- Page 1 EG126118999KR Ultimate High Performance Audio sMS-100 Operating Instructions Rev. : 2.3 www. sotm-audio.com...
-
Page 2: Warranty Information
In case of not following the instructions on this manual. A Please read this instructions and Q&A board on our website carefully before asking for the warranty service. Supplied accessories sMS-100 standard wall adopter(9V/2A) - 1 -... - Page 3 Front & Rear Panels Front Panel ① Power LED : indicate the power on/off status. Rear Panel ① ETHERNET port: connect to a network router by LAN Cable. ② USB port: connect to a USB DAC or USB audio device. ③...
-
Page 4: Connection Guide
About sMS-100 ‘sMS-100’ is a network player which supports SqueezeLite, AirPlay, DLNA, MPD, and HQPlayer NAA function. ‘SqueezeLite’ output mode: connect sMS-100 to Logitech Media Server (LMS) through a local area network and playback the music files listed in LMS. - Page 5 Connect a network router to the Ethernet port on the rear panel of sMS-100 by LAN cable. Connect a USB DAC or DDC to the USB port on the rear panel of sMS-100 by USB cable. Check the device used as for a server, each server device should operate normally in the local area network.
- Page 6 1.3.2 AirPlay 1.3.2.1 To use AirPlay function, select ‘SOtM-Airplay’ as the Airplay output on your iPad, iPhone, and on iTunes. 1.3.3 DLNA 1.3.3.1 To use DLNA function, a Digital Media Server (DMS) and a Digital Media Controller (DMC) are needed. The sMS-100 will operate as your Digital Media Renderer (DMR) for playback of your content.
- Page 7 2.3.1.1 Please type ‘http://sonicorbiter.com/my/’ on an address bar in a web browser to check sMS-100’s IP address. (If you can’t access the sMS-100 Web page, you need to wait a bit more until the booting will be finished completely.) 2.3.1.2 Please click the IP address on the screen or type the IP address or ‘http://sonicorbiter.local/’...
- Page 8 How to playback music files SqueezeLite 3.1.1 Set up SqueezeLite function 3.1.1.1 In sMS-100 Web Page, please open ‘Apps -> Audio App Switcher’ menu, and select ‘SqueezeLite’. 3.1.1.2 If you want to check the information about USB DAC status which is currently connected with sMS-100, please open ‘Apps ->...
- Page 9 3.3.1.3 If you can’t playback the contents normally even though the USB audio device is connected, please click ‘Restart Squuzelite’ button on the upper right side. 3.3.1.4 If the USB audio device is not connected normally, ‘Not available’ message is indicated as the below image, you should check the USB audio device connection.
- Page 10 Remote Control screen, and select ‘SOtM-Squeeze’ (sMS-100). (The standard name for sMS-100 is ‘SOtM-Squeeze’. If you have several sMS-100s in the local area network, you can name each sMS-100 to distinguish each other. To name them, please refer to 24page, 3.1 SqueezeLite.)
- Page 11 Please execute iPeng, and click the dropdown menu on the upper right side of the screen, and select ‘SOtM-Squeeze’ (sMS-100). Once sMS-100 is selected, browse and playback music files. (You can adjust volume by the Volume Bar on the upper right side of the screen.)
- Page 12 AirPlay 3.2.1 Set up AirPlay function In sMS-100 Web Page, please open ‘Apps -> Audio App Switcher’ menu, and select ‘AirPlay’. 3.2.2 Browse and play music files 3.2.2.1 By iTunes Please execute iTunes on PC or MAC. - 11 -...
- Page 13 Please click Airplay icon(the next button of Volume Bar) on the left side of the screen and select ‘SOtM-Airplay’(sMS-100). Once SOtM-Airplay(sMS-100) is selected, browse and playback music files. - 12 -...
