When Scale Video is not
selected, X Center and Y
Center pan around the full-
resolution video image
with the video window as
the viewable area.
54
FPG Features (Cont.)

Configuration Setup

Scale Video
Selects between scaling a full frame of video to the
video window, or using the video window as a
viewer to the full frame video signal. See Page 59
for examples of this function.
Keep Aspect
Selects between maintaining proper aspect ratio for the
video window, or allowing an arbitrary size for the
video window. See Page 60 for examples.
Field Rep
When selected, will replicate the captured even field of
video into the odd field. This is useful in minimiz-
ing motion artifacts or when a flash has illuminated
the even field at a different intensity than the odd
field.
One Field
Mono Comp
Alt Sources
X Center/Y Center
In the default mode, when Scale Video is selected from the main Setup menu,
X Center and Y Center will move the entire video image side to side (X),
or up and down (Y). Some video devices may show a thin black line on
the left edge of the video window. Adjusting the X Center can shift the
video image to compensate for this.
JPEG Q
Adjusts the relative Q factor for compression when saving a JPEG image.
Values range from 1-100, with 100 being highest quality and 1 being
poorest. The default value of 75 produces good results in most cases.
