ASM-TS150/TS300
TS150/TS300 Loud Speakers
INSTALLATION AND OPERATION MANUAL
REV 1.00 Nov 13, 2019
Anodyne Electronics Manufacturing Corp.
15-1925 Kirschner Road
Kelowna, BC, Canada.
V1Y 4N7
Telephone (250) 763-1088
Facsimile (250) 763-1089
Website: www.aem-corp.com
© 2019 Anodyne Electronics Manufacturing Corp. (AEM),
All Rights Reserved
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASM-TS150 and is the answer not in the manual?

Questions and answers

Related Manuals for AEM ASM-TS150

Summary of Contents for AEM ASM-TS150

  • Page 1 REV 1.00 Nov 13, 2019 Anodyne Electronics Manufacturing Corp. 15-1925 Kirschner Road Kelowna, BC, Canada. V1Y 4N7 Telephone (250) 763-1088 Facsimile (250) 763-1089 Website: www.aem-corp.com © 2019 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
  • Page 2 © 2019 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved This publication is the property of AEM and is protected by Canadian copyright laws. No part of this document may be reproduced or transmitted in any form or by any means including electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AEM.
  • Page 3 TS150/TS300 Loud Speakers ASM-TS150/TS300 Installation and Operation Manual Prepared By: Checked By: Approved By: Tony Pearson Tom Betzelt Duane Stewart Ron Briggs Product Support Designer Designer R&D Mgr Designate Manager Nov 25, 2019 Nov 13/19 Nov 15, 2019 Nov 18, 2019 The status of this installation and operation manual is controlled by issue shown on the title page.

  • Page 4: Table Of Contents

    TS150/TS300 Loud Speakers ASM-TS150/TS300 Installation and Operation Manual Table of Contents Section Title Page Description Introduction Purpose of Equipment Features Specifications 1.4.1 Performance Specifications 1.4.2 Physical Specifications System Configuration Installation Introduction Unpacking and Inspection 2.2.1 Warranty Installation Procedures 2.3.1 Warnings 2.3.2...

  • Page 5: Description

    106 ±3 dB 128 ±3 dB (@ 230 W) Note: These specifications reflect installation with the LSA400-001 Amplifier and are given for guidance only. If further information is required, please contact the Product Support department at AEM. 1.4.2 Physical Specifications See the appropriate Mechanical Installation drawings (922-0) in Section 2 of this manual for the Loud Speaker physical specifications.

  • Page 6: System Configuration

    TS150/TS300 Loud Speakers ASM-TS150/TS300 Installation and Operation Manual System Configuration The TS150 and TS300 Loud Speakers should be chosen to match the audio output power of the PA System amplifier. As a general rule, the system should have one speaker driver (minimum) for each 150 watts of audio power.

  • Page 7: Installation

    - Release certification (as applicable) Verify that all items are present before proceeding and report any shortage immediately to your supplier. 2.2.1 Warranty All Anodyne Electronics Manufacturing Corp. (AEM) products are warranted for 2 years. See the website www.aem-corp.com for complete details. Installation Procedures 2.3.1...

  • Page 8: Cabling And Wiring

    TS150/TS300 Loud Speakers ASM-TS150/TS300 Installation and Operation Manual 2.3.3 Cabling and Wiring All unshielded wire shall be selected in accordance with AC43.13-1B Change 1, Paragraphs 11-76 through 11-78. Wire types should be to MIL-W-22759 as specified in AC43.13-1B Change 1, Paragraphs 11-85, 11-86, and listed in Table 11-11.

  • Page 9: Post-Installation Checks

    TS150/TS300 Loud Speakers ASM-TS150/TS300 Installation and Operation Manual 2.3.5 Post-Installation Checks Ensure all connectors are tight and the mechanical installation is sound. When the PA system installation is complete, carry out a full performance test to ensure that all components of the system (including the speaker) are functioning correctly.
  • Page 10 May 20/15 Sept 14/15...
  • Page 11 May 20/15 Sept 14/15...
  • Page 12 May 20/15 Sept 14/15...
  • Page 13 SOUND WARNING LABELS 8.25 MAX 5.40 MAX VIEW A-A AEM LABEL METAL HORN LABEL 12.8 101.3 0.51 3.99 156.5 6.16 MAX 177.8 7.00 44.5 1.75 PRODUCT LABEL 2.60 40.6 101.6 1.60 4.00 NAME DATE UNLESS OTHERWISE SPECIFIED: 15-1925 KIRSCHNER RD.
  • Page 14 May 25/15 Nov 4/15...
  • Page 15 May 25/15 Nov 4/15...
  • Page 16 May 25/15 Nov 4/15...
  • Page 17 May 25/15 Nov 4/15...
  • Page 19 0.245±0.010 THRU 4.00 19.1 0.75 28.6 1.13 129.5 5.10 115.6 4.55 213.4 8.40 MAX 54.91±1.27 AEM LABEL 2.16±0.050 106.7 4.20 NAME DATE UNLESS OTHERWISE SPECIFIED: 15-1925 KIRSCHNER RD. KELOWNA BC V1Y 4N7 DIMENSIONS ARE IN INCHES [MM] 17-Jun-15 DRAWN 133.4...

  • Page 20: Operation

    TS150/TS300 Loud Speakers ASM-TS150/TS300 Installation and Operation Manual Section 3.0 Operation Introduction Information in this section consists of the functional and operational procedures for the TS150 and TS300 Loud Speakers. General The TS150 and TS300 Loud Speakers are lightweight loudspeakers that can be used for both internal and external aircraft applications.
