23. Trouble shooting - Service Mode (INSTART)

Model Name
Serial Number : SKYJY1107
S/W Version
MICOM Version
BOOT Version
FRC Version
IR LED Version
EDID Version (RGB)
EDID Version (HDMI)
Chip Type
Wireless Host Ver.
Wireless B/B Ver.
Wi-Fi Version
Wi-Fi Mac
MAC Address
ESN Num. : LGE-TEST==XXXX000001FD91
Local Dimming Ver.
Debug Status
UTT : 5
APP History Ver.: 26524
PQL DB : LGE_EF_LGT10_ALLxN42
10. Sync Level
: You can control sync level of Component, HDMI input source. (Range is from 0 to 31)
11. Wireless Ready
: You can set RF Group, Media-box type and get some information about Wireless Diagnostics.
14. Local Dimming
: You can check current Local Dimming binary file version. When you upgrade latest F/W, you can re-download with using this menu.
If TV system doesn't support Local Dimming Function, you can't see this menu.
Copyright ⓒ 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
START
IN
: GLOBAL-PLAT2
: 02.05.00.01
: 3.01.7
: 1.01.62
: 1.30
: c7
: 0.01
: 0.01
: BCM 3549
: 0.00.0
: 0.00.0
: 1.0
: 00:ED:91:C6:C7:92
: FE:22:56:43:00:55
: 0x0703
: EVENT
▶
1. Adjust Check
2. ADC Data
3. Power Off Status
4. System 1
5. System 2
6. Model Number D/L
7. Test Option
8. External ADC
9. Spread Spectrum
10. Sync Level
11. Wireless Ready
12. Stable Count
13. ODC Test
14. Local Dimming
• IN-START mode displays various TV
system information and supports useful
functions for engineer.
• Each of menu has sub-menus for detail set-
up
1. Adjust Check
: Refer to next page.
2. ADC Data
: This menu supports manual ADC
adjustment for COMP 480i/COMP 1080P/RGB.
3. Power Off Status
: You can check previous power-off history
with this menu.
4 & 5 . System
: There are various sub-menus for TV system
setting.
6. Model Number D/L
: You can change TV System's model name
& Serial Number manually.
7. Test Option
8. External ADC
: You can adjust external Analog-to-Digital
Converting Level when you have external
devices as Master.
9. Spread Spectrum
: To enable FRC spread spectrum function and
set detail value as spreading percent, period.
