This Installation Manual includes instructions on how to mount the S2000-SP1 Executive Relay
Module (hereinafter referred to as the module) and to prepare it for operation.
The description of the module and rules of setting up and operating this one can be found in
S2000-SP1 Instruction Manual (which is a part of the standard delivery and can also be
downloaded from the website of the Bolid Company at the address of www.bolid.com, in the
Products Section).
1 SAFETY PRECAUTIONS
- There are no potential hazard circuits within the module.
- Do SHUT OFF the device power before mounting, wiring, or maintaining the
module.
- Mounting and maintaining the module MUST be performed by qualified engineers.
2.1 The module is to be mounted within cabinets, on walls, or on other constructions within
premises closely to connected executive devices at places protected against atmospheric
fallouts, mechanical damage, and unauthorized access.
2.2 Wiring the module is performed in accordance with Figure 4.
www.bolid.com
EXECUTIVE RELAY MODULE
S2000-SP1 ver.1.56 INSTALLATION MANUAL rev.0
S2000-SP1
INSTALLATION MANUAL
ORION ISS
1
Advertisement
Table of Contents
Related Manuals for bolid S2000-SP1 ORION ISS
Summary of Contents for bolid S2000-SP1 ORION ISS
- Page 1 The description of the module and rules of setting up and operating this one can be found in S2000-SP1 Instruction Manual (which is a part of the standard delivery and can also be downloaded from the website of the Bolid Company at the address of www.bolid.com, in the Products Section).
- Page 2 3.1.7 Variant 2. Apply the Mounting Pattern (page 7) to the wall. Drill three Figure 2. Opening the front cover holes (A, B and C or D) 3.1.8 Insert wall plugs to the holes. www.bolid.com S2000-SP1 ver.1.56 INSTALLATION MANUAL rev.0...
- Page 3 4.3.1 Connect the main power supply to the terminals “+U1” and “0V” of the module. 4.3.2 If necessary, connect the optional power supply to the terminals “+U2” and “0V” of the module. 4.3.3 Please do not confuse the polarity connecting the module to the power supply (supplies). www.bolid.com S2000-SP1 ver.1.56 INSTALLATION MANUAL rev.0...
- Page 4 It is advisable to use battery backed power supplies of RIP-12 or RIP-24 series manufactured by the Bolid Company 4.4 Close the module front cover as shown in Figure 6. Tamper Switch S2000-SP1 Jumper to connect EOL resistor 620 ХР2 ХТ1...
- Page 5 1.5 s. Pauses between pressings should be 0.1 to 0.7 s. 5.6.2 If the module operates correctly, its READY indicator shall flash five times per second while relays “1” to “4” shall be activated one-by-one for a short time. www.bolid.com S2000-SP1 ver.1.56 INSTALLATION MANUAL rev.0...
- Page 6 PC with installed Orion Pro software, it should be assigned to a unique network address and be set properly (see the Instruction Manual for the S2000-SP1). ZAO NVP Bolid, 4 Pionerskaya Str., Korolev 141070, Moscow Region, Russia Phone/fax: +7 495 775-7155 Email: info@bolid.ru,...
- Page 7 S2000-SP1 ver.1.56 INSTALLATION MANUAL rev.0...
- Page 8 BOLID ONE YEAR LIMITED WARRANTY Bolid Company and its divisions and subsidiaries («Seller»), 4 Pionerskaya Str., Korolev 141070, Mos- cow Region, Russia warrants its security equipment (the «product») to be free from defects in materials and workmanship for one year from date of original purchase, under normal use and service. Seller’s obligation is limited to repairing or replacing, at its option, free of charge for parts or labor, any product proven to be defective in materials or workmanship under normal use and service.
