SKF Thermal Camera
TKTI 21 & 31
Quick Start guide
1. Camera Description
3.5"
Colour
display
Status
LED
Control
Buttons
Microphone
Battery
door
Mini USB connector
Micro SD card port
(2GB Micro SD card
supplied)
Mini jack video output
12V DC connector
(Power adapter
not provided)
Connectors
hatch
Digital Camera lens
Trigger
Infrared
Camera lens
Laser
Focus Ring
Tripod Mount
