Elliott Studio Arts Series Sixty-Six Model 66-001p Vacuum Tube Reference Stereo Preamplifier Table of contents: Introduction………………………………………………………………………….3 Placement and hookup……………………………………………………………..3 Things to consider…………………………………………………………….…….4 Maintenance…………………………………………………………………………6 Vacuum tube replacement………………………………………………………….6 Pictorial diagram……………………………………………………………………7 Specifications………………………………………………………………………..7 Warranty……………………………………………………………………………..8 Contact information and Registration form……………………………………..9... -
Page 3: Introduction
Welcome to the wonderful world of vacuum tube audio! Vacuum tube audio components can add a life to music that only the most expensive solid-state gear can match. The Elliott Studio Arts 66-001p stereo preamplifier was designed to give many years of musical satisfaction and add fun to your listening experience. -
Page 4: Things To Consider
12au7a and use only 12au7a and Preamplifier Preamplifier ECC99 tubes ECC99 tubes 66-001p 66-001p Hand Built with Pride Hand Built with Pride in the USA in the USA The preamp has 5 unbalanced stereo line inputs, 1 unbalanced stereo phono input, dual unbalanced stereo outputs and 1 unbalanced stereo recording output. - Page 5 This is OK, most amplifiers will clip with as little as 1.5 volts – the 66-001p will put out a full 6 volts p – p without distortion. This gain structure was chosen to reduce noise and put the volume pot in a more linear region of its travel for average listening levels.
-
Page 6: Maintenance
ground and is there to protect you if there is a fault that could energize the chassis of the component and cause electrocution. Maintenance of your amplifier Tube equipment requires periodic maintenance to ensure optimum performance. Cleaning – Keep the tubes clean and free of dust and oily deposits. Remove and clean with a soft towel and a mild solvent if necessary (every couple of years). -
Page 7: Pictorial Diagram
Figure 2 – Vacuum tube layout Specifications: *Non-inverting design *Unbalanced inputs / unbalanced outputs *Fully point to point construction with high temp wiring and silver solder *Hand-matched high quality parts used throughout *FET / Triode cascode phono stage input topology for high gain and low noise *MM RIAA passive equalized phono input (47K input impedance, 15pf capacitance) *RIAA stage gain = 45dB -S/N ratio: 76dB reference -40dB in @ 1kHz, +5dB record out, no weighting... -
Page 8: Warranty
The customer must pay shipping fees to Elliott Studio Arts for warranty service. Elliott Studio Arts will not cover under warranty any repairs of our products due to neglect, abuse, accident or misapplication. Elliott Studio Arts reserves the right to determine what constitutes neglect, abuse, accident or misapplication. -
Page 9: Contact Information And Registration Form
Feel free to contact us for questions regarding repairs, service information, set up instructions or praise.. -Specifications, parts and design subject to change without notice- ……………………………………………………………………… Elliott Studio Arts Product Registration Form Model # Serial # Purchase Date Dealer / Direct...
