Baby Control Digital BC-200 User Manual

Digital apnoe alarm systems
Hide thumbs Also See for BC-200:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Use Manual
CE1011
Baby Control
User Guide and Warranty for
BC-200 one sensor pad,
•
BC-210 two sensor pads,
•
BC-230 three sensor pads
•
BC-230i four sensor pads for twins
•
Digital Apnoe Alarm Systems.
Dear Customer!
Congratulations to you and your newborn baby and to your wisdom in purchasing the "Baby
Control Digital". Not only will your child be sleeping peacefully!
Some of the features why it worth to choose Baby Control :
Large Sensor Pads*: the size of the sensor pad is 30 x 50 cm. Depending on the product having 1, 2,
•
3 or 4 (twins) sensor pads. The product with 3 sensor pads is able to cover the whole resting place of
the baby, even large cots.
Extra Sensor Pads:* Extra sensor pads can be used at the baby's temporary resting-place. You have to
•
carry only the control unit.
• Excellent Lateral Sensitivity
Usable for all mattress models.
•
Digital movement display*: luminous display can be clearly seen at night.
•
Digitally adjustable sensitivity by 9 degrees*: with the control button you can setup the sensitivity
•
level (threshold) of the control unit.
Event Memory*: The control unit stores the event of the last 10 minutes before the alarm.
•
,
Important phone numbers, addresses:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BC-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Baby Control Digital BC-200

Summary of Contents for Baby Control Digital BC-200

  • Page 1 CE1011 Baby Control User Guide and Warranty for BC-200 one sensor pad, • BC-210 two sensor pads, • BC-230 three sensor pads • BC-230i four sensor pads for twins • Digital Apnoe Alarm Systems. Important phone numbers, addresses: Dear Customer! Congratulations to you and your newborn baby and to your wisdom in purchasing the “Baby...
  • Page 2 • Two Years Guarantee* • *- only Baby Control possess these features in the market! Product Packages: A BC-200 package contains: 1 BC-103 control unit, 1 BC-101 sensor pads, A BC-210 package contains: 1 BC-103 control unit, 2 BC-101 sensor pads,...

  • Page 3: Control And Display

    Functionality The „BABY CONTROL DIGITAL” continuously checks your baby’s breathing and movements to confirm the absence of a possible danger. The BABY CONTROL triggers an acoustic and visual alarm if breathing stops for longer than 12 seconds or if the rate of breathing is bellow 8 breaths per minute.

  • Page 4: Operation

    Operation 1. Place the sensor pad on the bed bottom. Place the mattress on the sensor pad and be sure that the sensor is well positioned with the mattress using the following guidelines: • Center of the sensor pad should be approximately in the position of where the baby’s chest will be.
  • Page 5 3. The green led (6) indicator will flash as the baby breathes or moves. 4. Turn off the unit (press the red button (1) twice) before you take the baby out of the bed. (If the alarm is on the unit can be switched off pressing the red button(1) once) While everything goes well After placing the baby and turning the unit on the digital display(2) shows the sensitivity level every 2 seconds and the green light flashes.

  • Page 6: E Vent Memory

    Alarm If the baby is not breathing for longer than 12 seconds, or the breath rate is too slow, after 4 warning signal an alarm signal will sound and the red indicator will flash. On the display(2) the „H”-„E”-„L”-„P” letters will be displayed. (If movement is detected during the 4 warning signal the alarm will not sound.
  • Page 7 Test You can test function of the BABY CONTROL in the following way (should be tested once a week): 1. If the baby is in the bed and the unit is ON, the green indicator should flash as the baby is breathing or moving.

  • Page 8: Medical Instructions

    Place at least one sensor pad under each baby. Connect the sensor pads to the left and the right connection points of the control unit, to identify the sensor pads for each baby. With the given “T” splitter you can also use two sensor pads for each baby.
  • Page 9 Since medicine can not tell them why their baby died, they blame themselves and often other innocent people. Their lives and those around them are changed forever. Being prepared Still today, "cot death" is an unforeseeable occurrence from which every 500th baby dies. 80% of infants affected are entirely healthy beforehand.
  • Page 10 2. Place infants to sleep in a baby bed with a firm mattress. There should be nothing in the bed but the baby - no covers, no pillows, no bumper pads, no positioning devices and no toys. Soft mattresses and heavy covering are associated with the risk for SIDS. 3.

  • Page 11: Specification

    Manufacturer: VMD 95 Kereskedelmi és Szolgáltató Kft. The subject of the declaration: Baby Control Digital Apnoe Alarm Systems The manufacturers declares that the product to which this declaration refers conforms with the relevant harmonized standards under the following Hungarian Directives 16/2006.
  • Page 12 It monitors and alerts, but cannot prevent any type of distress. The responsibility of assistance rests on you. Baby Control Digital senses movements and motion only and cannot monitor other occurrences. The purpose of the device is to alert you when stopping or slowing of movement occurs.
