Audio Recording

Record/Playback
• 32 channels record/playback, simultaneous with video
• Simultaneous Dante, Analog, HDMI or SDI, AES/EBU, selectable per channel

Analog Audio

Inputs • 8 Balanced, line-level inputs on DB-25.
• Ch1,2 also on XLR
Outputs • 8 Balanced, line-level outputs on DB-25.
• Ch1,2 also on XLR
Frequency Response 10Hz-20kHz, +/- 0.5dB re 1kHz
THD + Noise
0.004% max (1kHz, 22Hz-22kHz)
Input and Output Topology
Fully electronically balanced, RF, ESD, short, and overload protected;
pin-2 hot, pin-3 cold
Line Output Clipping Level +18dBu
Front Panel Headphone 1/4" with gain control
Line Input Clipping Level
+26dBu
Input Impedance
10k

Digital Audio

Sample Rate / Bit Depth
• 44.1 kHz, 47.0952 kHz, 48 kHz, 48.048 kHz
• 24-bit
AES3
• 8 channels in and out via DB-25, 110 ohm, 2 V p-p.
• Accepts 32k, 44.1k, 48k, 96k, 192k sample rates. with SRC at input.
HDMI
• 8 channels embedded HDMI input
• 8 channels embedded HDMI output.
• Accepts 32k, 44.1k, 48k, 96k, 192k sample rates.
SDI
• 16 channels embedded SDI input
• 16 channels embedded SDI output
• 48k sample rate, with sample rate conversion
Dante • 32 channels
• 48kHz input and output
File Storage
Disk Format
PIX-CADDY 2 mounted drives
eSATAp conected drives
See Sound Devices' website for a list of approved media:
exFAT
Two, front-mounted Sound Devices approved 2.5-inch drives (or Sound Devices approved CF
cards with PIX-CADDY CF. Poly WAV recording only)
Two, rear panel eSATAp ports for drives meeting Sound Devices specifications, supplies 5V
@ 2A
www.sounddevices.com/approved
