FPG Features (Cont.)

Setup Menu

The Setup menu contains the control panels to set the
video parameters, the video grab parameters, the flash
type and delay and the general board configuration
.

Video Setup Menu

Brightness, Contrast
Sets the relative level of brightness and contrast for the
live video input.
Saturation, Hue
Sets the relative level of color hue and saturation for the
live video input. These values are used with
Composite and S-video inputs only.
Sharpness
Sets the sharpness level of the incoming live video (used
with Composite input only).
Auto Iris
Sets the voltage level on the DC Iris output to control
the iris in the camera lens.
Video Standard
Selects between NTSC (North America) and PAL
(European) video input standards.
Input Type
Selects between RGB, Composite and S-video inputs.
Green Sync
Selects Sync on Green for RGB inputs.
