Storm LOKI X3 User Manual

Storm racing drone srd130 with cleanflight controller

Hide thumbs

page of 20

/ 20
Bookmarks

Quick Links

Download this manual

Storm Racing Drone SRD130

with CleanFlight Controller

USER MANUAL

V1.0

Need help?

Do you have a question about the LOKI X3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Storm LOKI X3

Page 2 DISCLAIMER Please read this disclaimer carefully before using this product. This product is a hobby with motors but not a toy which is not suitable for people under the age of 18. By using this product, you hereby agree to this disclaimer and signify that you have read them fully.
Page 10: Fpv System
FPV System The video transmitter has up to 40 different video channels, available to avoid interference with other channels. If two or more drones are flying at the same time, try to select different video frequency to avoid video interference. The bigger different in video frequency between drones, the less interference generated.
Page 11 Binding with Radiolink AT9 Transmitter If your drone cannot response to the radio controller, the connection between radio controller and receiver may lost and you can try to re-bind them by following the procedure. (Skip Step One if it is already Purple light) Press the tiny black button on the side of the receiver twice with small screwdrivers to make LED indicator turns PURPLE to enter S.Bus...
Page 12 Radio Controller Parameters - Radiolink AT9 Transmitter If you reset your radio controller (AT9) setting, you can apply the setting below: 1) Press and Hold the controller wheel (With wordings 2) [STK-MODE] = 2 (Stick Mode) “PUSH”) to unlock the manual. Press and Hold [LockScreen] = 30s (Time to lock screen) Mode Button to go into basic menu page 3) [TYPE] = AIRCRAFT...
Page 13 [1] [TIME] = 10:00 [1] [MODE] = UP [1] [ON][1] = ST-THK (Using Throttle Stick to start the timer) [1][ON] [2] = 15% ( Move the indicator over the value, set throttle stick to around 15%, Press and hold “Push” button to recognize the throttle value and move the wheel to change the arrow sign) [1][RESET] [1] = SwH (Using Switch H to responsible...
Page 14 Binding with FrSky Taranis X9D Plus Transmitter Turn on your Taranis X9D Plus transmitter, goto "Model Setup" (Press MENU and PAGE button once). In the "Internal RF" section, choose Mode = D16, Channel Range = CH1-16, Receiver No. 01, and then click "Bind", the transmitter will start beeping.  Power up the X4R-SB receiver (Connect battery to the drone) while holding the Bind button.
Page 15 Connect your FrSky Taranis X9D Plus transmitter to your PC / Mac via USB cable and the controller screen will show “USB Connected”.  Click ! to read your radio controller profile Your radio controller profile will be loaded on the screen, always click ! to save your existing profile before you make any changes, incase thing goes wrong.
Page 16 Press and hold “PAGE” for 1 second, you’ll enter Telemetry screen, press “PAGE” again cycle thru telemetry screens. VFAS : Battery voltage RSSI : Radio signal Curr : Current drainage VFAS- : Lowest battery voltage RSSI- : Lowest radio Curr+ : Max. current drawn T1 : Timer (Auto start with throttle, Switch H to reset) VFAS: Battery voltage...
Page 18 Avoid using bare hand to grab motors when tightening propellers or you may cut your fingers!! Propellers are very sharp, we use a damp cloth here to help to grab the motor so we can tighten to propeller locknut. Avoid using bare hand to grab the motor or you may cut your fingers! Copyright@2016 HeliPal.com.
