3.2 Switching On the Camera

The Thermal camera is switched On and Off by pressing and holding the On/Off button for
at least 3 seconds, until the display switches On.
The clicking noise heard frequently when the camera is switched On is due to the
calibration of the Infrared detector. This is done automatically by the camera.
Note:
After powering off, please wait ten seconds before switching On the camera again.
On/Off Button
Figure 6 Switching on the camera

3.3 Focusing

• Sharpen the
image by rotating
the focus ring
Figure 7 Focusing
REMEMBER TO REMOVE THE LENS CAP
Focus:
• Is the most important step to obtain a good quality image.
• Influences the accuracy of the temperature reading.
• Cannot be modified when viewing the images on a PC.
• Some palettes allow you to make a better focus.
• Make sure you are in automatic span and level.
