- Page 1 Operating Instructions English...
-
Page 2: Table Of Contents
Content Scope of Supply ....21 1 Switchbox with switches for LED light and discharge chute control Safety Instructions ....22 2 Safety bar Assembly ......24 3 LED light 4 Battery compartment Startup .......27 5 Discharge chute with adjustment Operation ......29 6 Rotor 7 Scraper blade Device Shutdown ....30 Battery removal ....30 Battery Care ......31 Scraper Blade Exchange ..32 Spare Parts ......32 Technical Data ......33 Warranty ......34... -
Page 3: Scope Of Supply
Scope of Supply Congratulations on the purchase of your Sonneck Packaging content – After opening the packaging check the completeness of the supplied components! SNOWMASTER product! Read the user manual carefully and familiarize yourself with the operating elements and the use of the de vice. The user is responsible for accidents with other persons or their property. Please observe all instruc... -
Page 4: Safety Instructions
Safety Instructions Bedeutung der Symbole Before snow clearing • Wear sturdy footwear and suitable clothing. Avoid Read the user ma Do not reach into loosefilling clothing and scarves: these can be caught nual before setting ro tating parts or into by the cutter! into operation! the discharge chute! • Only position the device on solid ground. Clear the Warning! Risk Ensure adequate area of objects and stones that could be caught and of injury if... - Page 5 • Have damaged parts repaired or replaced immedia • Switch the device off and remove the battery and tely. safety key, if: • Ensure that no liquids get into the device. - you leave, clean or handle the device or wish to • Use only Sonneck original replacement parts and do adjust the discharge chute. not open the housing yourself under any circumstan the rotor is blocked. ces, otherwise the warranty of your device will expire. if the device has collided with an obstruction: Only authorize the Service and Repair service respon Immediately check whether the device or rotor is sible for your area – see back page.
-
Page 6: Assembly
Assembly ENGLISH Operating Instructions ACCU 450... - Page 7 Operating Instructions ACCU 450 ENGLISH...
- Page 8 6. Assemble the discharge chute 7. Push the screws through the 8. Secure the two screws with the and fit the two seals precisely holes from the inside at both knurled nuts and tighten them. between the plastic parts. sides. ENGLISH Operating Instructions ACCU 450...
-
Page 9: Startup
Startup 1. Fully charge the battery. Charging operation takes approx. 90 minutes. Observe LED display: red + green = battery charging 2x green = battery charged Definitely observe the instructions for battery care! Operating Instructions ACCU 450 ENGLISH... - Page 10 4. Press the safety button and keep it 5. … while you pull the start 6. Now you can release depressed… lever towards yourself. the safety button. ENGLISH Operating Instructions ACCU 450...
-
Page 11: Operation
Operation 8. Swing dis 9. Swing dis 7. Switch LED light on charge chute charge chute and off to the left to the right Operating Instructions ACCU 450 ENGLISH... -
Page 12: Device Shutdown
Device shutdown/battery removal 2. Open the battery 3. Remove the battery for charging compartment or if the device is not used for a and remove prolonged period. the safety key. 1. Release the switch bar to shut down ENGLISH Operating Instructions ACCU 450... -
Page 13: Battery Care
Battery care Servicing and storage: Observe LED display: • Keep the charger unit only in red + green = battery charging dry rooms. 2x green = battery charged • Charge the battery in warm 2x red = battery/charger and dry rooms. unit defective. • Protect the battery and char Contact Support. ger unit from the effects of the weather! •... -
Page 14: Scraper Blade Exchange
Scraper blade exchange/spare parts 1. Make sure that the battery and safety key have been removed from Replacement scraper blade the device Artikel No. EAAK 450 before you EAN 9002766100483 handle it! Replacement battery Artikel No. AK 36V EAN 9002766036997 3. Loosen the 4 screws on the bottom of the device. Replacement 2. You will require a replace- 4. Replace the used scraper charger ment scraper blade and a blade with the new one. -
Page 15: Technical Data
Technical data TIPS: Snow clearing capacity: 150 m Battery: 36V, 2,6Ah, Lithium-Ion battery • Clearing just after snowfall makes the work easier Operating time: approx. 30 min./battery • For heavy wet snow or very Charging time: approx. 90 min. deep snow, use half the Snow clearing width: 450 mm snow clearing width Throwing distance: 45 m • You can use a non-stick spray for wheels and... -
Page 16: Warranty
Warranty You have the right to the statutory ger unit connected to the power warranty period for your quality supply system also maintains the product. This is governed accor charge status of the battery over ding to the regulations valid in the a prolonged period. Winter hardy L it h iu m I o n battery for the respective countries. whole year! • To preserve the manufacturer’s The battery has also been optimi... -
Page 17: Service & Support
Service & Support Register your device Your satisfaction is particularly important to us! … simply online at Therefore please direct your con www.sonneck.com/service cerns in complete confidence to within 10 days of purchase. Warranty services the ServiceCenter: You can also fill out the regist ration card and drop it into the Pospischil Tools GmbH nearest postbox. Spare parts such as Lütowgasse 12–14...
