- Page 1 Programmable Fast Ethernet switch By ELC lighting bv...
- Page 2 The dmXLAN switch8LX is an intelligent Ethernet network switch for 10/100 MBit applications. It features 8 programable network ports, and programmable static multicast routing. The network switch is to be used when needed to connect more than 2 Ethernet devices. Each CAT5 port has a Neutrik Ethercon connector and can be connected to a different network device, with up to 100m (300ft) of cable in between.
- Page 3 Port programmability options Each of the 8 ports can be programmed to the following functions. The Programming of the ports can be done with the free dmXLAN software available at www.elclighting.com Disabled, the port will do nothing. Normal, the port will act as network connection and will pass thru all the data. Loop Loop ports are always programmed in pairs (port 1&2, 3&4, 5&6 or 7&8).
- Page 4 Filtered A very special feature of the switch8LX is the ability to analyze and filter network data. The port can be programmed with and artnet-filter and can block MAnet. Other multicast protocol filter options are available thru the static multicast routing. Examples of using port filtering.
