ProSpec HD101 ProSpec HD101DC INSTRUCTIONS FOR USE MODELS: 56382658, 56382659 FOR YOUR CONVENIENCE, RECORD THE FOLLOWING IMPORTANT INFORMATION MODEL: SERIAL NUMBER: DATE PURCHASED: PURCHASED FROM: 10/11 Form Number 56091054...
Unplug electrical appliances before vacuuming them. Do not use outdoors or on wet surfaces. Do not use without dust bag in place. Store the machine in a cool, dry area. SAVE THESE INSTRUCTIONS 2 - FORM NO. 56091054 - ProSpec HD101 / HD101DC...
N’utilisez pas l’appareil a l’exterieur ni sur sol mouille. Ne vous servez pas de l’appareil si le sac a poussiere n’est pas en place. Rangez l’appareil a l’interieur, dans un endroit frais et sec. CONSERVEZ CES INSTRUCTIONS FORM NO. 56091054 - ProSpec HD101 / HD101DC - 3...
Extension cords connected to this machine should be 12 gauge, three-wire cords with three-prong plugs and outlets. DO NOT use extension cords more than 50 feet (15 m) long. PLEASE NOTE: FOR NORTH AMERICA ONLY 4 - FORM NO. 56091054 - ProSpec HD101 / HD101DC...
Les ralonges connectées à cette machine doivent avoir 12 mesures, trois ganses de fi l ayant trois fi ches masculines féminines tree-prong plugs and outlets. N´UTILISEZ PAS de ralonge de plus de 15 m (50 pieds) de long. VEUILLEZ NOTER: CES INSTRUCTIONS CONCERNENT UNIQUEMENT L’AMÉRIQUE DU NORD FORM NO. 56091054 - ProSpec HD101 / HD101DC - 5...
This is the sound of the beater bars grooming the pile. Align the holes, insert the other 2-part bolt (A), and tighten. NOTE: Raise the front of the machine to ease changing the settings. 6 - FORM NO. 56091054 - ProSpec HD101 / HD101DC...
Cut away any hair or thread wound around the brush roll or the belt pulley because the buildup could cause the belt to rotate unevenly. 8 - FORM NO. 56091054 - ProSpec HD101 / HD101DC...
Page 9
ProSpec HD101DC The following section also applies to ProSpec HD101 machines that have the Dirt Cup Conversion Kit part number 56039515 installed.
Page 10
DIRT CUP MODEL ASSEMBLY 10 - FORM NO. 56091054 - ProSpec HD101 / HD101DC...
Page 11
DIRT CUP MODEL ASSEMBLY FORM NO. 56091054 - ProSpec HD101 / HD101DC - 11...
Page 12
Raise the dust cup support. Push the lower handle (largest end down) through the tube of the dust cup support and into the handle socket at the back of the cleaner. Align the holes, insert a 2-part bolt (A), and tighten. 12 - FORM NO. 56091054 - ProSpec HD101 / HD101DC...
Page 13
Motor damage from failure to service the carbon brushes is not THE ELECTRICAL OUTLET. covered under warranty. CAUTION! Keep the area behind each latch free of dust or obstructions that would prevent it from locking securely. FORM NO. 56091054 - ProSpec HD101 / HD101DC - 13...
