PIX 260i User Guide
Specifications

SDI

Input
Output
SMPTE

HDMI

Input
Output

Video Input Resolutions / Rates

Input Resolutions / Rates

Video Codecs and Files

Codecs
Files

Up/Down/Cross Conversion

Up/Down/Cross Conversion

Frame Rate Conversion

Frame Rate Conversion

LCD

LCD
84
v. 2.10
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
• 4:4:4 or 4:2:2; 12, 10, or 8-bit
• 3G-SDI (levels A and B), HD-SDI, or SDI
• 4:4:4 or 4:2:2; 12, 10, or 8-bit
• 3G-SDI (level A), HD-SDI, or SDI
12M-1, 12M-2, 125M, 259M, 272M, 291M, 292, 296M, 299, 315M, 352M, 372, 424, 425
v1.4a, 4:4:4 or 4:2:2, RGB or YCbCr, 10 or 8-bit, HDCP-enabled
v1.3, 4:2:2 8-bit, RGB and YCbCr
• 1080p23.976/24/25/29.97/30
• 1080i50/59.94/60
• 1080PsF23.976/24/25/29.97/30
• 720p23.976/24/25/29.97/30 (SDI Only)
• Apple ProRes 4444, 330 Mb/s, 12-bit
• Apple ProRes 36, 100, 145, 220 Mb/s, 8 and 10-bit
• Avid DNxHD 36, 100, 145, 220 Mb/s, 8 and 10-bit
QuickTime wrapper (.MOV), Broadcast Wave (.WAV) Audio Only
• From input: 480i, 576i, 720p, 720PSF, 1080i, 1080p, 1080PSF
• To output and file: 480i, 576i, 720p, 720PSF, 1080i, 1080p, 1080PSF
• Hardware based, 10-bit
• 24, 25, 30, 50, 60 to 24, 25, 30, 50,60, 23.976, 29.97, 59.94 to 23.976, 29.97, 59.94, automatic
3:2 pull-down removal in 23.976 and 24 frame modes, other pull-down cadences include 2:2:2:4,
2:3:3:2, 3:2:3:2:2, and 2:2
• Hardware based, 10-bit
• 5-inch LCD - IPS (In-Plane Switching), glossy, 800x480 pixel LCD display
• Ultra wide viewing angle and color accuracy
• 720p50/59.94/60
• 576i50 (PAL)
• 480i59.94 (NTSC)
