BFM Europe The Collection Da Vinci Illumia Installation, Maintenance & User Instructions

Balanced flue log effect heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Da Vinci Illumia &
Distinction Illumia
BALANCED FLUE LOG EFFECT HEATER
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No. DDVL**RN2 is for use on Natural Gas (G20) at a supply pressure
of 20 mbar in G.B. / I.E.
** Denotes cosmetic variant

Advertisement

Table of Contents
loading

Related Manuals for BFM Europe The Collection Da Vinci Illumia

Summary of Contents for BFM Europe The Collection Da Vinci Illumia

  • Page 1 Da Vinci Illumia & Distinction Illumia BALANCED FLUE LOG EFFECT HEATER Installation, Maintenance & User Instructions Hand these instructions to the user Model No. DDVL**RN2 is for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E. ** Denotes cosmetic variant...

  • Page 2: Table Of Contents

    Lighting the appliance 52-58 Cleaning instructions / removing & replacing the glass assembly 59-61 Removing & replacing the logset 62-67 Replacing the glass assembly User replaceable parts Model number DDVL**RN2 is manufactured by:- BFM Europe Ltd, Trentham Lakes, Stoke-on-Trent, Staffordshire, ST4 4TJ...

  • Page 3: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Main injector : (1 off) Cat 82 – size 600 Pilot Type : Black Technigas “Polidoro” G27.2 Max. Gross Heat Input : 8.7kW Min. Gross Heat Input : 5.5 kW 0.799 m 3 /hr (High) Gas Rate : 0.511 m 3 /hr (Low) Cold Pressure :...

  • Page 4: Conditions Of Installation

    INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a GAS SAFE Registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution.

  • Page 5: Flue Terminal Position

    FLUE TERMINAL POSITION The minimum acceptable dimensions from the flue terminal to obstructions and ventilation openings are shown below and listed in the table It is important that the position of the flue allows the free passage of air across it at all times. The minimum acceptable space from the flue terminal to obstructions and ventilation openings are specified below (figure 3).

  • Page 6: Installation Of Fire

    SECTION 2 INSTALLATION OF FIRE UNPACKING THE COMPONENTS Remove the loose item packaging carefully from the pack. Check the contents as listed :- DO NOT UNDER ANY CIRCUMSTANCES USE THIS APPLIANCE IF THE GLASS PANEL IS BROKEN OR NOT SECURELY FIXED TO THE FIREBOX. Packing Check List Pack 1 of 3 - Combustion Chamber Pack 1 off...
  • Page 7 Carefully lift the surround components out of the wooden crate. Remove the loose item packaging carefully from the pack. Check the contents as listed below :- Pack 3 of 3 - Da Vinci Surround 1 off Hearth 1 off L/H leg 1 off Shelf 1 off R/H leg...

  • Page 8: Preparing The Combustion Chamber Opening (In Studded Wall)

    PREPARATION OF THE COMBUSTION CHAMBER OPENING (INTO STUDDED WALL) 2.2.1 All combustible parts of the studwork must be set at the distances as shown below in figure 4 & 5. Fig. 4 Minimum 50mm at rear Minimum 50mm at sides Combustion Chamber 2.2.2 Refer to figure 1 on page three for dimensions of the flue outlet.

  • Page 9: Preparing The Combustion Chamber Opening (In Chimney Breast)

    PREPARATION OF THE COMBUSTION CHAMBER OPENING (INTO EXISTING CHIMNEY BREAST) 2.3.1 An opening should be constructed to the following dimensions in the existing chimney breast as shown in figure 6 below. Fig. 6 Lintle must project 150mm either side of the opening if cutting into an existing chimney...
  • Page 10 (CONTINUED) 150mm Fig. 7 The Interactive Zone - Openings, beams or joists within this area need to be assessed. 400mm interactive area Load triangle - No beam or opening permissible within this area 600mm load triangle Minimum 200mm Lintel e.g. 750mm x 75mm Proposed Opening in Chimney Breast...

  • Page 11: Installation Of The Gas Supply

    INSTALLATION OF THE GAS SUPPLY (INTO STUDDED WALL OR EXISTING CHIMNEY BREAST) 2.4.1 Before installing the combustion chamber, decide from which side or if a rear connection to the gas supply is required. Plan the pipe run to enter the below the firebox from the left and connect to the inlet elbow. See figure 8, 9 &...

