TRENDnet TEW-644UB User Manual

Wireless n usb adapter
Hide thumbs Also See for TEW-644UB:
Table of Contents

Advertisement

Quick Links

Download this manual
--

Advertisement

Table of Contents
loading

Related Manuals for TRENDnet TEW-644UB

Summary of Contents for TRENDnet TEW-644UB

  • Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. 0560 TRENDnet tímto prohlašuje, že tento TEW-644UB je ve shodě se základními požadavky a dalšími Česky [Czech] příslušnými ustanoveními směrnice 1999/5/ES.
  • Page 4 Por medio de la presente TRENDnet declara que el TEW-644UB cumple con los requisitos esenciales y Español cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. [Spanish] ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ TRENDnet ΔΗΛΩΝΕΙ ΟΤΙ TEW-644UB ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ Ελληνική ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.

  • Page 5: Table Of Contents

    TABLE OF CONTENT Introduction ....................1   Overview of this User’s Guide ................1   Unpacking and Setup .................. 2   Unpacking ......................2   Setup ........................2   Connecting the USB Extension Cable ..............2   Software Installation ................... 3  ...

  • Page 6: Introduction

    INTRODUCTION Congratulations on your purchase of this Wireless N USB Adapter. This manual contains detailed instructions regarding the operation of this product. Please keep this manual for future reference. With the Wireless N USB Adapter, a desktop or laptop computer can communicate with another computer wirelessly.

  • Page 7: Unpacking And Setup

    This section provides unpacking and setup information for the Wireless N USB Adapter. Unpacking The box should contain the following items: One TEW-644UB Wireless N USB Adapter One Driver & Utility CD-ROM One Multi-Language Quick Installation Guide One USB extension cable If any item is found missing or damaged, please contact your local reseller for replacement.

  • Page 8: Software Installation

    SOFTWARE INSTALLATION This section describes how to install the driver and utility for the Wireless N USB Adapter. Windows Based Utility Installation 1) Insert the Utility and Driver CD-ROM into your computer’s CD-ROM Drive and then click Install Utility. 2) Select the desired language and then click Next.
  • Page 9 3) Follow the InstallShield Wizard Instructions 4) Click Finish. 5) Reboot your PC and plug in the Wireless N USB Adapter into an available USB slot on your computer.

  • Page 10: Wireless Utility Setting

    WIRELESS UTILITY SETTING The user can configure the wireless settings using the Wireless Adapter Configuration Utility. Double-click the utility icon that appears in the taskbar. The Wireless Adapter Configuration Utility is divided into five sections: Link Info, Configuration, Site Survey, Profile, WPS and About. Link Information This is the default screen after launching the Utility program.

  • Page 11: Configuration

    Link Quality: Shows the link quality of the Wireless N USB Adapter with the Access Point when operating under Infrastructure mode. Signal Strength: Shows the wireless signal strength of the connection between the Wireless N USB Adapter with the Access Point. Data Rate: Shows the statistics of data transfer, and the calculation is based on the number of packets transmitted and received.
  • Page 12 Open System and Shared Key Open System and Shared Key requires the user to set a WEP key to exchange data with other wireless clients that have the same WEP key. The following will be activated when Open, Shared Key or Auto is enabled: Default Key: select one of the 4 keys to use.
  • Page 13 WPA/WPA2 EAP-TLS If using the WPA/WPA2 EAP-TLS authentication method, please select the Encryption type for TKIP or AES then select the WPA/WPA2 Certificate from drop down list.
  • Page 14 WPA/WPA2-PSK If using the WPA-PSK/WPA2-PSK authentication method, please select the Encryption type for TKIP or AES then enter the Passphrase key.

  • Page 15: Site Survey

    Site Survey This screen allows the user to scan for available wireless networks (wireless clients and Access Points). It also allows the user to establish wireless communications with an available wireless network. Select any one of the wireless networks by double-clicking on it or clicking on the “Connect”...

  • Page 16: Profile

    Profile The user can create and manage the created profiles for home, work or public areas. By double-clicking on one of the created profile, the setting will adjust to the specific setting such as SSID, channel, and encryption as saved by that particular profile.
  • Page 17 Add: Adds a new profile. The following screen will appear. Enter the Profile Name, SSID and select the Wireless Mode, Authentication and Encryption then click Apply to save the new profile. Remove: Delete the selected profile.
  • Page 18 Edit: Edit an exist profile. The following screen will appear. Edit the SSID and select the Wireless Mode, Authentication and Encryption then click Apply to save the profile. When the Profile name was changed, a new profile will be added in the list.

