SPECIAL NOTICE
This product is now licensed to Anodyne Electronics Manufacturing (AEM) from Northern
Airborne Technology (NAT). AEM is responsible for all matters related to this product, including
sales, support and repair services.
Please note the transition to convert product manuals and supporting documentation is an
ongoing process and is being addressed on an 'as needed' basis.
All references to NAT product part numbers (and associated images) are equivalent to AEM
product part numbers.
Contact info:
Anodyne Electronics Manufacturing Corp.
#15-1925 Kirschner Road
Kelowna B.C. Canada
V1Y 4N7
Email:
support@aem-corp.com
Toll Free: 1-888-763-1088
Phone: 1-250-763-1088
Fax: 1-250-763-1089
www.aem-corp.com
Advertisement
Table of Contents
Related Manuals for AEM TS100 Series
Summary of Contents for AEM TS100 Series
- Page 1 SPECIAL NOTICE This product is now licensed to Anodyne Electronics Manufacturing (AEM) from Northern Airborne Technology (NAT). AEM is responsible for all matters related to this product, including sales, support and repair services. Please note the transition to convert product manuals and supporting documentation is an ongoing process and is being addressed on an ‘as needed’...
- Page 2 REV 5.00 April 16, 2012 Anodyne Electronics Manufacturing Corp. 15-1925 Kirschner Road Kelowna, BC, Canada. V1Y 4N7 Telephone (250) 763-1088 Facsimile (250) 763-1089 Website: www.aem-corp.com © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
-
Page 3: Important Information
COPYRIGHT STATEMENT © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved This publication is the property of AEM and is protected by Canadian copyright laws. No part of this document may be reproduced or transmitted in any form or by any means including electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AEM. - Page 4 The status of this installation and operation manual is controlled by issue shown on the title page. The status of each section is controlled by revision shown in the footer of each page. All revisions affecting sections of this manual have been incorporated into the latest issue. AEM MANUAL REVISIONS Section Revision Number...
-
Page 5: Table Of Contents
TS100/TS200 Series PA Speakers SM70 Installation and Operation Manual Table of Contents Section Title Page Description Introduction Purpose of Equipment Features Specifications 1.4.1 Performance Specifications 1.4.2 Physical Specifications System Configuration Installation Introduction Unpacking and Inspection 2.2.1 Warranty Installation Procedures 2.3.1 Warnings 2.3.2 Cautions... -
Page 6: Description
11 Ohms 110 dB (1 W, 1000 Hz signal) Note: These specifications are given for guidance only. If further information is required, please contact the Product Support department at AEM. 1.4.2 Physical Specifications See the appropriate Mechanical Installation drawings (922-0) in Section 2 of this manual for the PA Speaker physical specifications. -
Page 7: System Configuration
TS100/TS200 Series PA Speakers SM70 Installation and Operation Manual System Configuration The TS100/TS200 PA Speaker should be chosen to match the audio output power of the PA System amplifier. As a general rule, the system should have one speaker driver (minimum) for each 100 watts of audio power. -
Page 8: Installation
Verify that all items are present before proceeding and report any shortage immediately to your supplier. 2.2.1 Warranty Complete the warranty card information and send it to AEM when the installation is complete. If you fail to complete the warranty card, the warranty will be activated on date of shipment from AEM. Note: An appropriately rated facility, e.g. -
Page 9: Cautions
TS100/TS200 Series PA Speakers SM70 Installation and Operation Manual 2.3.2 Cautions Do not operate the equipment in a hangar or in confined areas. Do not operate the equipment with snow, water or other foreign matter in the loudspeaker horn. Do not clean the loudspeaker with compressed air. Be careful only to operate the siren for 3 cycles at a time and trill for a short 2 to 3 second burst. -
Page 10: Continued Airworthiness
TS100/TS200 Series PA Speakers SM70 Installation and Operation Manual Continued Airworthiness Maintenance of the TS100/TS200 Series speakers is ‘on condition’ only. Periodic maintenance of this product is not required. Installation Drawings DRAWING REV. DESCRIPTION TYPE TS100WR TS100WR\403-0 1.00 Lightweight Speaker Interconnect TS100WR\405-0 1.00... - Page 18 Confidential and Proprietary to NAT...
- Page 19 Confidential and Proprietary to NAT...
-
Page 24: Operation
TS100/TS200 Series PA Speakers SM70 Installation and Operation Manual Section 3.0 Operation Introduction Information in this section consists of the functional and operational procedures for the TS100 and TS200 Series PA Speakers. General The TS100 and TS200 Series PA Speakers are lightweight loudspeakers that can be used for both internal and external aircraft applications.
