Page 1: Instruction Manual
Janome 7312 Instruction Manual Janome Sewing Machine Janome Magnolia 7312 Instruction Manual www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... - Page 2 3. Do not reach for the appliance that has fallen into water. Unplug immediately. 4. Do not place or store appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
- Page 3 Please note that on disposal, this product must be safely recycled in accordance with relevant National legistlation relating to electrical/electronic products. If in doubt please contact your retailer for guidance. (European Union only.) www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
- Page 4 Janome 7312 Instruction Manual Janome Sewing Machine www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
-
Page 5: Table Of Contents
Strech Stitches ..................... 31 6. CARE OF YOUR MACHINE ............32-36 Cleaning the Feed Dog ................32 Dismantling and Assembling Hook Race Unit ..........33 Sewing Light ....................34 Oiling ......................34 Troubleshooting ..................35-36 www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 6: Essential Parts
@0 Presser foot holder @1 Carrying handle @2 Handwheel @3 Stop motion knob @4 Machine socket @5 Power switch @6 Free arm @7 Presser foot lifter Note: The specifications are subject to change without prior notice. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 7: Standard Accessories
Needle set r Seam ripper / buttonhole opener t Quilting guide y Mchine oil u Felt i Zipper foot o Buttonhole foot !0 Blind hem foot !1 Zigzag foot (set on the machine) www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 8: Getting Ready To Sew
. 4. Turn on the power switch to turn on the power and sewing light. q Power switch w Outlet e Machine socket r Machine plug t Foot control y Power supply plug www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 9: Foot Control
Do not modify the plug in any way. The foot controller Model KD-1902 (USA and Canada market) or KD-2902 (230V,Europe) is used with the sewing machine. Model Sew Simple 113. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 10: Extension Table
— For darning socks or mending knees, elbows or areas of wear in children's clothes Accessories Storage Box Sewing accessories are conveniently located in the extension table. q Accessories storage box www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 11: Levelling The Machine
Janome 7312 Instruction Manual Janome Sewing Machine Levelling the Machine Turn the adjusting foot to adjust its height so the machine sits stable, without wobbling. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 12: Presser Foot Lifter
The presser foot will drop off. To attach: Place the presser foot so the pin on the foot lies just under the groove of the foot holder. Lower the foot holder to lock the foot in place. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 13: Removing Or Inserting The Bobbin Case
Latch When inserting the bobbin case, place the horn into the recess of the hook race. e Horn Removing Bobbin Release the latch and the bobbin will fall out easily. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 14: Setting Spool Pins
When the bobbin is fully wound, stop the machine. Return the bobbin winder spindle to its original position by moving the spindle to the left, and cut the thread. m Tighten stop motion knob by turning it clockwise. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 15: Threading Bobbin Case
Pull the thread into the bobbin case slot. c Draw the thread under the tension spring and into the delivery eye. * Leave about 10 cm (4˝) of free thread. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 16: Threading The Machine
Firmly draw the thread up and through the take-up lever from right to left. v Draw the thread down and slip it into needle bar thread guide. b Thread the needle eye from front to back. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 17: Drawing Up Bobbin Thread
Lightly draw up the needle thread forming a loop of the bobbin thread. c Pull 15 cm (6˝) of both threads back and under the presser foot. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 18: Balancing Needle Thread Tension
Needle thread tension is too loose: The needle thread (top thread) will appear on the wrong side (bottom side) of the fabric..Tighten the needle thread tension by moving the dial to a higher number. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 19: Changing Needle
50 to 80 Cotton weight Percale 50 to 60 Synthetic Cotton Covered Polyester Denim, Tweed, 50 Silk Heavy Gabardine, weight Coating, Drapery and 40 to 50 Cotton Upholstery Fabric 40 to 50 Synthetic Cotton Covered Polyester www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 20: To Drop Or Raise The Feed Dogs
Feed dogs must be up for normal sewing. Reverse Stitch Button As long as you keep the reverse stitch button depressed, the machine sews backwards. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 21: Pattern Selector Dial
