Storm DJI Flamewheel F450 RTF Manual

DJI Flamewheel F450 RTF package
DEVO 7 Setup for NAZA V2 / Lite
Step 1 - Set Fixed ID on the transmitter
Skip this part if you have a brand new DJI F450 RTF Package,
!
we have already done before we ship.
1.
Make sure you have NOTHING plugged into BATT port on the RX701 receiver.
2. On the transmitter, goto MODEL > FIXED ID, press ENT, if it is showing the code, then
press ENT again, press one more time, it's showing RUN, press "R" to choose NO, press
ENT again, it's showing FIXID, press "R" again to choose OFF, then press EXT, and turn off
transmitter.
3. Plug the bind plug into Batt port on the RX701 receiver, with this plug still in BATT port
and power up the drone, you will see receiver flashing red slowly, then means old code
has been erased, unplug drone battery and remove this bind plug.
Now you need to activate the Fixed ID function.
4.
Turn on transmitter, then make sure Throttle Stick is all the way down, all trimming is
neutral, both corner FMOD switch and Throttle Switch is off (pointing backward) and all
switches on the transmitter pointing upward, then turn off transmitter.
5. Connect drone battery, the receiver will start flashing, place drone on flat surface.
6. Turn on transmitter, you should see black box running on the transmitter screen, do no
touch anything or you will break the searching mode.
Do not touch anything (around 7-10 seconds) until transmitter stop flashing and you will
7.
see the RX701 receiver have solid light, that means binding has completed.
On the transmitter, goto MODEL > FIXED ID, turn it ON, then press DN button to confirm
8.
the code, then press ENT, and press ENT again to confirm, it will ask you to RUN, choose
YES and press ENT. From now on your receiver is bound to this memory on your DEVO 7.
- 1 -
