TWO LINE CALLER ID SPEAKERPHONE
•
Two phone lines can be conferenced for 3 Way conversations
•
Caller ID shows you caller's name and number on line 1 or line 2
•
Hands-free speakerphone with LED indicator and volume control
•
80 name and number caller ID memory
•
Tone / pulse switchable dialing
•
Automatic time and date display
•
One-touch caller ID call back of received numbers
•
13 memory telephone (3 one-touch & 10 two-touch)
•
Wall / desk usable
•
Requires 4 size "AA" batteries (not included) or the supplied AC adaptor
Remember to connect the supplied AC adaptor before use.
To use the caller ID feature of this phone, you must subscribe to caller ID service
from your phone company.
To use the two line and conference functions, you need to have 2 incoming phone
lines from your phone company and use the supplied AC adaptor.
NOTE: READ AND FOLLOW THESE INSTRUCTIONS BEFORE USING YOUR TELEPHONE
IB-PH568-WM-E-040506(RTT).pmd
MODEL PH-568
OPERATING INSTRUCTIONS
1
IB-PH568-WM-E-040506
7/4/2006, 4:28 PM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Durabrand PH-568
Summary of Contents for Durabrand PH-568
-
Page 1: Operating Instructions
To use the two line and conference functions, you need to have 2 incoming phone lines from your phone company and use the supplied AC adaptor. NOTE: READ AND FOLLOW THESE INSTRUCTIONS BEFORE USING YOUR TELEPHONE IB-PH568-WM-E-040506(RTT).pmd MODEL PH-568... -
Page 2: Table Of Contents
Connecting the Telephone Line Cord ... 8 To Connect a Two-line Telephone Jack ... 8 To Connect Two Single-line Telephone Jacks ... 8 If You Want to Use This Phone Only as a Single-line Telephone ... 8 Customizing Your Phone ... 9,10 Telephone Basics Making Calls ... -
Page 3: Important Safety Instructions
1 0 . Do not use the telephone to report a gas leak in the vicinity of the leak. 11. Do not allow anything to rest on the telephone cord. Do not locate this product where the cord will be damaged by persons walking on it. -
Page 4: Battery Safety Instructions
Incorrect reassembly can cause electric shock when the appliance is subsequently used. 1 3 . Installation of batteries should only done by an adult for safety. SAVE THESE INSTRUCTIONS IB-PH568-WM-E-040506(RTT).pmd IB-PH568-WM-E-040506 7/4/2006, 4:28 PM... -
Page 5: Important Telephone Company & Fcc Information
(i.e., RJ11C or RJ14C) in the packaging with each piece of approved terminal equipment. c) A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. -
Page 6: Important Telephone Company & Fcc Information
- Consult the dealer or an experienced radio/TV technician for help. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IB-PH568-WM-E-040506 IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM... -
Page 7: Checking The Package Contents
As you unpack this set, make sure you have the following items in the package. HANDSET COILED HANDSET CORD 4-WIRE STRAIGHT TELEPHONE LINE CORD (black) AC ADAPTOR IB-PH568-WM-E-040506(RTT).pmd TELEPHONE BASE 4-WIRE SHORT STRAIGHT WALL CORD (for wall mounting use) 2-WIRE STRAIGHT TELEPHONE... -
Page 8: Location Of Controls
Speakerphone microphone AC adaptor jack (AC 9V) L1 or L1/L2 jack (L1=line1) L2 jack Hook switch (L2=line 2) IB-PH568-WM-E-040506(RTT).pmd Delete button Menu button Dial/Adjust button Mute button Flash button Redial/Pause button Line 2 button & Line 2 indicator Speakerphone button &... -
Page 9: Settings
Only use the supplied AC adaptor. • During a power failure, the unit will work as a standard telephone on the line 1, but the caller ID, speakerphone, line indicator, hold, LCD display features will not work, unless the batteries are installed. Line 2 is not available. -
Page 10: Connecting The Telephone Line Cord
Single-line telephone jack (RJ11C) 4-wire or 2-wire telephone line cord If you want to use this phone only as a single-line telephone Single-line telephone jack (RJ11C) 4-wire or 2-wire telephone line cord For this connection, you can only use LINE 1 and no need to use the AC adaptor if you have installed the batteries. -
Page 11: Customizing Your Phone
You may need to set up the LCD contrast level, language, area code, time and date, and dialing mode for your telephone when you power your phone for the first time or when you move to an area that has a different area code. Area code setting is necessary because the phone must distinguish local or long distance calls to properly dial calls from the Caller ID list. -
Page 12: Customizing Your Phone
Caller ID when your phone rings (twice or more). NOTE: Please do these settings quickly before the setup returns to normal standby mode (about 15 seconds). IB-PH568-WM-E-040506(RTT).pmd (Setting up LCD contrast, language, area 1 2 3 4 5 LCD contrast level... -
Page 13: Telephone Basics Making Calls
To hold both lines, press the HOLD button. To resume to talk with one line, press the corresponding line button. To resume to talk with both lines, press the CONFERENCE button. IB-PH568-WM-E-040506(RTT).pmd Slide the handset VOLUME control (loud or normal). Slide the SPEAKERPHONE VOLUME control (on the right side of the phone). -
Page 14: Telephone Features
FLASH button on your telephone, you will put on hold the party you are having conversation with and be able to talk to the new caller, after you finish the conversation with the 2nd caller, press the FLASH button to return to the 1st call). -
Page 15: Caller Id Operation
CALLER ID OPERATION This telephone has a Caller ID feature and if you subscribe to Caller ID service, the Caller’s telephone number (if available), Name (if your caller ID service includes), Time, Date, and called line will be displayed between the first and second ring of the phone. The phone stores the data of the last 80 calls received including “UNAVAILABLE CALL”... -
Page 16: Desk Use / Wall Mounting
3. Connect the telephone line cord. If you use wall mounting, in order to avoid the exposing of the long telephone cord, please use the supplied short wall cord, plug one end into the LINE 1 (L1 for L1/ L2) jack, route the cord into the channel at the phone back, and the other end into the wall jack. -
Page 17: Trouble Shooting
Check if the AC adaptor is connected properly. • Check if the straight line cord you used is the attached 4-wire line cord. When you connect the telephone and a two-line telephone jack, you must use the attached 4-wire line cord. IB-PH568-WM-E-040506 7/4/2006, 4:28 PM... - Page 18 Static can cause this message. • If this condition persists, contact your local telephone company to ensure that there is no problem with your phone line. • To erase ALL call records, make sure the phone is not in use, press the DELETE button and hold for 3 seconds, the display will show “DELETE...
-
Page 19: Ib-Ph568-Wm-E
During the initial 1 year period after original purchase, we will service the set that is returned to LENOXX ELECTRONICS CORP., prepaid, at no charge. After the initial 1 year period expires, we will exchange, at no charge, any part that is defective, but will charge for the cost of labor, return postage paid by LENOXX.
