Ebac Pro 100 Series User Manual

WARNING – THIS APPLIANCE MUST BE EARHED
FITTING REPLACEMENT PLUG
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your own plug,
proceed as follows:
The wire which is coloured Green and Yellow must
be connected to the terminal in the plug which is
marked with the letter E or by the Earth Symbol or
coloured Green and Yellow. The wire which is
coloured blue must be connected to the terminal in
the plug which is marked with the letter N or
coloured Black. The wire which is coloured Brown
must be connected to the terminal which is marked
with the letter L or coloured Red.
You must dispose of the non rewireable plug once
it has been removed from the flexible cord. It is
dangerous to attempt to insert the plug into any
electrical socked elsewhere in the house. If the
flexible cord becomes damaged it must be replaced
by an identical cord.
TECHNICAL SPECIFICATIONS
SPECIFICATION
POWER REQUIREMENTS
Height
Weight
Min Operating Temperature
Max Operating Temperature
Water Extraction (24hrs) 32°C / 90%RH
Max Operating Temperature 32°C / 90%RH
Max Running Cost
Fuse Rating (UK)
Pump – max head
•
Do not remove the front or rear panels
•
This machine should only be serviced by qualified Ebac personel or other persons having technical
competence servicing refrigeration equipment, following the instructions in the Ebac service manual.
•
Ebac service manuals and spares lists are available upon request by contacting your local Ebac
distributor.
• Never operate the unit in a bathroom or swimming pool area.
•
Do not use the machine if the power cord or cabinet are damaged.
•
Do not poke objects into and of the grilles on the machine
•
Do not cover or obstruct the air inlet or outlet.
•
When running, the noise level of this machine is less than 70dba
•
This machine complies with the electromagnetic compatibility 1992 regulations.
•
This machine has been manufactured in the United Kingdom.
CHANGING THE FUSE
Only 13 Amp fuses that are ASTA approved to
BS1362 should be used.
The fuse cover must
replacement of the fuse. In the event of the fuse
cover being lost or damaged, the plug must not
be used until a replacement is obtained.
Replacement fuse covers, which must be
coloured BLACK, are obtainable from electrical
retailers.
PRO 100
230-240V/50Hz/1 Phase 230-240V/50Hz/1 Phase
670 mm
Width 355 mm
Depth 380 mm
22 kg
1 °C
35 °C
15 litres
325 W
2.4 A
13 A
3m
be refitted after
PRO 200
800mm
510mm
480mm
40kg
1 °C
35 °C
24 litres
500W
2.5 A
13 A
3m
HEAVY DUTY
Pro 100/200 Series
DEHUMIDIFIER
USER MANUAL
TPC - 253