  • Page 19: Wps

    Wi-Fi Protected Setup (WPS) is an optional certification program from the Wi-Fi Alliance that is designed to ease the task of setting up and configuring security on a wireless network. There are two methods used in the WPS as below instruction. Push the button on my access point Using the WPS configuration with the “Push the button on my access point”...
  • Page 20 4) If the WPS configuration was successful, the follow window will show on. 5) If the WPS configuration was failed, the follow window will show on.
  • Page 21 Enter a PIN into my access point Using the WPS configuration with the “Enter a PIN into my access point” method, the configuration steps as below: 1) Selected the “Enter a PIN into my access point”, the PIN will be show on the button of the windows.
  • Page 22 3) Selected a wireless access point or router which one will be connecting then click the Next button start the WPS configuration. If the “Automatically select the network” was checked, the setup step will be skip.
  • Page 23 4) If the WPS configuration was successful, the follow window will show on. 5) If the WPS configuration was failed, the follow window will show on.

  • Page 24: About

    About This screen displays information about the Wireless N USB Adapter, such as the Driver and Utility version. When a new version of the utility becomes available for upgrade, users will be able to identify by version numbers.

  • Page 25: Mac Os X Software Installation

    MAC OS X SOFTWARE INSTALLATION This section will lead you to install the driver and utility of the TEW-644UB on your Apple computer with Mac OS X 10.4/10.5. Before insert the TEW-644UB into USB port of your computer, please install the Utility Program first.
  • Page 26 Mac OS X. 4. Browse the contents of TEW-644UB_MAC_OS_X and select MacOS_X_10.4 or MacOS_X_10.5 folder whichever applicable on your Apple computer 5. Double click on the install.pkg to start the installation of the TEW-644UB driver/utility.
  • Page 27 6. Click “Continue” button. 7. If prompted to, select a destination volume to install the utility and then click Continue. 8. Click “Install” button.
  • Page 28 9. Input your password then click “OK” button. 10. Click “Continue Installation”. 11. Click “Restart” to reboot your computer.
  • Page 29 12. Insert the TEW-644UB on your Mac. The USB Wireless Utility will automatically appear. If the utility does not appear, you will find the “USBWirelessUtility” icon in the Dock menu. Click on the USB WirelessUtility icon to start the TEW-644UB configuration.

  • Page 30: Uninstall

    Uninstall OS X 10.5 1. Double click on the “Unistall.pkg” start the un-installation of the TEW-644UB driver/utility. 2. Click “Continue” button. 3. Click “Install” button.
  • Page 31 4. Input your password then click “OK” button. 5. The computer will restart when the installation is done, click “Continue Installation” start the software installation. 6. Click “Restart” to reboot your computer. 7. Disconnect the adapter from your computer.
  • Page 32 OS X 10.3/10.4 1. Double click on the “Uninstall.command”. 2. Enter the password for your computer and hit “Enter”. 3. The utility is now uninstalled from your computer. Disconnect the adapter from your computer.

  • Page 33: Configuration

    CONFIGURATION Link Status Status: Shows the current connected SSID and BSSID, which must be the same on the wireless client and AP in order for communication to be established. Current Channel: Shows the current channel for communication. Link Speed: Shows the current linking speed for transmit and receive. Throughput: Shows the current throughput.
  • Page 34 Profile The user can create and manage the created profiles for home, work or public areas. Add: Adds a profile, user can enter the necessary information required for accessing Access Points or Wireless Router. Edit: View and edit the existing profile. Remove: Deletes the selected profile.
  • Page 35 Add Profile: Select any one of the available wireless networks from list then click ADD PROFILE button to add on to the profile list. Advanced Setting Enable TX Burst: Enable/Disable the TX Bust function on the TEW-644UB to improve data transmit throughput. Enable PSP XLink: Enable/Disable the PSP XLink Mode on the TEW-644UB.
  • Page 36 Using the WPS configuration with the “PBC” method, the configuration steps as below: 1. Push the WPS configuration button on your wireless access point or router. 2. Click the PBC button start the WPS configuration. 3. If the WPS configuration was successful, the follow window will show on. 4.
  • Page 37 1. Enter the PIN code into the WPS “Clint PIN number” of you wireless access point or router then click the Start PIN button, the wireless access point or router will start the WPS configuration process. 2. Selected a wireless access point or router which one will be connecting then click the PIN button start the WPS configuration.
  • Page 38 4. If the WPS configuration was failed, the follow window will show on. About This screen displays information about the TEW-644UB, such as the Wireless Utility Version, NIC Driver Version and MAC Address. When a new version of the utility becomes available for upgrade, users will be able to identify by version...

  • Page 39: Limited Warranty

    Three years If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item. All products that are replaced will become the property of TRENDnet.
