Elliott Studio Arts Series Sixty-Six Model 66-100 100 watt / channel Stereo power amplifier Table of contents: Introduction …………………………………………………………………………3 Primer on tubes……………………………………………………………………..3 Placement and hookup……………………………………………………….…….4 Initial setup and power-up…………………………………………………….…..4 Maintenance…………………………………………………………………………5 More things to consider……………………………………………………….…...6 Pictorial diagram…………………………………………………………….……..8 Specifications.…………………………………………………………………..…...8 Warranty……………………………………………………………………….…….9 Contact Information & Registration form…………………………………….. 10... -
Page 3: Introduction
You will be pleased with the amount of detail and resolution you will hear from your recordings through the 66-100. You may find that you can listen longer and at subjectively louder levels with tubes, as there’s less listener fatigue. -
Page 4: Placement And Hookup
Placement and hookup of your shiny new amp Place the amplifier on a level non-resonant surface with plenty of ventilation above and behind. Tube amps won’t survive in cramped equipment racks or enclosed spaces; they need to breath. Also, why would you want to hide it away? You can bask in the warm orange glow of the tube filaments. -
Page 5: Maintenance
control clockwise. Switch to the next position clockwise, this is for V2. Again, the pointer on the switch points to the tube you’re adjusting. Set to 40 ma. Set each output tube in this manner. Go back and re-set each tube again because each adjustment slightly affects the others. -
Page 6: More Things To Consider
sources. You can leave the filter out of the fan for slightly better airflow and cooling at the expense of a little more dust accumulation and fan noise Now some more things to consider as you’re enjoying the music: Feel free to try different brands of tubes, they all have a different sound and you may like some better than others. - Page 7 100. Check your input cables for continuity. The use of a high quality isolation transformer is recommended to remove ground loops. Do not float the AC ground on the 66-100 or any other grounded component in your system in an attempt to isolate...
-
Page 8: Pictorial Diagram
Figure 1 Specifications: *Output Power: 100 watts per channel into 4 ohms Ultralinear; 65 watts per channel (optional) Triode *Distortion @ 1 KHz, 100 Watts/ 4 ohms: THD .889%, THD+N .895% *Frequency Response: 20 hz to 20 Khz +/- 3dB *Class AB operation, 40ma initial bias (adjustable) *Input sensitivity: 1.5 v p-p for full output *Non-inverting... -
Page 9: Warranty
The customer must pay shipping fees to Elliott Studio Arts for warranty service. Elliott Studio Arts will not cover under warranty any repairs of our products due to neglect, abuse, accident or misapplication. Elliott Studio Arts reserves the right to determine what constitutes neglect, abuse, accident or misapplication. -
Page 10: Contact Information & Registration Form
Feel free to contact us for questions regarding repairs, service information, set up instructions or praise.. -Specifications, parts and design subject to change without notice- ……………………………………………………………………… Elliott Studio Arts Product Registration Form Model # Serial # Purchase Date Dealer / Direct...
