorder! Except general function of the car data recorder, following new features of the equipment have been updated: （1） Double-lens has been built in so as to take two images in both front and back directions respectively at the same time; （2）GPS module has been added for completely recording travelling track.
  • Page 3 （3）The built in G-Sensor is able to record gravity induction information and make judgment according to offset in up and down directions, left and right directions and front and back directions of the automobile. If the offset reach specified value, it will think that the automobile is running abnormally and it will automatically lock current video for protection.
  • Page 4 In order to develop the maximum efficiency of the car data recorder, please carefully read this operation manual (please understand us if the updated design and specification of the equipment and accessories couldn’t reach you). Catalogue Product structure ………………… Start up car data recorder …………………...
  • Page 5 Setup the menu ………………… Video ………………… Use hotkey during for taking video ………………… Instruction for reading video and AP software ………………… Read and play video file ………………… Save video file ………………… Delete file ………………… Repair file ………………… GPS positioning and application …………………...
  • Page 6 3. Reset 4. Down 5. Up 6. Menu 7. Mode。 8. Emergency lock 9. Switch display of lens 10. Microphone 11. GPS indicator。 12. Work indicator 13. TF card holder 14. DC interface...
  • Page 7 15. GPS interface 16. Support of automobile bracket 17. Loudspeaker 18. Lens 19. LCD display screen Start up car data recorder Charge battery Charge power by vehicle power delivered along with equipment When charge power, the green indicator will be on; when power charge is completed, the indicator will be off.
  • Page 8 Prepare memory card（TF） TF card requirement: capacity of TF card of the equipment is required to be more than 4GB and speed is required to be above CLASS6. As independent file system is adopted for this equipment, when initially use the memory card, it will notify you to format it so as to build individual file system.
  • Page 9 Adjust position of lens Front lens/rear lens of the equipment can rotate 180°and the user can rotate it to a suitable angle according to fixed position so as to gain better shooting effect. Turn on/off 1. Manually turn on: Press the power button once, the red start-up indicator will be switched on and it will start to take video following a tick sound.

  • Page 10: Basic Operation

    Reset the equipment When the machine behaves abnormal due to improper operation, press reset button and start up again, it will work normal. Basic operation Switch work mode There are two kinds of work mode for the equipment: Video and Playback. It can be switched by pressing MODE button.
  • Page 11 setting page. You can select the items required by pressing UP and DOWN buttons and press OK for confirming to enter into the submenu for relevant setting. Press MENUE again to quit. System setting： Item Submenu Video mode CH1&CH2/仅 CH1/仅 CH2 Time setting During set time, value can be increased or decreased by pressing UP and DOWN buttons.
  • Page 12 Alert tone On/Off Video On/Off Language English/ Simplified Chinese/ Traditional Chinese/Japanese/Russian/German Screen setting On/Off (After setting, it will automatically turn off the screen LCD within three minutes if no operation is done.) Sensitivity Low/Ordinary/ High/Turn off, (The function will adopt automatic video gravity sensor to start up automatic video-taking protection...
  • Page 13 Video After connect to car charger and the automobile is started up, the car data recorder will be started up 2 seconds later in order to prevent the instant pulse current from damaging the equipment when automobile starts up. The car data recorder will automatically take consecutive video after start-up.
  • Page 14 particular emergency lock button which can be pressed for locking and protecting current record, when emergency occurs. The video taking after or before 60S after it is started will be protected and it couldn’t be lost. Instruction for reading video and AP software The equipment doesn’t support reading by USB directly.
  • Page 15 When open TF card on , you can’t find any other video files except software J PLAYER . User should take use of this software to read video or complete relevant applications. Read and play video file When click button, file menu for opening selection will appear.
  • Page 16 Route: Import AP for all video files saved under specified PC folder. Pass word: If TF card is encrypted, you can only read content after input pass word. After above route has been selected, click “COPY” to return to AP for playing the file Click activex to control play status: click from left...

  • Page 17: Delete File

    Save whole video file: Just mark the square before the video and then click button to save it in the specified space. Save partial video file: Each video file of the equipment sill make small part in each three minutes and save specific parts, so as to reduce file size. Stop cursor on the video file that requires to be saved and don’t mark before and then click button to save it.
  • Page 18 . Options “OK/CANCEL” will appear. If you select “OK”, the selected video file will be deleted. Repair file： During video-taking period, the current file would be damaged due to card problem or sudden power off etc. At the meanwhile, you can click button to repair it.
  • Page 19 should be required for this application: GPS has been successfully positioned during take the video and current PC is connected with internet. After GPS is successfully positioned, there will be notice bar showing longitude, latitude and speed above AP And then click button to open or close map.
  • Page 20 the options in the top right corner. If drag button to the map, you can shoot the actual street scenery (This function requires GOOGLE support and please contact GOOGLE service for concrete areas and countries). GOOGLE earth KML applications Click button to download the data positioned by GPS and save as *.KMLfile.
  • Page 21 Pass word setting: User can encrypt TF card for protection purpose. The video files saved on encrypted TF card can only be opened by pass word. Characteristics of product - Small volume, 180°rotation type and 140°A+ clear double lens with wide...
  • Page 22 angle, with perfect design: One for outside and one for inside, or one for front and one for side of the automobile. It is convenient for shooting video for each kind of occasions from multiple angles and high resolution - Built in 1/4 inch charge-coupled device with low noise intensity and high quality of image, which can capture HD picture in the darker occasion.
  • Page 23 - Encryption for video, which can protect user’s privacy by setting pass word. -Built in lithium battery, which can take video during power charge. -Support video output. Technical specification LCD screen size 2.3” HD screen Double 140°lens with wide angle and it can rotate 180°at Lens the same time.
