Summary of Contents for Friedman JJ-100

  • Page 1                     INSTRUCTION MANUAL...
  • Page 2 KEY FEATURES:   new guitar amplifier designed by one of the  Hand Wired the USA  most well known amp modders and designers in  100-Watt all tube head the LA Music scene for the past 20 years, Dave   Two channels Friedman.     4 x EL-34 power tubes    4 x 12AX7 preamp tubes Dave Friedman has been designing and building   Master volume and gain controls guitar rigs for the stars since the early nineties.  ...
  • Page 3   INSTRUCTIONS 4. Follow Instructions – All operating and use    instructions should be followed.  Please keep this instruction manual for future  5. Water and Moisture – The amplifier should  reference and for the duration of owning this  not be used near water – for example, a  Friedman Amplifier. Please carefully read and  bathtub, washbowl, kitchen sink, laundry tub,  understand the instructions inside this user’s  wet basement, or near a swimming pool, and  manual before attempting to operate your  the like.  new amp. This instruction manual includes  6. Carts and Stands – The amplifier should be  essential safety information regarding the use  used only with a cart or stand that is  and maintenance of the amplifier. Take  recommended by the manufacturer.  special care to heed all warning symbols and  An amplifier and cart combination should be  signs inside this manual and those printed on  moved with care. Quick stops, excessive force,  the amplifier itself.  and uneven surfaces may cause the amplifier    and cart combination to overturn.  7. Wall or Ceiling Mounting  – The product should never be mounted to a  wall or ceiling.  WARNING!  8. Heat – Amplifier should be situated away  TO PREVENT FIRE OR SHOCK HAZARD, DO  from heat sources such as radiators, heat  NOT EXPOSE THE AMPLIFIER TO WATER OR  registers, stoves, or other amplifier (including  MOISTURE. DO NOT OPERATE NEAR ANY  amplifiers) that produce heat. ...
  • Page 4 slightly damp with water. Avoid getting water  tripod, bracket, or table recommended by the  inside the amplifier.  manufacturer, or sold with the product.  14. Non‐use Periods – The power cord of the  21. Lightning – For added protection for this  amplifier should be unplugged from the outlet  product before a lightning storm, or when it is  when left unused for a long period of time.  left unattended and unused for long periods  15. Object and Liquid Entry  of time, unplug it from the wall outlet. This  – Care should be taken so that objects do not  will prevent damage to the product due to  fall and liquids are not spilled into the  lightning and power line surges.  enclosure through openings.  22. Replacement Parts – When replacement  16. Damage Requiring Service  parts are required, be sure the service  – The amplifier should be serviced by qualified  technician has used replacement parts  service personnel when:  specified by the manufacturer or have the  A. The power‐supply cord or the plug has  same characteristics as the original part.  been damaged; or  Unauthorized substitutions may result in fire,  B. Objects have fallen, or liquid has been  electric shock, or other hazards.  spilled into the amplifier; or  23. Safety Check – Upon completion of any  C. The amplifier has been exposed to rain; or  service or repairs to this product, ask the  D. The amplifier does not appear to operate  service technician to perform safety checks to  normally or exhibits a marked change in  determine that the product is in proper  performance; or  operating condition.  E. The amplifier has been dropped, or the ...
