UCView View Media 50 Installation Manual

UCView
Reaching Your Audience
Thank you for purchasing the UCView View Media 50 player. Please match the items on the list
below with the items in the box. If any item is missing or damaged, please contact your UCView
Media Networks sales representative immediately.
• One (1) View Media 50 player
• One (1) Power supply
• One (1) Cable cord
• One (1) Antenna

Installing your VM 50 Player

Remove packaging - make sure box and plastic casings are stored away in case a return is
1
necessary.
2
Plug in the LAN/Ethernet cable into the VM 50 player.
3
Plug in your video source, HDMI or DVI cable, into the VM 50 player and the monitor.
4
Plug in the Power cable into the VM 50 player.
5
Attach the antenna, which is included in your package, to your VM 50 player.
LAN/Ethernet
1
HDMI
HDMI (High-Definition Multimedia Interface):
transmitting high - definition video and high - resolution audio.
DVI (Digital Video Interface):
signal.
VGA (Video Graphics Array):
computer to a monitor.
LAN/Ethernet: A LAN/Ethernet cable can connect to devices over a local area
network, such as PCs and routers.
VIEW MEDIA 50 PLAYER
INSTALLATION MANUAL
DVI
A single cable which is capable of
A cable which is capable of providing digital video
An analog cable which enables connection from your
Power