- Page 14 3.2.2.2 By iPad or iPhone Please touch iPad or iPhone’s screen from the botton to up to execute ‘Control Center’, and click ‘Airplay’ and select SOtM-Airplay(sMS-100). (when you select ‘AirPlay’ on iPad) (when you select ‘AirPlay’ on iPhone) - 13 -...
- Page 15 Once SOtM-Airplay(sMS-100) is selected, browse and playback music files by the music player application for iPad or iPhone. (This is an image when playing music files on iPad) (This is an image when playing music files on iPhone) - 14 -...
- Page 16 DLNA 3.3.1 Set up DLNA function In sMS-100 Web Page, please open ‘Apps -> Audio App Switcher’ menu, and select ‘DLNA’. 3.3.2 Browse and play music files By PlugPlayer (iPad) 3.3.2.1 Please execute ‘PlugPlayer’ and click ‘Devices’ on the bottom of the screen, select ‘SOtM-DLNA(sMS-100)’...
- Page 17 3.3.2.2 Once SOtM-DLNA(sMS-100) is selected, browse and playback music files. 3.3.2.3 This is an image when playing music files. - 16 -...
- Page 18 MPaD or MPDroid. 3.5.1.2 In sMS-100 Web Page, please click ‘Apps -> Audio App Switcher’, and select DLNA. 3.5.1.3 To check the connection information of the Vortexbox shared music file, please open ‘Apps ->...
- Page 19 3.4.2 By MPaD (iPad) 3.4.2.1 Please execute MPaD, click the Players button on the upper side and select ‘SOtM-MPD’ (sMS-100), click ‘Done’ button. 3.4.2.2 Once sMS-100 is selected, browse and playback music files. - 18 -...
- Page 20 Web Page Menu Please type sMS-100 IP address on an address bar in a web browser to connect sMS-100 Web Page. (Please refer to 6 page, 2.3.1 How to connect sMS-100 Web Page.) Home Indicate sMS-100 software version and network connection information.
- Page 21 2.2.2 Restart SqueezeLite: if the USB DAC status is indicated normally but music is not playing, please click this button. 2.2.3 USB DAC status: indicate the USB DAC information which is currently connected with sMS-100. 2.2.4 Play back: indicate the music file information which is currently playing. - 20 -...
- Page 22 2.3.1 Restart MPD: restart MPD. 2.3.2 Clear MPD database: clear the MPD database. HQPlayer 2.4.1 HQPlayer version : indicate the HQPlayer version. 2.4.2 HQPlayer EULA : indicate the HQPlayer’s user license. - 21 -...
- Page 23 System Status Indicate the current sMS-100’s system status. - 22 -...
- Page 24 Software Update Update sMS-100’s software. Once you click the update button, it will detect the latest software version and start the update. Caution : Please set up the value at Settings menu and click ‘Save changes’ to save all needed information correctly after you update the software.
- Page 25 SqueezeLite You can change sMS-100’s SqueezeLite Player name and set up the setting values. Caution : Please set up the Player Name and click ‘Save changes’ button to save the needed information correctly after you update the software. You can change sMS-100’s MPD Player name.
- Page 26 DLNA You can change DLNA Player name. Caution : Please set up the Player Name and click ‘Save changes’ button to save the needed information correctly after you update the software. Airplay You can change Airplay Player name. Please set up the Player Name and click ‘Save changes’ button to save the needed ...
- Page 27 Localization You can set up sMS-100’s time zone or language. Help You can get the information how to use sMS-100. System Reboot: reboot sMS-100. Power Down: finish the operation. - 26 -...
- Page 28 Specification Audio player feature DNLA audio renderer AirPlay SqueezeLite HQPlayer Support 24bit/384KHz Max, DSD High precision digital volume control Input voltage range : 7Vdc~9Vdc Input current : minimum 2A Ethernet : Gigabit Ethernet x 1 USB port : USB 2.0 x 3 ...
- Page 29 Ultimate High Performance Audio - 28 -...
