SOtM sms-100 Operating Instructions Manual

Hide thumbs Also See for sms-100:

Advertisement

Quick Links

Download this manual See also: Operating Instructions Manual
EG126118999KR
S
O
M
t
Ultimate High Performance Audio
sMS-100 Operating Instructions
Rev. : 2.3
www. sotm-audio.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the sms-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOtM sms-100

Summary of Contents for SOtM sms-100

  • Page 1 EG126118999KR Ultimate High Performance Audio sMS-100 Operating Instructions Rev. : 2.3 www. sotm-audio.com...

  • Page 2: Warranty Information

    In case of disassemble or modify the product. In case of not following the instructions on this manual. A Please read this instructions and Q&A board on our website carefully before asking for  the warranty service. Supplied accessories sMS-100  - 1 -...

  • Page 3: Front And Rear Panels

    Front & Rear Panels Front Panel  ① Power LED : indicate the power on/off status. Rear Panel  ① ETHERNET port: connect to a network router by LAN Cable. ② USB port: connect to a USB DAC or USB audio device. ③...

  • Page 4: Connection Guide

    ‘sMS-100’ is a network player which supports DLNA, AirPlay, SqueezeLite and MPD function.  ‘DLNA’ function: connect sMS-100 to DLNA server through a local area network and playback the music files shared by DLNA server. ‘AirPlay’ function: connect sMS-100 to Apple devices(iTunes, iPad etc.) through a local area network and playback the music files.
  • Page 5 Connect a network router to the Ethernet port on the rear panel of sMS-100 by LAN cable. Connect a USB DAC or DDC to the USB port on the rear panel of sMS-100 by USB cable. Check the device used as for a server, each server device should operate normally in the local area network.
  • Page 6 1.3.4 MPD 1.3.4.1 To use MPD function, please check the Vortexbox OS operates normally since sMS-100 playbacks music files shared by Vortexbox OS in the local area network. 1.3.4.2 If there is no VortexBox device, you need to download Vortexbox software from www.vortexbox.org and install it on your PC.
  • Page 7 2.3.1.1 Please type ‘http://sonicorbiter.com/my/’ on an address bar in a web browser to check sMS-100’s IP address. (If you can’t access the sMS-100 Web page, you need to wait a bit more until the booting will be finished completely.) 2.3.1.2 Please click the IP address on the screen or type the IP address or ‘http://sonicorbiter.local/’...
  • Page 8 How to playback music files DLNA 3.1.1 Set up DLNA function In sMS-100 Web Page, please open ‘Apps -> Audio App Switcher’ menu, and select ‘DLNA’. 3.1.2 Browse and play music files By PlugPlayer (iPad) 3.1.2.1 Please execute ‘PlugPlayer’ and click ‘Devices’ on the bottom of the screen, select ‘Sonicorbiter(sMS-100)’...
  • Page 9 3.1.2.2 Once Sonicorbiter(sMS-100) is selected, browse and playback music files. 3.1.2.3 This is an image when playing music files. - 8 -...
  • Page 10 AirPlay 3.2.1 Set up AirPlay function In sMS-100 Web Page, please open ‘Apps -> Audio App Switcher’ menu, and select ‘AirPlay’. 3.2.2 Browse and play music files 3.2.2.1 By iTunes Please execute iTunes on PC or MAC. - 9 -...
  • Page 11 Please click Airplay icon(the next button of Volume Bar) on the left side of the screen and select ‘Sonicorbiter’(sMS-100). Once Sonicorbiter(sMS-100) is selected, browse and playback music files. - 10 -...
  • Page 12 3.2.2.2 By iPad or iPhone Please touch iPad or iPhone’s screen from the botton to up to execute ‘Control Center’, and click ‘Airplay’ and select Sonicorbiter(sMS-100). (when you select ‘AirPlay’ on iPad) (when you select ‘AirPlay’ on iPhone) - 11 -...
  • Page 13 Once Sonicorbiter(sMS-100) is selected, browse and playback music files by the music player application for iPad or iPhone. (This is an image when playing music files on iPad) (This is an image when playing music files on iPhone) - 12 -...
  • Page 14 SqueezeLite 3.3.1 Set up SqueezeLite function 3.3.1.1 In sMS-100 Web Page, please open ‘Apps -> Audio App Switcher’ menu, and select ‘SqueezeLite’. 3.3.1.2 If you want to check the information about USB DAC status which is currently connected with sMS-100, please open ‘Apps -> SqueezeLite’ menu, you will find the information.
  • Page 15 <USB audio device is connected, but doesn’t playback music files > 3.3.1.3 If you get the same issue as the above image, you need to click ‘Restart SqueezeLite’ button and try playing the music files again. <USB audio device is not connected properly > 3.3.2 Browse and play music files 3.3.2.1 By LMS Web Remote Control A.
  • Page 16 Control screen, and select ‘Sonicorbiter’ (sMS-100). (The standard name for sMS-100 is ‘Sonicorbiter’. If you have several sMS- 100s in the local area network, you can name each sMS-100 to distinguish each other. To name them, please refer to 23page, 3.1 SqueezeLite.) Once sMS-100 is selected, browse and playback music files.
  • Page 17 Please execute iPeng, and click the dropdown menu on the upper right side of the screen, and select ‘Sonicorbiter’ (sMS-100). Once sMS-100 is selected, browse and playback music files. (You can adjust volume by the Volume Bar on the upper right side of the screen.)
  • Page 18 MPaD or MPDroid… 3.4.1.2 In sMS-100 Web Page, please click ‘Apps -> Audio App Switcher’, and select ‘MPD’. 3.4.1.3 If you want to check the information about the Vortexbox shared music file, please open ‘Apps ->...
  • Page 19 3.4.2 By MPaD (iPad) 3.4.2.1 Please execute MPaD, click the Players button on the upper side and select ‘Sonicorbiter’ (sMS-100). 3.4.2.2 Once sMS-100 is selected, browse and playback music files. - 18 -...
  • Page 20 Web Page Menu Please type sMS-100 IP address on an address bar in a web browser to connect sMS-100 Web Page. (Please refer to 6 page, 2.3.1 How to connect sMS-100 Web Page.) Home Indicate sMS-100 software version and network connection information.
  • Page 21 Restart SqueezeLite: if the USB DAC status is indicated normally but music is not playing, please click this button. USB DAC status: indicate the USB DAC information which is currently connected with sMS-100. Play back: indicate the music file information which is currently playing. - 20 -...
  • Page 22 2.3.1 Restart MPD: restart MPD. 2.3.2 Clear MPD database: clear the MPD database. System Status Indicate the current sMS-100’s system status. - 21 -...
  • Page 23 Software Update Update sMS-100’s software. Once you click the update button, it will detect the latest software version and start the update. Settings - 22 -...
  • Page 24 SqueezeLite You can change sMS-100’s SqueezeLite Player name and set up the setting values, please click ‘Save changes’ button after you finish changing the name or setting values. You can change sMS-100’s MPD Player name, please click ‘Save changes’ button after you finish changing the name.
  • Page 25 DLNA You can change DLNA Player name, please click ‘Save changes’ button after you finish changing the name. Localization You can set up sMS-100’s time zone or language. Help You can get the information how to use sMS-100. System Reboot: reboot sMS-100.

  • Page 26: Specification

    Specification Audio player feature  DNLA renderer AirPlay SqueezeLite Support 24bit/384KHz Max, DSD High precision digital volume control Input current : minimum 2A  Ethernet : Gigabit Ethernet x 1  USB port : USB 2.0 x 3  Power indicate lamp x 1 ...
  • Page 27 Ultimate High Performance Audio - 26 -...
