Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Preliminary Notes Before Installation This is a High Efficiency, Flueless, Inset Live Fuel Effect appliance. It provides radiant and con- vected warmth both efficiently and safely utilising the latest type catalytic converter burner tech- nology. This fire incorporates a combustion monitoring system (Oxygen Depletion Sensor). It must not be adjusted or put out of operation. -
Page 4: Table Of Contents
Section Contents Page No. Section Contents Page No. Important Notes Cable Fixing Appliance Data Fuel Bed Installation Requirements 10.0 Fitting Decorative Hood/Frame Room Sizing 11.0 Testing and Commissioning Site Requirements 11.1 Operating the Appliance Ventilation 11.2 Spark Failure Unpacking the Appliance 11.3 Setting Pressure Component Checklist... -
Page 5: Appliance Data
APPLIANCE DATA Gas Group G20 Natural Gas CAT I2H Inlet Pressure 20 mbar Max Energy Input Gross 2.6 kW 2.35 kW Max Gas Rate 0.25 m3/h Min Energy Input Gross 1.5 kW 1.35 kW Pilot Energy Input Gross 166 W 150 W Setting Pressure High... -
Page 6: Ventilation
SITE REQUIREMENTS (continued) Opening DEPTH must be 90 mm or greater. Opening DEPTH includes any plaster, cement or infill/back panels that form part of the installation. In the event that the fire is sited in a disused or unserviceable fireplace served by a natural draught flue, any existing under grate draught device should be sealed off to prevent loss of heat or creation of draughts. -
Page 7: Unpacking The Appliance
UNPACKING THE APPLIANCE Stand the carton the right way up, cut the strapping bands and remove the top endcap. Read ALL these instructions before continuing to unpack or install this appliance. Remove the box containing the cast front fret, and the box containing the ceramic coals and other ceramic firebed components. -
Page 8: Gas Supply Routes
GAS SUPPLY ROUTES The gas supply may enter the fire over the hearth or by concealed connection behind the fire. Following preparation of the fixing method, the concealed gas supply (if required), can now be installed. When the opening is ready for installation the gas supply can be routed. If the gas pipe has been sleeved the ends of the sleeving must be sealed. - Page 9 INSTALLATION METHOD 2 (recessing into a non-combustible wall) This method allows for installation of the appliance with the rear part recessed into the inner leaf of a cavity wall. This should enable a standard fire surround and back panel/hearth set to be fitted to the wall with the fire presented naturally in a flush fitted manner.
- Page 10 INSTALLATION METHOD 3 (timber framed buildings) Where removal of any part of a timber frame is undertaken the structural integrity of the wall must be retained. The advice of your local building control officer should be sought. If the prop- erty is under any NHBC warranty it is also advised that their advice on this kind of modification is sought.
-
Page 11: Gas Supply
INSTALLATION METHOD 3 (continued) 50mm Rockwool to Insulate Cavity Superlux Box: 12mm thick, Fireplace Backpanel, External Dims; Height 670mm, non-combustible Width 529mm, Depth 152mm Rockwool Insulation 50mm sides and rear 100mm top Cavity Box Inner cavity Leaf Outer Cavity Leaf Installation as per method 2 (recessing into a wall) When setting the appliance into the wall find a suitable position between frame timbers and open up the hole. -
Page 12: Cable Fixing
CABLE FIXING When using this method for fixing, the minimum depth of the opening must be increased from 145 mm to 175 mm. This is to allow for the eyebolts and a space for the cable 380 mm tensioning. Drill four holes as shown in the diagram and fit the fibre 200 mm rawlplugs. -
Page 13: Fitting Decorative Hood/Frame
FUEL BED (continued) Fit the glass door assembly with the 4 screws provide in the positions indicated. Ensure that the screws are tight- ened so as to achieve a good seal between the glass frame gasket and the firebox. The fire is designed to operate correctly with the sup- plied components according to the instructions. -
Page 14: Spark Failure
11.2 SPARK FAILURE The gap between the spark electrode and the pilot should be 3 - 5mm to produce a good spark. There should be no need to adjust this. If under any circumstances the piezo electric spark fails, the pilot cannot be lit manually. SETTING PRESSURE 11.3 To commission the appliance, the burner pressure must... -
Page 15: Cleaning The Coals
13.1 CLEANING THE CERAMICS Remove the fire front and place to one side. Remove the hood. Remove the glass door assem- bly. Remove the ceramic components. Gently clean in the open air with a soft brush. Be care- ful not to create dust from the ceramics. Where necessary replace damaged components with genuine spares. -
Page 16: Testing For Firebox Leakage
13.4 CATALYTIC CONVERTER (continued) Position gas sample probe directly over the catalyst via the outlet louvre, in the centre of the upper firebox. Ignite the fire as per the operating instructions, and run at high setting for 15 minutes. Record the carbon dioxide (CO2) concentration and then the carbon monoxide (CO) concentration as displayed by the analyser - also noting the units in which the values are expressed. -
Page 17: Troubleshooting Guide
14.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire - check isolators are open. Pipe work blockage or kink - rectify. Air not fully purged - re-purge supply or wait longer. Spark earthing to metal work - check gap is correct. Blocked pilot - check and replace where necessary. -
Page 18: User Instructions
USER INSTRUCTIONS Section Content Page No Important Notes Fire Front Clearances to Combustibles Ventilation and Room Size Operating Instructions Combustion Spillage Monitoring System Cleaning Ceramics Servicing 10.0 List of Replacement Parts IMPORTANT NOTES The installation and Servicing of this fire MUST only be carried out by a competent person (such as a CORGI registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manu- facturer's instructions. -
Page 19: Clearances To Combustibles
FIREFRONT This fire is supplied with a particular style of fire front. Use of the fire front will ensure an ade- quate airflow under the firebox for the correct functioning of this appliance. Compliance with safety standards cannot be guaranteed when another style of front is used. CLEARANCES TO COMBUSTIBLES A non-combustible shelf may be fitted to within 100mm of the top edge of the fire frame. -
Page 20: List Of Spare Parts
OPERATING INSTRUCTIONS - continued To turn to the PILOT position from the HIGH or LOW positions, press the control knob in, and return to the pilot position and release. To turn the fire OFF, keep the knob pressed in, return to the off position and release.
