Summary of Contents for ARC R10
- Page 3 Fill the shock oil to just cover the inside bevel of the gears. DO NOT COMPLETELY COVER THE GEARS WITH OIL. Apply Oil before assembly Diff case direction needs to match as below. Apply Oil before assembly...
- Page 4 CNC SPUR 48dp CNC SPUR 64dp R104101 48dp 84T Option R104110 64dp 96T Option R104099 48dp 82T Option R104111 64dp 98T Option R104100 48dp 83T Option R104112 64dp 100T Option R104102 48dp 85T Option R104113 64dp 102T Option R104118 64dp 112T Option R104119 64dp 114T...
- Page 5 R103022 1.0mm Option R103021 0.5mm Option R103020 0.3mm Internal Ratio Front Pulley Middle Pulley Rear Pulley...
- Page 8 Rear lower arms have 6 different positions for shocks and anti-roll bars. Make sure left and right sides are symmetrical during assembly. Front lower arms have 4 different shock positions. Make sure left and right sides are both symmetrical during assembly. R103022 1.0mm Option...
- Page 9 R103022 1.0mm Option R103021 0.5mm Option R103020 0.3mm...
- Page 10 Use a screw to push the ball into the ball joint to avoid damage to the ball joint.
- Page 11 R103015 Pivot Pin Front-Out 23mm...
- Page 12 The bumper can be cut at the black lines to make it smaller.
- Page 14 It is recommended to use servo mount rubber. R102011 Servo Mount Alu R R102012 Servo Mount Alu L R102013 Servo Mount L-Low Alu...
- Page 15 Motor Pinion (Not included) Gear mesh should have a minimal amount of play between spur and pinion. Use a small file to shape the battery holder edge. A gear mesh that is too tight will put extra strain on the spur gear. A gear mesh that is too loose will strip the spur.
- Page 16 Battery location can be adjusted by moving the battery holder. Use glass fiber tape attached to the battery It can be used to adjust weight distribution. mount plate to secure the battery.