  • Page 12: Specifying The Flue System & Components

    SPECIFYING THE FLUE SYSTEM & ASSOCIATED COMPONENTS This product comes with the optional of 3 methods of flueing :- Decide upon the method of flue that is most suitable for the property in which you are installing the product, from the following options :- 2.5.1 Balanced Flue in Horizontal Configuration This flueing method uses a 0.5 metre vertical pipe starter pipe section, then...

  • Page 13: Balanced Flue In Horizontal Flue Configuration

    BALANCED FLUE IN HORIZONTAL CONFIGURATION 2.6.1 Horizontal balanced flue configuration and components identified as shown below in figure 11. Fig. 11 1554mm Max 1 metre length of metalotherm 324mm Min flue duct 469mm Max This is the standard flue duct supplied.
  • Page 14 BALANCED FLUE IN HORIZONTAL CONFIGURATION (CONTINUED) 2.6.2 Mark the position of the centre of the flue on the inner wall. (See figure 11 on previous page for position). 2.6.3 Cut hole for outer flue pipe. There are two possible methods to achieve this, either core drill or via hammer and chisel.

  • Page 15: Balanced Flue In Vertical Flue Configuration

    BALANCED FLUE IN VERTICAL CONFIGURATION 2.7.1 Vertical flue configuration and components identified as shown below in figure 12. Fig. 12 For details of weather proofing options at point of exit, please Vertical Terminal see overpage, sections 2.7.1 to 2.7.8 for a flat roof or 2.7.9 for a pitched roof Locking Bands Minimum Flue Height = 3 metres...

  • Page 16: Balanced Flue In Vertical Flue Configuration (Flat Roof)

    BALANCED FLUE IN VERTICAL CONFIGURATION (FLAT ROOF) 2.8.2 Determine the position of the flue run within the property and the termination position is correct in accordance with BS 5440. Ensure that clearances to combustible surfaces (50mm minimum) are sufficient where the flue run may come within close contact of joists etc. 2.8.3 For a flat roof installation the following components will need to be ordered from Metaloterm :-...

  • Page 17: Balanced Flue In Vertical Flue Configuration (Pitched Roof)

    BALANCED FLUE IN VERTICAL CONFIGURATION (PITCHED ROOF) 2.9.1 Determine the position of the flue run within the property and the termination position is correct in accordance with BS 5440. Ensure that clearances to combustible surfaces (50mm minimum) are sufficient where the flue run may come within close contact of joists etc. 2.9.2 For a pitched roof installation the following components will need to be ordered from Metaloterm :-...

  • Page 18: Balanced Flue Utilising Existing Chimney

    2.10 BALANCED FLUE UTILISING EXISTING CHIMNEY Vertical flue configuration and components identified as shown below in figure 15 for installation into an existing chimney. Fig. 15 Outside Mounting Plate 4” / 100mm Flexible Flue Liner Minimum Flue Internal Height Mounting = 3 metres Plate Sliding Adaptor...
  • Page 19 2.10 BALANCED FLUE UTILISING EXISTING CHIMNEY (CONTINUED) 2.10.1 Check the soundness of the chimney to ensure that there are no leaks or remedial work required. Sweep the chimney if necessary. 2.10.2 Feed the 4” / 100mm flue liner through the chimney. 2.10.3 Attach the sliding adaptor to the bottom of the flexible liner and secure with the 2 off screws provided.

  • Page 20: Securing The Combustion Chamber In The Opening / Fitting The Closure Plate

    2.11 SECURING THE COMBUSTION CHAMBER IN THE OPENING / FITTING THE CLOSURE PLATE / CONVECTION CHANNEL 2.11.1 The product is supplied with a closure plate to assist in sealing off the top of the opening, and providing access to the flue connection on the top of the fire.

  • Page 21: Setting Hearth Panel / Surround Legs / Combustion Chamber Height

    2.12 SETTING THE COMBUSTION CHAMBER HEIGHT TO INSTALL THE SURROUND AND CENTRALISING THE SURROUND LEGS. 2.12.1 In order to ensure that the combustion chamber is at the right height to allow the controls access panel to open and close correctly, it is necessary to adjust the height of the combustion chamber as shown below in figure 17.
  • Page 22 2.12 SETTING THE COMBUSTION CHAMBER HEIGHT TO INSTALL THE SURROUND AND CENTRALISING THE SURROUND LEGS. (CONTINUED) 2.12.3 In order to ensure that controls access cover does not bind on the surround legs, it also necessary to set the surround legs to assume a 4mm gap at each side of the controls access cover, centrally about the opening.

