View Media 100 Player Installation Manual
Thank you for purchasing the UCView View Media 100 player. Please match the items on the
list below with the items in the box. If any item is missing or damaged, please contact your
UCView Media Networks sales representative immediately.
One (1) VM 100 player
One (1) Power supply
One (1) Cable cord
One (1) or two (2) antenna(s)
Note: View Media 100 player will arrive with one (1) or two (2) antenna(s), depending on the model.
Installing your VM 100 Player:
1) Remove packaging - make sure box and plastic casings are stored away in case a
return is necessary.
2) Plug-in the LAN/Ethernet cable into the VM 100 player.
3) Plug-in your video source, HDMI or DVI cable, into the VM 100 player and the monitor.
4) Plug-in the Power cable into the VM 100 player.
LAN/Ethernet
Note:
* A DVI to VGA converter will enable you to plug in a VGA screen.
* A DVI to HDMI converter will enable you to plug in two HDMI cables.
HDMI
transmitting high-definition video and high-resolution audio.
DVI
(Digital Video Interface): A cable which is capable of providing digital video signal.
VGA
(Video Graphics Array): An analog cable which enables connection from your
computer to a monitor.
LAN/Ethernet:
network, such as PCs and routers.
5) Attach the antenna(s), which is included with your package, to your VM 100 player.
HDMI
(High-Definition Multimedia Interface): A single cable which is capable of
A LAN/Ethernet cable can connect to devices over a local area
18425 Napa St. Northridge, CA 91325
DVI
Power
www.ucview.com
1-818-772-8255
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for UCView View Media 100
Summary of Contents for UCView View Media 100
- Page 1 One (1) or two (2) antenna(s) Note: View Media 100 player will arrive with one (1) or two (2) antenna(s), depending on the model. Installing your VM 100 Player: 1) Remove packaging - make sure box and plastic casings are stored away in case a return is necessary.
- Page 2 Note: Image depicts the back portion of the VM 100 player. Please connect your cable to the appropriate receptacle labeled below. 6) Once the appropriate cables are securely attached to both the VM 100 player and the monitor, firmly press the power button, which is located in the front of the VM 100 player.
- Page 3 1) Move over to your workstation to access your management tool. 2) Locate the PC you will be using to monitor your digital signage network. 3) Open up an Internet browser. 4) Type in portal.ucview.com in the address bar. 5) A login screen will appear.
- Page 4 6) Type in your username. 7) Type in your password. 8) Once you press enter, the main screen displaying EZBoard, Campaigns & Ads, etc., will appear. 9) Make modifications, release messages, and insert apps as you wish. 10) Press Log Out on the upper right hand corner to exit. 11) See user manual or video tutorials for more information.
