IP Power 9820 User Manual

Power distribution unit (pdu) & remote power control (rpc) system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IP Power 9820
User Manual
Firmware Version: 1.0B
Date Released: SEP. 2014
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9820 and is the answer not in the manual?

Questions and answers

Related Manuals for IP Power 9820

Summary of Contents for IP Power 9820

  • Page 1 IP Power 9820 User Manual Firmware Version: 1.0B Date Released: SEP. 2014 - 1 -...
  • Page 2 Warning: Any changes made to this equipment without permission may cause damages to the device! IMPORTANT NOTICE 1. IP Power 9820 was designed for indoor use, we carry no responsibility for possible damages caused by outdoor use, especially in the rain.

  • Page 3: Table Of Contents

    Table of Content WELCOME ......................5 Introduction ..............................5 PRODUCT OVERVIEW ..................6 Features ................................. 6 Specification ..............................7 Minimum System Requirements ......................... 7 Package Contents ............................8 INTERFACE DESCRIPTION ................9 Front View..............................9 Rear View ..............................11 From Left side to Right side ........................11 SETTING UP USER DEVICE ................
  • Page 4 OTHER WAY TO CONTROL ................81 By IR Remote Controller ..........................81 CGI HTTP Commands ..........................82 Telnet Control ..............................84 FAQ : ........................85 - 4 -...

  • Page 5: Welcome

    9820 supports Auto Ping , Time Scheduler which is more suitable for factory / office / home automation . 9820 can auto control one outlet as DI get status change ( Dry contact ) Besides power control , through 9820 , user can also check the power usage WH ( watt per hour ) , current consumption of each port , voltage and external Temperature value , LOG information &...

  • Page 6: Product Overview

    Webpage : easy to Control ON/OFF& get meter value Android APP “ IP QR Code : create QR code of the 9820 IP address 15) Time Schedule - can pre-set a suitable time to turn power on / off automatically .

  • Page 7: Specification

    24) Specific software developed by Aviosys and provided free of charge : SDK available : HTTP Command IP Power Center - for control multiple Aviosys IP devices in same software CNT software ( Cross Network Technology )- allows user eliminate set up work on any Router without port forwarding , simply Plug &...

  • Page 8: Package Contents

    Package Contents 1. 9820 Unit x 1 2. IR Remote Power Control 3. 9820 Installation 4. WiFi Antenna X 1 pcs The power inlet SPE is C20 . Please double check the power cable compatible Input for 10/15/20 amp current loading ( depends on user device power consumed ) .

  • Page 9: Interface Description

    Another one is for USB Flash Drive saving current & temperature sensor data as CSV files Please do not connect more than 1pc. USB Camera to 9820. WiFi - Signal light WiFi Signal light in flash Green . The Indicator shows the WiFi signal transfer status.
  • Page 10 5- 6 seconds then release. There are THREE beeps response ( short –- mid long – short ) which means reset successfully and 9820 will be rebooted itself ( one beep after reboot ) and most information go back to default setting .

  • Page 11: Rear View

    The Power switch turns on the input power. Breaker Reset : This is Fuse protection to prevent electrical surges from damaging the unit. The 9820 comes with one spare fuse in the unit. 8 Outputs: There are 2 different outlets by different model : 9820-S : IEC 320 C13 .

  • Page 12: Setting Up User Device

    6. ) Go to page #16 for software installation guide – use IP Edit to log in the webpage of 9820. Note: To change the network setting for WiFi connection ( if user Router without WPS function ) , please go to page # 19 to setup the WiFi connection manually .

  • Page 13: Installing Software

    4.) All the available downloads for the 9820 will be shown 5.) Download the required software – IPEdit.exe - by clicking on the download button. Then user can select to connect 9820 by LAN or by WAN / WAN- WPS - 13 -...

  • Page 14: Connection By Wifi- Wps ( Wifi Protection Service )

    Please refer following steps to setup WiFi –WPS connection Step 1: Power on the 9820 - only connect power in but do not connect the LAN cable , user will hear one short beep in 40 seconds means 9820 boot successfully Step 2: Press the “WPS button”...
  • Page 15 Step 5: There is one short beep in 45 seconds which means 9820 boot up successfully . Step 6 : Execute IPEDIT.exe . The device name with mean the WiFi IP address of this device . There is WiFi IP address of 9820 shown in IPEDIT.exe as following : If can not see the IP in the area of Local Devices of IPEDIT.exe.