  • Page 23: Removal / Re-Fitting The Glass Frame Assembly

    2.13 REMOVING THE GLASS FRAME ASSEMBLY 2.13.1 To remove the glass frame, the glass clamp as supplied in the loose items pack will be required. Secure the clamp to the glass panel as shown below in figure 20. Fig. 20 Glass clamp 2.13.2 The glass frame is released by firstly unscrewing the retaining bolts of...
  • Page 24 2.13.3 Whilst holding the glass suction clamp, release the bottom glass clamps as indictated below in figure 22 by unlatching them down and forwards. Fig. 22 Bottom Glass Clamps 2.13.4 Ensure the glass assembly is supported at all times during the following operations using the glass clamp.
  • Page 25 Fig. 24 Move entire glass assembly to the left Fig. 25 Swing right hand edge of glass frame assembly forwards to clear R/H leg of surround. Glass frame assembly can then be removed.

  • Page 26: Installation Of Lamp Assemblies

    2.14 INSTALLATION OF LAMP ASSEMBLIES 2.14.1 Remove the ceramic support which is held in place by six off screws as shown below in figure 26. Fig. 26 Six off ceramic support retaining screws 2.14.2 Remove the burner and controls tray which is held in position by fourteen screws as shown below in figure 27.
  • Page 27 2.14.3 Remove two screws from electric cover and remove cover as shown below in figure 28. Fig. 28 Screws for electric cover 2.14.4 Feed wiring from lamp assemblies through the grommet in the side of the fire and make connections as shown in figure 29 below. Fig.

  • Page 28: Making The Electrical Connection

    2.14.5 Re-assemble the electrics cover in reverse order. 2.14.6 Route lamp wiring up to surround shelf infill level ensuring that the wiring is kept clear of hot surfaces. 2.14.7 Fit the surround up to the point of the shelf infill (refer to section 2.16) 2.14.8 The surround lamp assemblies are then fitted to the surround using the two nuts provided, as shown in figure 30 below.

  • Page 29: Installing The Da Vinci / Distinction Surround Design

    2.16 INSTALLING THE DA VINCI / DISTINCTION SURROUND 2.16.1 Unpack the surround from the wooden crate, check all parts are present as per figure 31 below and carefully store the components. 2.16.2 Set the hearth panel equally around the centre of the opening and ensure that it is level across it’s width.

  • Page 30: Fitting The Fuel Bed Logset

    FITTING THE FUEL-BED LOGSET 3.1.1 Log “A” must be fitted with the retaining lugs as shown below in figure 32 positioned on Log “A” into the locating holes in the fuel-bed base plate as shown below. Fig. 32 Locating lugs - position into holes as shown above 3.1.2 Log “A”...
  • Page 31 3.1.3 Place the bark chippings over the burner as shown below in figure 34, do not allow the bark chippings to cover the area around the pilot as indicated below. Fig. 34 Keep area around pilot clear of bark chippings 3.1.4 Position the retaining lug on Log “B”...
  • Page 32 3.1.5 Fit Log “B” into position, using the locating lug that fits into left hand end of Log “A” as shown below in figure 36. Fig. 36 Log “B” Fitted onto Log “A” 3.1.6 Fit Log “C” into position at right hand side of log “A” as shown below in figure 37, using the location lug in the right hand end of Log “A”...
  • Page 33 3.1.7 Fit Log “D” into position at right hand side of centre of the fuel-bed base log “A”as shown below in figure 38, using the locating lug in Log “A” as a guide for placement. Fig. 38 Log “D” Fitted onto Log “A”...
  • Page 34 3.1.9 Fit Log “F” into position at the centre of the fuel-bed as shown below in figure 40, using the locating lug in Log “D” as a guide for placement. Fig. 40 Log “F” Fitted onto Log “D” 3.1.10 Fit Log “G” into position at the left hand centre of the fuel-bed as shown below in figure 41, using the locating lug in Log “F”...
  • Page 35 3.1.11 Fit Log “H” into position at the right hand centre of the fuel-bed as shown below in figure 42, using the retaining lug in Log “F” as a guide for placement. Finally, check pilot area to ensure no bark chippings have covered the pilot.

  • Page 36: Making The Gas Conection & Checking For Gas Tightness

    MAKING THE GAS CONNECTION & CHECKING FOR GAS TIGHTNESS 3.2.1 Before making the final gas connection, thoroughly purge the gas supply pipework to remove all foreign matter, otherwise serious damage may be caused to the gas control valve on the fire. Failure to purge the gas supply will invalidate the guarantee.

