Fusion Encounter EN-FR4020 Quick Manual

ENCOUNTER
SPEAKERS
EN-FR4020, EN-FR52520, EN-FR6520, EN-FR6530
EN-FR4620, EN-FR5720, EN-FR6920, EN-FR6930
Speaker Parameters
Max Power Rating
RMS Power Rating
Frequency Response
Impedance
Sensitivity
Mounting Depth
Mounting Diameter
Max Power Rating
RMS Power Rating
Frequency Response
Impedance
Sensitivity
Mounting Depth
Mounting Diameter
Installation Guidelines
1) Ensure there is adequate clearance and depth for the speaker to be mounted
2) Use the supplied template to mark out and cut the correct diameter hole
3) Drill four holes for the mounting screws
4) Separate the grille from the frame
5) Insert the speaker and grille frame and affix with the screws provided
6) Complete installation by replacing the grille into the grille frame
(see diagram on reverse side)
EN-FR4020 EN-FR52520
120 Watts 140 Watts
35 Watts 40 Watts
75Hz - 20kHz 72Hz - 21kHz
4 Ohms 4 Ohms
86 dB 87 dB
47mm (1-5/8") 50mm (2")
93mm 120mm
(3-11/16") (4-3/4")
EN-FR4620 EN-FR5720
120 Watts 180 Watts
35 Watts 50 Watts
90Hz - 20kHz 52Hz - 21kHz
4 Ohms 4 Ohms
86 dB 86 dB
49mm 59mm
(1-15/16") (2-5/16")
140mm (5-1/2") 180mm (7-1/16) x
x 87mm (3- 128mm
7/16") (5-1/16")
EN-FR6520 EN-FR6530
180 Watts 200 Watts
50 Watts 55 Watts
63Hz - 21kHz 63Hz - 22kHz
4 Ohms 4 Ohms
87 dB 87 dB
60mm (2-3/8") 60mm (2-3/8")
130mm 130mm
(5-1/8") (5-1/8")
EN-FR6920 EN-FR6930
240 Watts 260 Watts
70 Watts 75 Watts
46Hz - 22kHz 47Hz - 22kHz
4 Ohms 4 Ohms
88 dB 88 dB
76mm 76mm
(2-31/32") (2-31/32")
233mm 233mm
(9-3/16") x (9-3/16") x
153mm (6") 153mm (6")