Setting mark Stitch Width Dial Turn the stitch width dial to set the the desired stitch width at the setting mark. The higher the number, the wider the stitch width. q Setting mark www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 22: Stich Reference Chart
Blind hem Box stitch Three step zigzag 0.5-3 stich Blind stitch Buttonhole 0.5-1 Single overlock stitch Honeycomb stitch Slant over edge Zigzag stretch stitch Straight stretch stitch Double overlock stitch Free-hand embroidery Removed www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 23: Basic Sewing
Raise the presser foot and remove the fabric, drawing the threads to the back. c Draw the threads up and into the thread cutter. The threads are cut the proper length for starting the next seam. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 24: Quilting Guide
1. Slide the quilting guide through the hole on top of the pressure foot holder. 2. Move the quilting guide to the required stitch distance. 3. Sew, tracing the previous stitching with the quilting guide. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 25: Utility Stitches
Machine Setting 1 Stitch Pattern : D, 2 Stitch Length : 1.5-4, (4) 3 Stitch Width 4 Thread Tension : 2-6 5 Presser foot : Zigzag foot Use these stitches for overcasting rough edges. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 26: Mending
Fold up the hem and fold it back to from a 0.4 to 0.7cm (1/4˝) allowance as illustrated. q Wrong side of the fabric w 0.4 to 0.7 cm (1/4˝) [A] Heavy weight fabrics [B] Fine or medium weight fabrics www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... - Page 27 Guide t Folded edge v Open the fold flat. y Right side of the fabric * If the needle drops far left, the stitches will show on the right side of the fabric. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
-
Page 28: Zipper Sewing
Reverse stitch to lock the stitches. Increase stitch length to 4 and set needle thread tension at 0. Sew the zipper opening with the basting stitch. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... - Page 29 Lower the needle slightly into the fabric, raise the foot. Open the zipper to move the slide behind the zipper foot. Lower the foot and stitch the remainder of the seam, making sure the fold is even. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
- Page 30 Lower the needle slightly into the fabric, raise the foot. Open the zipper to move the slider behind the zipper foot. Lower the foot and stitch the remainder of the seam, making sure the fold is even. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
-
Page 31: Buttonhole
(C) on the slider meets the start mark (B). Line up the markings on the starting point on the fabric. Note: The scale on the slider is engraved in centimeters. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 32: Buttonhole
7 Remove the fabric from the machine and cut the sewing thread. Insert a pin inside the bartack. Then cut the opening with a seam ripper. Take care not to cut the stitches. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 33: Corded Buttonhole
Pull the left end of the filler cord to tighten it. Thread the end through a darning needle, draw to the other side of the fabric and cut. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 34: Decorative Stitches
1 Stitch Pattern 2 Stitch Length : 0.5-1 3 Stitch Width : 3-5 4 Thread Tension : 2-6 5 Presser foot : Zigzag foot Satin stitching can be used for sewing initials, patterns, applique, etc. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 35: Stretch Stitches
3 Stitch Width 4 Thread Tension : 1-4 5 Presser foot : Zigzag foot Use this stitch with knitted, tricot or other stretchy fabrics. The stitch enables your seam to stretch without breaking the thread. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 36: Care Of Your Machine
Remove the needle and the presser foot. Remove the needle plate set screw and remove the needle plate. With a brush, clean out dust and lint clogging the feed dog teeth. Reset the needle plate. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 37: Dismantling And Assembling Hook Race Unit
Attach the hook race ring making sure the bottom pin fits into the notch. Lock the hook race ring by turning the holders back into position. Insert the bobbin case. y Pin u Notch www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 38: Sewing Light
Remove the cap, screw and face plate. Oil the point as indicated in the illustration. - Oiling the shuttle hook area Remove the hook race ring and hook. Oil the point as indicated in the illustration. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... -
Page 39: Troubleshooting
2. The needle is bent or blunt. See Page 15 3. The needle and/or threads are not suitable See Page 15 for the work being sewn. 4. The needle thread is not threaded properly. See Page 12 www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide... - Page 40 1. Threads have been caught in hook See page 33 The machine does mechanism. not run smoothly 2. The feed dog is packed with lint. See Page 32 and is noisy. www.aaasewing.com Magnolia 7312 Owners Manual/ User Guide...