  • Page 37: Replacing The Glass Assembly

    REPLACING THE GLASS ASSEMBLY 3.4.1 When replacing the glass assembly manouever into position by reversing the instruction for removal as detailed in section 2.13 3.4.2 Centre the assembly (use the legs on the surround as a guide) but take care not to damage the surround. When fitted correctly all the glass frame should be hidden behind the surround legs.

  • Page 38: Lighting / Using The Appliance

    LIGHTING THE APPLIANCE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. Ensure the 3 off AAA batteries as supplied in the loose items pack has been fitted to the remote handset before attempting to use the handset and the mains electrical connection has been made to the product as per section 2.15...
  • Page 39 3.5.1.3 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily. To reduce the heat input directly down to the minimum level, press the “SMALL”...
  • Page 40 3.5.2 Operation of the Fire in “TEMPERATURE” mode 3.5.2.1 In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (figure 48) mode or “NIGHT TEMP” mode (figure 49).
  • Page 41 3.5.3 Operation of the Fire in “TIMER” mode 3.5.3.1 In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...
  • Page 42 3.5.4 Operation of the Fire in “LIGHT / DIMMER” mode (where down lights are specified) 3.5.4.1 In order to change the mode of operation from “MANUAL” to “LIGHT / DIMMER”, briefly press the “SET” button to scroll through to the light bulb mode as shown below in figure 52.
  • Page 43 3.5.5 Operation of the Fire in “CIRCULATING FAN” mode 3.5.5.1 In order to change the mode of operation from “MANUAL” to “CIRCULATING FAN”, briefly press the “SET” button to scroll through to the circulating fan mode as shown below in figure 53 / 54, both fan and level icons will flash.

  • Page 44: Fitting The Handset Wall Bracket

    3.5.6 Low Battery Signal 3.5.6.1 When the battery in the handset needs replacing, “BATT” will be displayed on the handset. 3.5.6.2 Remove the cover on the rear of the handset and replace the 9V battery as necessary. 3.5.7 To Set the Time on the Remote Handset 3.5.7.1 Simultanelously press the “UP”...

  • Page 45: Maintenance

    SECTION 4 MAINTENANCE Servicing Notes Servicing should be carried out annually by a competent person such as a GAS SAFE registered engineer. It is a condition of the guarantee scheme that this is carried out by a competent person i.e a GAS SAFE registered Engineer in accordance with these servicing notes, and the pilot must also be changed as a requirement of the guarantee.

  • Page 46: Removal Of The Gas Control Valve / Controls Access Cover

    4.2.3 Replace in reverse order and carry out a gas tightness test. Removing the Gas Control Valve / Controls Access Cover 4.3.1 Open the controls access cover at the bottom of the fire. 4.3.2 Isolate the gas supply. 4.3.3 It may be advantageous to remove the controls access cover at this point.

  • Page 47: Removal Of The Convection Fan

    4.4.2 Lift the ultrasonic receiver out of it’s retaining bracket at the left hand side of the gas control valve 4.4.3 Disconnect the control wires. 4.4.4 Re-fit the new receiver and re-connect the control wires in reverse order, replace the receiver unit into it’s cradle at the left hand side of the gas control valve.

  • Page 48: Removal / Replacement Of The Handset Batteries

    4.6.2 It may be advantageous to remove the controls access cover at this point. To do this, firstly loosen the 2 off rear capscrews and remove the front 2 off capscrews. This will enable the entire mechanism to be removed in one assembly, with the finished controls access cover still in position, see figure 56 on previous page for further details.

  • Page 49: Wiring Diagram

    4.10 Wiring Diagram Fig. 57 IMPORTANT : ALL ELECTRICAL WORK MUST BE CARRIED OUT BY A COMPETENT, QUALIFIED ELECTRICIAN.

  • Page 50: 5.2 Installation Information / About Your Fire

    If this appliance is fitted directly on to a wall without the use of a BFM Europe supplied fireplace or surround, soft wall coverings such as wallpaper, blown vinyl etc.