  • Page 16: Connection First By Lan -Network Cable Then Setup For Wifi Connection

    Step 1: Connect the LAN cable to 9820 .The LAN cable should be connected to a Router / HUB + Router. Step: 2 : Connect power cable to 9820 and Power on the 9820 .There is one short beep in 45 seconds after 9820 power up .The short beep means 9820 boot up successfully Step 3 : After hear the one short beep , please execute IPEDIT.exe .
  • Page 17 “ IPEDIT “ LAN connect by IP Search software IP Edit is a search tool designed to search, configure, or access the IP Power 9820 from a local networked computer. IP Power 9820 Default Login / Password Default IP: 192.168.1.168 (When no DHCP is apparently)
  • Page 18 Select the 9820 device and the device information will pop up on the right. Check to see that the gateway IP and the IP Address (9820) match user current network. If not, type in the correct information, then hit the submit button to save changes.
  • Page 19 EX: The IP of user PC is 192.168.100.122. If the “ Local IP Address “ at WiFi Info is 192.168.100. x ( X can the value of 1~252 ) , user PC can get into the webpage of 9820 .
  • Page 20 WiFi Connection after log in webpage by LAN : After log in 9820 , to connect by WiFi , please go to Network  WiFi Survey to add the WiFi router in to 9820 WiFi profile . 1) As go to WiFi Survey page, there is a list for the available WiFi router near 9820 . Please select the one plan to use and click “...
  • Page 21 As connection successful , the page will turn to “WiFi Information “ and show the information . Now user can see the new WiFi IP address which can be found by software IPEDIT. Then user can remove the LAN cable and re-log in the 9820 by IPEDIT re-search of above WiFi IP address.

  • Page 22: Internet Setup

    Forwarding in user router. Please check user Router owner’s manual .  If just want to control each port ON or OFF in IP Power 9820, user can install our own software “ IP Power Center “ and enable IP Server function as following . Please refer to the “IP Power Center “...
  • Page 23 *User device must be Port Forwarded for the login screen to appear. EX: The 9820 device name as Cathy , and user can search the device easily after log in the webpage and change the default name from “ IP_POWER ” to Cathy 5.) After user have connected to user device, type in the Login and Password for user device...

  • Page 24: Web Interface

    1.) Open Internet Explorer type in the IP Address of the device followed by the : sign. For example: http:192.168.122.188:9258 192.168.122.188 – IP Address 2.) Once user have typed in the IP address of the 9820 and it is ready to use. The default username and password for the 9820 Username : admin...
  • Page 25 The IP Power 9820 Console consists of seven main sections which will be explained in details below.  Device name & to Hide or Display the setting column at left ( for smart phone control )  Information : Time , Temperature , Voltage , DI status , Outlet name & Current Amp value .

  • Page 26: Device Name

    Display or Hide the left setting section : For smart phone user to control 9820 easily , user can select to show or to hide the left control section by pressing the blue area near device name for smart phone control :...

  • Page 27: Information

    Information : In this section, there is information of Time, Temperature , Voltage , DI status , Outlet name & Current Amp value . Time : This section showed the time. - 27 -...

