Setup and Function

The „Shake" function
With the shake function of the smartLAB® move you can check your battery status and your daily goal
status. The three LED's (green, orange, red) on the bottom of the device show you the relevant status. The
meaning of the different options will be described below.
Battery Status
When you shake your device twice up to down with the logo showing up in a fast movement it will first
show you your battery status blinkig 3 times after another:
LED display
Green, orange and red light up
Orange and red light up
Red lights up
Daily Goal Status
After the battery status was displayed the device will show you your current daily goal status (LED lights
up for a longer time):
LED display
Red LED
Orange LED
Green LED
Notice: The definition of the daily goal depends on your portal provider. Please ask your provider for more
information.
If all three LED's light up your daily goal is set on zero. This is possible when no goal is provided by the
system or the device has not been set by the gateway (e.g. when exanging the battery).

Exchanging the batteries

To exchange the batterie you need to open the battery lid with a coin in direction of the arrow (pict 5).
Remove the battery carefully and insert the new battery into the battery lid with the plus side to the lid.
Then close the lid by using the coin again.
Notice: After a battery exchange you need to reset your device by the gateway. Please make sure to be near
the gateway when exchanging.
Step counter and batteries need to be disposed of according to
local regulations.
Battery status
Battery is fully charged
Battery is half charged
Battery is quarter charged
Daily goal status
You are far away from your goal
You have reached minimum 85 % of your goal
You have reached your goal
pict 5
