FlashPoint 128 MCI Overlay Driver (Cont.)
Standard
Allows setting the default video standard to NTSC or PAL.
Type
Allows setting the video type to Composite, S-video or RGB.
Source
Although most FlashPoint Intrigue cables supply RGB as Source 0 and
Composite/S-video as Source 1, developers may wish to design custom
cables for their application and thus customize the video sources of Source 0
and Source 1.
FlashType
Allows selection between None, Universal and Auto (for the Kodak
CCD4000).
FlashDelay
Choose the number of video fields to delay between firing the flash and
grabbing an image.
Grab Align
Specifies which video field to start a grab.
Field Replication
When selected, will replicate the captured even field of video into the odd
field.
Video Control
The default settings for the ‘Video Control’ section are correct for most
applications, however, a brief explanation of the various controls may help in
fine tuning the driver for particular applications.
Freeze on overlap
Freeze the entire video window when another window overlaps part of
the video.
Clip on overlap
Freeze only the section of video that is covered when another window
overlaps part of the video.