  • Page 28: Io Control

    Fahrenheit , C = Celsius ). IO Control : The IO Control Section allows user to directly / automatically control the outlets of the 9820 as well as schedule daily, weekly, and monthly power cycles. There are 5 sections : Control , Schedule , Ping , Timeline and History.
  • Page 29 Original Status as OFF : Press “Apply” then the outlet will turn ON  OFF ON. Group Setting : User can control more than one outlet by press the right side “Apply “ button . For safety concern , each port of 9820 will turn ON or OFF one after one . - 29 -...
  • Page 30 For example : The following pictures means that Power #1 & #4 is ON , Power #2 & #3 is OFF The following 3 pictures shows that after press the power cycle with 5 seconds setting , the outlet “ Power1 “ will to turn off for 5 seconds and then turn ON . The power cycle action will execute after press the “...
  • Page 31  Email Alarm Setting : Use can enable /disable the email alarm here .The email alarm section allows 9820 to notify user by following situation : Receive Email with Current , Voltage & Temperature info. as 9820 device boot up.
  • Page 32 Current limit：This section allow user to enable the protection as over current and setup the maximum value. The range of each outlet is 0~ 10 amp . As over the setting value, 9820 will keep beeping for several times and then turn OFF the power output automatically.
  • Page 33 Voltage limit：This section allow user to set up the maximum value of current limit. The range is at 60~ 260 V AC . As over the setting value, 9820 will keep beeping for several times and then do the setting ON/OFF/None by user.
  • Page 34 2. Digit Input (DI) Setting : Enable /disable the email / beep alarm as DI status change Setup Auto Control on one outlet to be ON/OFF /NONE as DI (Dry Contact ) status change . Do the Action at one time only For example : Outlet #1 is OFF .
  • Page 35 Over Current Protection ( Max. Current limit ) There has “ over current protection” in 9820. As the Amp value of power number is over the setting or over the maximum value 10 Amp, 9820 will automatically turn off that power A in few seconds .
  • Page 36 Schedule In this section , user can see the setting schedule list first up to 29 rules . To setup each schedule , please press “ Schedule Setting “ , then user can get the “ Schedule List “ page as following : Please Click the button to switch between “...
  • Page 37 One the scheduler has been setup , hit the “ ADD No.:X Power Schedule “ button and you will see your setting located on the bottom of the Action section . Edit a schedule event : Step1 : Please select the Rule you want to edit in Scheduler Table. Then the button “ADD No.:X Power Schedule “...
  • Page 38 Ping The ping function allows the device to automatically Ping an IP Address to act as a watchdog to make sure the device getting Pinged is working properly. Please Click the button to switch between “ Ping Setting “ & “ Ping List “ . User can hide the setting section by press “ Ping List “ There are 8 rules for Ping .
  • Page 39 : Execute Action by either one IP Host failure as setting 2 pcs IP Host : Execute Action by both IP Host failure as setting 2 pcs IP Host Single : 9820 will Ping one IP address. As the IP fail times up to the setting times . Action (ON/OFF/RESET) will be activated .
  • Page 40 OR : 9820 will Ping 2 IP address. Either one IP fail times up to the setting times. Action (ON/OFF/RESET) will be activated . AND : 9820 will Ping 2 IP address. Both IP fail up to the setting times.
  • Page 41  Ping failure action : When the number of Ping Failures times have been reached. The device can be set to “ ON , OFF or Reset “ function Reset: Can set up the time gap of OFF to ON. The “ Sec “ section is for action as Reset only. Select the action as ping failure as no responding.
  • Page 42 Display Interface:  A. Display chart : User can select the chart which can be display by pressing the top 6 buttons : Meter , Outlet 1& 2 , Outlet 3 & 4 , Outlet 5 & 6 & Outlet 7 & 8 and Voltage Ex: Select Meter , Outlet 3 &...
  • Page 43  B. Meter section : In this section , user can get the channel name , the consumed current of each port show in chart & in word , and setup the max. limit current of each output directly. Channel Name Green area: Consumed current It showed 1Amp in this picture.
  • Page 44 X axis - horizon , it show date and time . Y axis – vertical , it shows current value in ampere of each port . Light Blue Bar at left : Show the date , time , outlet name and limit information . Dark Blue Bar at Right : Show the max.
  • Page 45 History : To use this function , please do setup the T first To see this section display, please do use IE9.0 or above or Firefox . and set resolution at 1280*768 . There are 4 sections in this section: Time Period 8 color Round signs , Duration Time, Total Power Usage information , Recently Record , Data list ,...
  • Page 46 Time period It show the calculate time period for the 3 chart : Power History of each outlet , Voltage and Temperature. 8 Round signs & Line Color information : User can select the 8 round signs represented output 1 ~ 8 to display the power usage history line of each port and total 8 ports.
  • Page 47 D. 3 charts : Power Usage History, Voltage and Temperature. D-1 Power History : The power history chart show the consumed current ( Ampere ) of each outlet in different color in the chart. User can just click the round circle sign and show to get the current line in chart . There are 8 color round signs on the top side show the total WH ( Watt –Hour) , Watt and Voltage of each power consumption in select time.
  • Page 48 The below 2 buttons are to control the Minimum value of X axis. D-3 Temperature chart The Temperature chart show the temperature near 9820 . The sensor is at front panel in red. To adjust the display range at X Axis , user can move the 2 buttons at right sides The above 2 buttons are to control the Maximum value of X axis.

