  • Page 1 POWERPLANT COMPONENT SPEAKER MODELS PP−CM40, PP−CM525, PP−CM65, PP−CMST1...
  • Page 2 POWERPLANT Explore the limits of car audio and PowerPlant will get you there. Fusion PowerPlant delivers accurate clear sound reproduction with real power. Push sound further than it’s gone before, confident that PowerPlant products have been engineered, designed and manufactured to...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS • COMPONENT SPEAKER FEATURES ......pg 4 • SPEAKER THEILE/SMALL PARAMETERS ......pg 4 •...

  • Page 4: Component Speaker Features

    COMPONENT SPEAKER FEATURES PowerPlant Component Speaker Systems feature an industrial cast basket with a protective finish, green top and bottom plate and a light-weight polypropylene cone complimented by a soft dome tweeter. The PowerPlant Component Speaker Systems provide style and great sound reproduction for the car audio specialist.

  • Page 5: Speaker Dimensions Pp-Cm40

    DIMENSIONS SPEAKER PP-CM40 128mm (5 -1/16") 51mm (2") 51mm 100mm (3 -15/16") (2") 128mm (5 -1/16") WOOFER TWEETER...
  • Page 6 DIMENSIONS X-OVER PP-CM40 92mm (3-5/8") 92mm (3-5/8") 175mm (6-7/8") 107mm (4-1/4") X-OVER...

  • Page 7: Speaker Dimensions Pp-Cm55

    DIMENSIONS SPEAKER PP-CM525 152mm (6") 51mm (2") 51mm 122mm (4-13/16") (2") 152mm (6") WOOFER TWEETER...
  • Page 8 DIMENSIONS X-OVER PP-CM525 92mm (3-5/8") 92mm (3-5/8") 175mm (6-7/8") 107mm (4-1/4") X-OVER...

  • Page 9: Speaker Dimensions Pp-Cm65

    DIMENSIONS SPEAKER PP-CM65 176mm (6-15/16") 51mm (2") 146mm (5-3/4") 51mm (2") 176mm (6-15/16") WOOFER TWEETER...
  • Page 10 DIMENSIONS X-0VER PP-CM65 92mm (3-5/8") 92mm (3-5/8") 175mm (6-7/8") 107mm (4-1/4") X-OVER...

  • Page 11: Speaker Dimensions Pp-Cmsti

    DIMENSIONS SPEAKER PP-CMST1 176mm (6-15/16") 51mm (2") 146mm (5-3/4") 51mm (2") 176mm (6-15/16") WOOFER TWEETER...
  • Page 12 DIMENSIONS SPEAKER & X-OVER PP-CMST1 128mm (5 -1/16") 51mm (2") 92mm (3-5/8") IN+ IN- W+ W- M+ M- T+ T- 92mm (3–5/8") 107mm (4–1/4") 51mm 100mm (3 -15/16") (2") 128mm (5 -1/16") 175mm (6-7/8") WOOFER X-OVER...

  • Page 13: Installation

    If the air volume is too small there could be lost low frequency notes. FUSION speakers are designed for optimal sound reproduction across the full audible spectrum – the human ear is most sensitive to amplitude, pitch, clarity and linearity in the 75Hz to  Khz bandwidth.

  • Page 14: Wiring

    Before any connection is made to the amplifier or source unit, make sure that you turn the audio system off. Failure to do so could result in either the stock system or new FUSION product being damaged. FUSION will not warranty damaged speakers due to incorrect installation.

  • Page 15: Woofer And Midrange Installation

    Note: Ensure the audio system is off during installation of FUSION product. Once the installation is complete FUSION recommends that you turn the volume of the source unit up slowly to prevent damaging the speakers. Please recheck the complete installation prior to turning the audio system...

  • Page 16: Tweeter Installation

    TWEETER INSTALLATION TWEETER (surface/angle mount) FUSION offers three choices of mounting styles to accommodate the varying requirements for on and off axis mounting positions. The most important goal for tweeter placement is the need to keep an un-obstructed path on axis to approximately 4"...

  • Page 17: X-Over Installation

    X-OVER INSTALLATION X-OVER INSTALLATION 1: FUSION x-overs are manufactured specifically for use with the FUSION full range component system. Use of any other crossover may result in damage to one or more of the components. 2: The x-over is designed for installation under the vehicle dash, under the rear parcel shelf or in the trunk of the vehicle.

  • Page 18: Wiring Diagram -Way X-Over

    WIRING DIAGRAM 2-WAY X-OVER PP-CM40, PP-CM525, PP-CM65 WIRING DIAGRAM 3-WAY X-OVER PP-CMST1...

  • Page 19: Tech Tips

    TECH TIPS In order to achieve accurate stereo imaging in your vehicle some basic principles should be applied. Designing a system around the principles of front stage and rear fill will enable the listener to perceive a stereo image in the front of them. The rear fill is the result of sound reflecting off the rear windshield and other surfaces which then travels to the listener.

  • Page 20: Trouble Shooting

    TROUBLE SHOOTING Before you contact your FUSION dealer or service centre, FUSION requires that you do some simple trouble shooting to help to diagnose the problem. If the FUSION speaker has been installed by a professional installation company, then we recommend that you return to the company so the technician can assess the problem and advise.
  • Page 21 NOTES...
  • Page 22 NOTES...
  • Page 23 YOU CAN HELP PROTECT THE ENVIRONMENT! PUBLISHED BY FUSION ELECTRONICS LIMITED: Please remember to respect the local regulations: © Copyright 006 by FUSION Electronics Limited. Hand in the non-working electrical equipment All rights reserved. Specifications and design are to an appropriate waste disposal center...
  • Page 24 Specifications and design are subject to change without notice.
