MONET - TRINITY- EBONY
ELECTRIC WALL HEATER
MODEL : P23E
INSTALLATION AND USER INSTRUCTIONS
All instructions must be handed to user for safekeeping
Revision D - 06/09
Country(s) of destination - GB/IE
Focal Point Fires plc, Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e-mail: sales@focalpointfires.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Focal Point TRINITY P23E
Summary of Contents for Focal Point TRINITY P23E
- Page 1 MODEL : P23E INSTALLATION AND USER INSTRUCTIONS All instructions must be handed to user for safekeeping Revision D - 06/09 Country(s) of destination - GB/IE Focal Point Fires plc, Christchurch, Dorset BH23 2BT Tel: 01202 499330 Fax: 01202 499326 www.focalpointfires.co.uk e-mail: sales@focalpointfires.co.uk...
- Page 2 TRINITY MONET EBONY Fig 1 Dimensions (Monet shown)
-
Page 3: Appliance Data
CONTENTS Section Contents Page No. Section Contents Page No. Preliminary Notes Preparing the Appliance Appliance Data/Specifications Fixing the Appliance Electrical Installation Requirements 10.0 Operating the Appliance Site Requirements 11.0 Safety Cut-Out System Clearances to Combustible Materials 12.0 Maintenance - Lamp Replacement Unpacking the Appliance 13.0 Cleaning... -
Page 4: Clearances To Combustible Materials
SITE REQUIREMENTS The appliances are designed to be wall mounted via the brackets on the rear panel with the fixings provided. The wall should be relatively flat and not interfere with any of the ventilation slots in the rear panel. The wall must be structurally sound and of a material capable of withstanding moderate heat. -
Page 5: Unpacking The Appliance
UNPACKING THE APPLIANCE Caution: This appliance is heavy. Always seek assistance whilst unpacking and/or during installation. Read all the instructions before continuing to unpack or install this appliance. Carefully remove the appliance from its packaging and lay on the floor with it`s back surface downward. Note: DO NOT stand the appliance on its front frame as this may cause distortion. - Page 6 FIXING THE APPLIANCE A) Marking Positions: Having selected the final mounting position for the appliance, taking into account the site requirements as detailed in section 4, the heater can now be fixed to the wall. There are three fixing positions, two upper “hanging” positions”, and one lower position on the backpanel locat- ed behind the fuel bed.
- Page 7 10.0 OPERATING THE APPLIANCE Read All Instructions Before Use Check that the heater outlet grille, mounted at the top of the appliance, is not covered or obstructed in any way, and ensure the power to the fire is switched on. The appliance is controlled using four switches mounted at the right hand side towards the top.
- Page 8 12.0 MAINTENANCE ALWAYS DISCONNECT THE APPLIANCE AT THE SUPPLY OUTLET SOCKET BEFORE UNDERTAKING ANY MAINTENANCE. Excluding the lamp and fuse, use only genuine spare parts available from your supplier. Replacement lamps must be of the same wattage and specification as those stated in Section 2.0 Appliance Data/Specifications. Replacing the Light Bulb.