  • Page 51: Important Safety Information

    ABOUT YOUR NEW DA VINCI / DISTINCTION GAS FIRE The Collection Da Vinci / Distinction log effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose log layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 52: Lighting The Appliance

    LIGHTING THE APPLIANCE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. Ensure the 3 off AAA batteries as supplied in the loose items pack has been fitted to the remote handset before attempting to use the handset and the mains electrical connection has been made to the product as per section 2.15...
  • Page 53 5.3.1.3 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily. To reduce the heat input directly down to the minimum level, press the “SMALL”...
  • Page 54 5.3.2 Operation of the Fire in “TEMPERATURE” mode 5.3.2.1 In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (figure 4) mode or “NIGHT TEMP” mode (figure 5).
  • Page 55 5.3.3 Operation of the Fire in “TIMER” mode 5.3.3.1 In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...
  • Page 56 5.3.4 Operation of the Fire in “LIGHT / DIMMER” mode 5.3.4.1 In order to change the mode of operation from “MANUAL” to “LIGHT / DIMMER”, briefly press the “SET” button to scroll through to the light bulb mode as shown below in figure 8. Fig.
  • Page 57 5.3.5 Operation of the Fire in “CIRCULATING FAN” mode 5.3.5.1 In order to change the mode of operation from “MANUAL” to “CIRCULATING FAN”, briefly press the “SET” button to scroll through to the circulating fan mode as shown below in figure 9, both fan and level icons will flash.
  • Page 58 None of these parts must be washed or exposed to any cleaning agents or water. Any damaged parts must be replaced by contacting your dealer or telephoning BFM Europe on the number stated on the rear cover of this book. Logs or bark chippings must only be...

  • Page 59: Cleaning Instructions / Removing & Replacing The Glass Assembly

    5.4.4 Removing the Glass Assembly - Ensure the fire is cool before attempting to remove the glass panel 5.4.4.1 To remove the glass frame, the glass clamp as supplied in the loose items pack will be required. Secure the clamp to the glass panel as shown below in figure 11.
  • Page 60 5.3.4.3 Whilst holding the glass suction clamp, release the bottom glass clamps as indictated below in figure 13 by unlatching them down and forwards. Fig. 13 Bottom Glass Clamps 5.3.4.4 Ensure the glass assembly is supported at all times during the following operations using the glass clamp.
  • Page 61 Fig. 15 Move entire glass assembly to the left Fig. 16 Swing right hand edge of glass frame assembly forwards to clear R/H leg of surround. Glass frame assembly can then be removed.

  • Page 62: Removing & Replacing The Logset

    REMOVAL AND REPLACING THE FUEL-BED LOGSET Remove the glass panel as shown in section 5.4.4 before attempting to remove or replace the logs. 5.5.1 Log “A” must be fitted with the retaining lugs as shown below in figure 17 positioned on Log “A” into the locating holes in the fuel-bed base plate as shown below.
  • Page 63 5.5.3 Place the bark chippings over the burner as shown below in figure 19, do not allow the bark chippings to cover the area around the pilot as indicated below. Fig. 19 Keep area around pilot clear of bark chippings 5.5.4 Position the retaining lug on Log “B”...
  • Page 64 5.5.5 Fit Log “B” into position, using the locating lug that fits into left hand end of Log “A” as shown below in figure 21. Fig. 21 Log “B” Fitted onto Log “A” 5.5.6 Fit Log “C” into position at right hand side of log “A” as shown below in figure 22, using the location lug in the right hand end of Log “A”...
  • Page 65 5.5.7 Fit Log “D” into position at right hand side of centre of the fuel-bed base log “A”as shown below in figure 23, using the locating lug in Log “A” as a guide for placement. Fig. 23 Log “D” Fitted onto Log “A”...
  • Page 66 5.5.9 Fit Log “F” into position at the centre of the fuel-bed as shown below in figure 25, using the locating lug in Log “D” as a guide for placement. Fig. 25 Log “F” Fitted onto Log “D” 5.5.10 Fit Log “G” into position at the left hand centre of the fuel-bed as shown below in figure 26, using the locating lug in Log “F”...
  • Page 67 5.5.11 Fit Log “H” into position at the right hand centre of the fuel-bed as shown below in figure 27, using a retaining peg in Log “F” as a guide for placement. Finally, check pilot area to ensure no bark chippings have covered the pilot.

  • Page 68: Replacing The Glass Assembly

    REPLACING THE GLASS ASSEMBLY 5.5.1 When replacing the glass assembly manouever into position by reversing the instruction for removal as detailed in section 2.14 5.5.2 Centre the assembly (use the legs on the surround as a guide) but take care not to damage the surround. When fitted correctly all the glass frame should be hidden behind the surround legs.

  • Page 69: User Replaceable Parts

    Spare bag of bark chippings Due to our policy of continual improvement and development the exact accuracy of illustrations and descriptions contained in this book cannot be guaranteed Part No. B-166140 Issue 3 BFM Europe Ltd. Trentham Lakes Stoke-on-Trent Staffordshire ST4 4TJ www.bfm-europe.com...
