- Page 1 10-port DMX Ethernet node Users Manual Software version 1.0...
- Page 2 The front panel has a graphic LC-display, 3 keys and a jog-encoder with push function and 4 LEDs. Connections at the back The dmXLAN node8 has many connectivity options. Viewed at the back from left to right: RS-232 (top SUB-D 9pin)
- Page 3 Network 10/100 MBit Ethernet (on Neutrik Ethercon) The network connection uses a standard UTP network connection. USB 2.0 Full-speed The USB connection uses standard USB pinout. DMX port 1 - 8 Description Ground/Screen Data - Data + The DMX ports 1 to 8 are bidirectional(via programmable setup), have an internal terminator resistor and are RDM prepared.
-
Page 4: Operation
Operation The dmXLAN node8 can be programmed in 2 ways. Either through the front panel control or the dmXLAN control software. The dmXLAN control software has to be software version 3.0 or up. The software can be downloaded from www.elclighting.com Control through front panel. - Page 5 Setup menu Enter the setup menu from the main screen by pressing By using the encoder select the item you would like to adjust. Options: Edit DMX port 1 to 8 or DMX input 9 and 10 • Set the ID •...
- Page 6 dual HTP like single, but merge two DMX universes (primary and • secondary) in highest take precedence. dual LTP like dual LTP, like dual HTP but in latest takes • precedence (on a channel by channel basis) DMX port as input When a port is set up as a DMX input, it can be operation in the following modes.
- Page 7 Rename current configuration The name of the current configuration is presented in the Main display and in the dmXLAN software. The name is also used to indicate the configuration setting when it is stored in one of the 4 built in configurations. Use the encoder to change the current character, and press the encoder to select the next.
-
Page 8: General Information
Contact closure 4 has the highest priority. General Information CE – Product The dmXLAN node8 permits to the CE requirements set up by the European Community. This can be recognized by this label on the outside of the product. Technical Specifications:... - Page 9 Designed and manufactured in the Netherlands by: ELC lighting Support contact: support@elclighting.com Distributed by: Worldwide distribution: ANIMA lighting Ltd Route du Stand 20 CH-1897 Le Bouveret Switzerland T +41 79 210 4613 F+4186 079 210 4613 Email: sales@elclighting.com URL: www.elclighting.com...
