- Page 1 Blood Pressure Monitor Semi-Automatic Blood Pressure Monitor 6012 Instruction Manual PLEASE NOTE: THIS MEDIC L INSTRUMENT MUST BE USED CCORDING TO INSTRUCTIONS TO ENSURE CCUR TE RE DINGS. Questions? Call DC toll free at 1-800-232-2670...
-
Page 2: Table Of Contents
6012 Semi- utomatic Blood Pressure Monitor Table of Contents Introduction Warnings and Cautions bout Blood Pressure What is Blood Pressure? What is a Normal Blood Pressure? What Influences Blood Pressure? Does Blood Pressure Vary? What is Hypertension? Can Hypertension be Controlled? -
Page 3: Introduction
This device offers clin- ically proven accuracy and has been designed to be user friendly. Read this booklet thoroughly before attempting to use your new ADC ®... -
Page 4: Bout Blood Pressure
Caution: To avoid any possibility of accidental strangulation, keep this unit away from children and do not drape tubing around your neck. Caution: The standard material used for the bladder and tubing is latex-free. ttention: Self-measurement means control, not diagnosis or treatment. Unusual values must always be discussed with your doctor. -
Page 5: Does Blood Pressure Vary
Even repeated blood pressure measurements taken without adequate rest between read- ings will alter your blood pressure as the vessels in your arm engorge with blood. Many of these influences are only temporary or short term, though chronic (long term) exposure to some factors may result in permanently elevated blood pressure levels. -
Page 6: Can Hypertension Be Controlled
3.6 Can Hypertension Be Controlled? Although essential hypertension cannot be cured, it can usually be controlled by altering lifestyle (including diet), adopting a program of exercise, stress management, and, where neces- sary, with medication under a doctor's supervision. To help reduce the risk of hypertension, or keep it under control, the American Heart As- sociation (AHA) recommends the following: •... -
Page 7: How Should I Record My Blood Pressure
(9”-13” / 22.86 - 33.02cm). Note: Do not force the cuff con- ON/OFF nection into the opening. If the Memory cuff is too small, call ADC for button further information. A larger cuff is available. Quick release valve T Connector... -
Page 8: Setting Up Your Blood Pressure Monitor
• Selecting the correct cuff size is of extraordinary importance. The cuff size is dependent upon the circumference of the arm (measured in the center). The permissible range is printed on the cuff. If your cuff does not fit properly, contact ADC. Note: Only use clinically approved DC cuffs! •... -
Page 9: Fitting The Cuff
6.3. Fitting the cuff a) Position the cuff flat on a table with the hook and loop adhesive side down. Pass the end of the cuff through the (Figure 1) metal ring so that a loop is formed. The hook & loop closure must be facing outward. -
Page 10: Measuring Procedure
6.4. Measuring procedure After the cuff has been appropriately positioned, the measurement can begin: a) Turn on the instrument by pressing the On/Off/Memory button. Many icons will appear in the display for 2 seconds. 3 short beeps follow to indicate that the instrument is ready. A blinking «0»... -
Page 11: Inflating Further
6.5. Inflating further If the cuff is not inflated sufficiently, the measurement is stopped after a few seconds and a flashing arrow pointing upwards appears in the display. It is then necessary to inflate at least 20 mmHg higher than the previous value. The instruction to inflate further can appear several times if the pressure is still not sufficient. -
Page 12: Error Messages/Troubleshooting
7. ERROR MESS GES/TROUBLESHOOTING If an error occurs during a measurement, the measurement is discontinued and a corresponding error code is displayed. (example: Er 1) Error No. Possible Cause(s) Er 1 The systolic pressure was determined but afterwards the cuff pressure fell below 20 mmHg. -
Page 13: Warranty
(Quiet conditions)! If fluctuations are larger than 15 mmHg, and/or you hear irregular pulse tones on several occa- sions, consult your doctor. Contact ADC ® if there are technical problems with your blood pressure monitor. Never attempt to... - Page 14 Never open the device! This will invalidate the manufacturer warranty. Periodic recalibration Sensitive measuring devices must from time to time be checked for accuracy. We recommend a periodic inspection of your monitor every 2 years. Contact ADC ® about the need for an accuracy check.
- Page 15 9. W RR NTY The blood pressure monitor (6012) is warranted for 5 years from date of purchase. This guaran- tee includes the instrument and the cuff. The warranty does not apply to damage caused by im- proper handling, accidents, improper use, or alterations made to the instrument by third parties.
-
Page 16: Technical Specifications
11. TECHNIC L SPECIFIC TIONS Weight: 284 g (with batteries) / 1.37lbs. Size: 3.5” (W) x 6.5” (L) x 8” (H) 119mm (W) x 146mm (L) x 60mm (H) Storage temperature: –20°C to +50°C Humidity: 15% to 90% relative humidity maximum Operation temperature: 10°C to 40°C Display:... -
Page 17: How To Contact Us
Inspected in the U.S. . Made in China 55 Commerce Drive tel: 631-273-9600, 1-800-232-2670 Hauppauge, NY 11788 fax: 631-273-9659 U.S. . www. dctod y.com DC (UK) Ltd. em il: info@ dctod y.com Unit 6, PO14 1TH United Kingdom IB p/n 93-6012-00 rev 4 english...