  • Page 49: Network

    The Network Section allows user to setup LAN –Ethernet or WiFi settings and WPS setting . There are 4 sections : Setting , WiFi Info , WiFi Survey and WPS . Setting : This Setting section is showed the network status of 9820. Please select one connect ion – Either LAN or WiFi connection but not both connected after finish setting .
  • Page 50  Default Gateway The gateway is the door for Internet connection , Email , DHCP UPNP NET Server . Please select correct Gateway LAN or WAN for the user to log in 9820 form Internet and use above functions .
  • Page 51 As the IP from DHCP Service of user`s router will be changed by router . 9820 will remember last IP of 9820 assigned by user`s router in “Last DHCP state “ for information C. PPPOE : Only support for Ethernet connection .
  • Page 52 User can only revise the Host Name under DHCP mode. This is also the default setting for fast LAN connection solution. As the IP from DHCP Service of user`s router will be changed by router . 9820 will remember last IP of 9820 assigned by user`s router in “Last DHCP state “ for information ...
  • Page 53 Please refer page 19 to setup the WiFi connection. User can add different router in profile list for 9820 to switch. User can get the Router name , signal strength , MAC address , WiFi IP address , Channel and most WiFi connection information in this section .
  • Page 54 This section is to arrange WiFi connection. 9820 will auto search the WiFi Router nearby and also their information as boot up , 9820 user can just select the router and type the password to connect with your WiFi router and make connection easily.
  • Page 55 Step 2 : 9820 will auto get the most information of your router and you just need to type the password to connect with the WiFi router then click “ Apply “ Then you will see the Router name add in to “Profile list “...
  • Page 56 EX: The IP of your PC is 192.168.100.122. If the “ Local IP Address “ at WiFi Info is 192.168.100. x ( X can the value of 1~252 ) , your PC can get into the webpage of 9820 .
  • Page 57 Step 4 : Press the WPS buttons of WiFi AP ( Router) soon in few seconds Step 5: After few seconds , there are short 2 beeps which means WPS connection successfully. There are messages updated during the configuration in “ WPS status “ section : As WPS connection successfully , there is “Configured “...
  • Page 58 Which means the WPS connection fail and there is one long beep mean the connection fail. Please try again. ) Step: 6 : User can see the WPS connection in section “ WiFi Info “ & “ WiFi Survey “ of Network In “...

  • Page 59: Application Settings

    Email In email section , there is 3 function : Receive Email with Current , Voltage & Temperature info. as 9820 device boot up. Email alarm as over setting at Current , Voltage and temperature. Notice : To send out the email successfully , please double check the setting of user DNS .
  • Page 60 The 9820 allows user to send from @gmail or @hotmail or @yahoo.com account .  SMTP Server: This is the mail server of sender . If user select @gmail or @hotmail account as SMTP Server , 9820 will fill the SSL & Port automatically ...
  • Page 61 Setup the limit range of each port. And click “Apply” to save the settings. C. POP3 Control User can control each port turn ON or turn OFF by email. The command format is limit . Please enable the function first . - 61 -...
  • Page 62 Mail Number : For 9820 to search as command mail in the number of your email receiver latest . EX : setup 20 that 9820 will check the latest 20pcs email in receivers mail box for the 9820 command mail ...
  • Page 63 Command format : IPPOWERCTRL:TAG=Test;POWER1=OFF;POWER2=OFF;POWER3=OFF;POWER4=OFF ;POWER5=ON; POWER6=ON; POWER7=ON; POWER8=ON There are 2 section of the command IPPOWERCTRL:TAG=Test This is command part. Beside the tag message part ( like Test on above example) user can change in setting section , the other command must be CAPITAL and are fixed content . 2.
  • Page 64 Email example :  Execute email command by “ Subject “ Execute email command by “ Body “  - 64 -...
  • Page 65 DDNS The DDNS section allows user to setup the 9820 with a DDNS server (i.e. www.dyndns.com). After the server has been setup correctly, enter the necessary information into the 9820 DDNS settings. Note : The DNS server will have extra change as apply new account.
  • Page 66 Get the QR code of 9820`s IP address. IP Server & CNT Setting The IP SERVER allow 9820 to be easily accessed on the internet by our IP Power Center or IP EDIT. With this feature anyone can find there device with no problems.
  • Page 67 QR code of 9820 : User can create own QR code of the IP information of 9820 ( LAN / WIFI / Internet), and scan / record in user QR code APP for quick search or log in 9820 .
  • Page 68 Please select the QR code of IP Information from Internet, LAN, WAN & IP Server. And then press “Apply to create new QR code. # Internet: It will create QR code with the Internet IP of the environment of 9820 . ( need port forwarding ) .
  • Page 69 Please go to our online IPEDIT : www.myipedit.com Them please select “ Server 2 “ and type the device name ( if change) or 9820. - 69 -...
  • Page 70 This section allow user to connect USB Webcam ( with UPNP function , M-JPG / YUV format ) and view the webcam in 9820 webpage directly. To work with 9820, the USB Webcam need to support UPNP and video as M-JPEG or YUV format to view the area near 9820.
  • Page 71 USB Storage 9820 can save the data of Current and temperature . It create CSV files by time , date week , month , year . The file will be save by date - 71 -...