  • Page 5   POWER SWITCH: Turn this ON for about one minute before taking the amp out of Standby for maximum  tube life.   ALWAYS MAKE SURE THERE IS A SPEAKER LOAD CONNECTED TO YOUR AMP BEFORE TURNING  ON.    STANDBY SWITCH:  Wait about a minute before placing this switch in the ON position.  This will put your  amp into PLAY mode.    POWER INDICATOR LAMP:  This is a gentle reminder that your amp is powered up.            MASTER VOLUME CONTROL: This is the overall volume of the amplifier.    PRESENCE CONTROL:  Adjusts the upper mids and highs in the power amp section.  Global on all  channels.  Start at about 4‐5 and adjust to taste.           Note:  This pot will sound scratchy when adjusted – this is normal.    BASS CONTROL:  This adds or reduces bass or bottom end.  As the amp gets louder, you may want to  back this off a bit.  Start at 7‐10 for bedroom volumes.     MIDDLE CONTROL :  Adds or reduces midrange.  Start at 5 or 6.  Lower settings will scoop the mids,  higher levels will allow your audience to actually hear the guitar in the mix.     TREBLE CONTROL:  This adds or reduces treble.  Start at 5 and adjust to taste.     MASTER:  This is the dirty channels VOLUME.  The more you turn it up, the louder it gets. If using the FX  loop, this becomes the amp’s SEND level and should be set at around 5 for optimum loop performance.   You then use the global master volume on the front of the amp for your overall volume.     GAIN CONTROL: This adds gain/distortion.  Adjust to taste.  Don’t be afraid.    CLEAN VOLUME:  Adjusts the clean channel’s volume.    BRIGHT SWITCH:   3 position switch that varies the overall brightness of the Clean Channel ONLY.    TREBLE CONTROL:  Adjusts the treble on the clean channel.  Start at 5 and adjust to taste.    MIDDLE CONTROL:  Adjusts the midrange of the clean channel. Start at 5 and adjust to taste.    BASS CONTROL:  Adjusts the bass on the clean channel.  Start at 5 and adjust to taste.   ...
  • Page 6     JBE SWITCH:  Primarily designed to add gain, compression and saturation.  It is normal for the volume  level to drop with this switch engaged.  Compensate with the amp’s Master volume.    FOOTSWITCH JACK:  This is where you plug in the footswitch.         SEND JACK:  This is where you plug the INPUT of your Effect(s).   Use a high quality shielded guitar cable.    RETURN JACK:  This is where you plug the OUT of your Effect(s). Use a high quality shielded guitar cable.    LINE OUT LEVEL CONTROL:  This controls the overall level of the line out.    LINE  OUT  JACK:    Connect  a  high  quality  ¼”  guitar  cable  to  send  signal  to  external  devices  such  as  additional power amps, FX, etc.  This is not speaker emulated.    SPEAKER OUT JACKS (2):  Plug speaker cabinets here.  Set Impedance selector to appropriate position.    MAINS INPUT:  Plug the supplied IEC power cord here and into a wall outlet to power the beast.  Only  plug into a wall outlet that matches the voltage of the amp.    MAIN FUSE:  This is the main fuse located in the mains input jack.  Replace only with type indicated on  rear panel.  If this fuse fails, it is most likely the result of a bad tube.  Constant blowing of this fuse (even ...
  • Page 7  Defective products must be shipped,  PROOF OF PURCHASE TO USE YOUR WARRANTY.  This warranty does not cover service or parts to  together with proof of purchase, freight  repair damage caused by accident, neglect, abuse,  pre‐paid and insured to the Authorized  normal wear, disaster, misuse, abuse, over‐ Friedman Service Center or directly to  powering, negligence, inadequate packing or  Friedman.    If a product must be returned to Friedman  shipping procedures and service, repair or any  modifications to the product which have not been  for warranty replacement/repair, a Return  authorized or approved by Friedman in writing.   Authorization Number must be obtained  ANY MODIFICATION TO THE AMPLIFIER WILL  from our Customer Service Department  VOID YOUR WARRANTY. If this product is  prior to shipping the product.    Please contact Friedman Customer Service  defective in materials or workmanship as  warranted above, your sole remedy shall be repair  Department for the Authorized Friedman  or replacement by Friedman as provided below.  Service Center nearest you.   Products must be shipped in their original   ...
  • Page 8 818‐505‐0391 – Monday – Friday 9AM‐4PM  option of repairing or replacing the product at no  (Pacific Standard Time)  additional charge, except as set forth below.      All replaced parts become a property of  Thank you again for choosing Friedman and we  Friedman. Products replaced or repaired  look forward to a long relationship!  under this warranty will be returned via    ground shipping within the United States    or Canada ‐ freight prepaid.      Friedman is not responsible for costs    associated with expedited shipping, either    to Friedman or the return of the product to    the customer.        All warranty repairs outside the United States and      Canada must be directed to the dealer or    distributor from which you purchased the    product.     ...
