peplink Surf 200BG-AP User Manual

Integrated home wi-fi access point
For more information, please visit peplink.com
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Wirelessly Connecting a Home Network via PePLink Surf 200BG-AP
I n t e g r a t e d H o m e W i - F i A c c e s s P o i n t S e t u p G u i d e

Overview

Integrated Home Wi-Fi Access Point – Introduction
Wirelessly Connecting a Home Network
This guide presents a brief introduction of, and a step-by-step process to
configure a basic setup for the Integrated Home Wi-Fi Access Point
functionality of PePLink Surf 200BG-AP.
Prior to carrying out the setup procedure in this
guide, the process of connecting PePLink Surf
200BG-AP with Citywide Wi-Fi must have been
successfully performed.
The high-level steps are as follows:
1. Configure
Integrated
Access Point on PePLink Surf 200BG-AP
2. Configure Wi-Fi enabled host PC(s)
3.
Test the Wi-Fi connection(s) with PePLink Surf 200BG-AP
The Integrated Home Wi-Fi Access Point functionality of PePLink Surf 200BG-AP
allows 802.1b/g devices on customers' premises to wirelessly connect with a PePLink
Surf 200BG-AP unit through which Citywide Wi-Fi is accessed.
With PePLink Surf 200BG-AP, the already existing Ethernet capabilities of the
PePLink Surf Series remain unaffected.
Figure 1 – PePLink Surf 200BG-AP and Integrated Home Wi-Fi Access Point
Home
Wi-Fi
1
How-to Document
PePLink Surf 200BG-AP
Copyright © 2006 PePLink Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Surf 200BG-AP and is the answer not in the manual?

Questions and answers

Related Manuals for peplink Surf 200BG-AP

Summary of Contents for peplink Surf 200BG-AP

  • Page 1 Surf 200BG-AP unit through which Citywide Wi-Fi is accessed. With PePLink Surf 200BG-AP, the already existing Ethernet capabilities of the PePLink Surf Series remain unaffected. Figure 1 – PePLink Surf 200BG-AP and Integrated Home Wi-Fi Access Point Wirelessly Connecting a Home Network Copyright © 2006 PePLink Ltd.

  • Page 2: Setup Procedure

    From the configuration and connections performed in the Prerequisite Setup, the Web-based Configuration Interface of PePLink Surf 200BG-AP should remain accessible via a host PC connected via Ethernet to the PePLink Surf 200BG-AP unit. Configure the Integrated Home Wi-Fi Access Point settings as follows: 1.
  • Page 3 Figure 3 – The AP Settings section on the CPE Setup page Figure 4 – Further configuration parameters are displayed upon the selection of the Configure Manually radio button. Wirelessly Connecting a Home Network Copyright © 2006 PePLink Ltd.
  • Page 4 The same value as the one entered here will subsequently be used when configuring host PC(s) that connect with Integrated Home Wi-Fi Access Point of PePLink Surf 200BG-AP. For illustration purposes, the encryption key value PePLinkSurfAP will be used throughout this guide.
  • Page 5 PePLink Surf 200BG-AP, via the URL http://192.168.20.1 Upon successfully connecting, the Welcome Screen is displayed. After successfully testing the connection between the Wi-Fi enabled host PC and PePLink Surf 200BG-AP, test the connection with the Internet by visiting our website at www.peplink.com. PePLink Technical Support...