  • Page 72: System Setting

    Operator : The operator can only control the setting of “ IO Control “ section but can not see other page of 9820 . Viewer: The viewer can only see the “ IO Control “ section but can not see other page of 9820. - 72 -...
  • Page 73 Please click “Apply “ button after change the account name / password Host Connection Interval The setting is for user to control the 9820 response time for IO sensor like ????? the time of speedy , timeline update . Default 1000ms ( = 1 second)
  • Page 74 Internet Load Factory Default & Restart System In this 2 section , user can click one button to set back the setting to default or restart the 9820 without device nearby user side. Note : The factory default setting of 9820 IP is assigned by DHCP. It will change the IP if load factory defaults .
  • Page 75 System Information In this section , user can get the system information and change own Language display in 9820 webpage in “ Language Setting “ : - 75 -...
  • Page 76  Language Setting : User can change the display Language - two customize Language and build own Language by simple procedure . Please refer the following two procedures : Change the text in SDK & Language Customize procedure . A. Change the Text in SDK : A-1 .
  • Page 77 Example: <message msgid="email title" msgstr="E-mail Setting" /> The webpage will display the Text in yellow background as above example Notice : To avoid any update problem , please ONLY change the Texts between the two “ marks after msgstr . A-4.
  • Page 78 Notice : There are 5 languages setting in this section :  ENG : Can’t change  Chinese : Can’t change  Simple Chinese : Can’t change  Other 1 : Can revise as user’s own Language  Other 2 : Can revise as user’s own Language Only “Other 1”...
  • Page 79 B- 5. Then the webpage will show that you have selected 5 files . Press “Apply “ to execute the update procedure B- 6 . Then the webpage will display “ user select 5 files “ to update. Press “ Apply “ to execute the replacement .

  • Page 80: System Log

    System Log In this section , user can get the 9820 system operation information and send the information to assign Server IP address ( not support name ) . The system information will be deleted after 9820 device power reboot.

  • Page 81: Other Way To Control

    Other way to Control By IR Remote Controller To control 9820 by IR remote power controller we supplied, please use 8 buttons in this remote controller : Power button , button #1~# 8  Enable remote controller : Press Power button one time and 9820 will response a short beep which mean the remote control function enable .

  • Page 82: Cgi Http Commands

    CGI HTTP Commands CGI Commands allow you to easily integrate the 9820 with other systems and programs. Please read the instructions carefully on how to use the Http:// Commands To use http:// Commands open up a web browser and type in the command that you would like to use.
  • Page 83 2.4 To get Current ： getcurrent http://192.168.1.18/set.cmd?cmd=getcurrent System return： CGI Command : Data follows c61=0.000000, c62=0.000000, c63=0.000000, c64=0.000000, c65=0.000000, c66=0.000000, c67=0.000000, c68=0.000000, temp=22.700001 C61 to C68 means 8 currents ，temp is temperature （as Celsius ） 2.5 To get temperature （Celsius）: gettemp http://192.168.1.18/set.cmd?cmd=gettemp System return：...

  • Page 84: Telnet Control

    Telnet Control User can get the Telnet command by -h - 84 -...

  • Page 85: Faq

    A5: If the WiFi connection for 9820 lost or the WiFi AP router damage, 9820 can not get the WiFi IP then it will change it`s IP to fixed IP address as 192.168.1.168 . User can not see the IP by IPEDIT as the Gateway is still at WiFi .
  • Page 86 “ and click “Apply” . Step 3 : Connect user PC and 9820 to a router by LAN. Then reboot 9820 (MUST DO) . After 45 seconds with a long beep, user can found the LAN IP of 9820 by IPEIDT.exe Q6: How can I reset to default: A6 : Please use tiny pin head and keep pressing the button “RESET for 5 seconds at least and...
