Carrier 50HJ015-025 Installation, Start-Up And Service Instructions Manual

Carrier 50HJ015-025 Installation, Start-Up And Service Instructions Manual

Single-package rooftop units electric cooling with electric heat option
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Step 1 - Provide Unit Support . . . . . . . . . . . . . . . . . . . 1
Step 2 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . 1
• POSITIONING
• ROOF MOUNT
Step 3 - Field Fabricate Ductwork . . . . . . . . . . . . . . . 7
Step 4 - Make Unit Duct Connections . . . . . . . . . . . 7
Step 5 - Trap Condensate Drain . . . . . . . . . . . . . . . . . 7
Step 6 - Make Electrical Connections . . . . . . . . . . . 8
• FIELD POWER SUPPLY
• FIELD CONTROL WIRING
• OPTIONAL NON-FUSED DISCONNECT
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•
Step 8 - Install Outdoor-Air Hood . . . . . . . . . . . . . . 12
Step 9 - Install All Accessories. . . . . . . . . . . . . . . . . 15
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-26
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-33
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . .34,35
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can
be hazardous due to system pressure and electrical compo-
nents. Only trained and qualified service personnel should in-
stall, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance func-
tions of cleaning coils and filters and replacing filters. All other
operations should be performed by trained service personnel.
When working on air-conditioning equipment, observe precau-
tions in the literature, tags and labels attached to the unit, and
other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations. Have
fire extinguishers available for all brazing operations.
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injury.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
PC 111
Book 1
4
Tab
1b 6b
Electric Cooling with Electric Heat Option
Installation, Start-Up and
Service Instructions
Page
Catalog No. 535-00025
Single-Package Rooftop Units
IMPORTANT: Units have high ambient operating lim-
its. If limits are exceeded, the unit will automatically
lock the compressor out of operation. Manual reset will
be required to restart the compressor.

Step 1 - Provide Unit Support

ROOF CURB - Assemble and install accessory roof curb or
horizontal supply roof curb in accordance with instructions
shipped with the accessory. Accessory roof curb and horizontal
supply roof curb and information required to field fabricate a
roof curb or horizontal supply roof curb are shown in Fig. 1
and 2. Install insulation, cant strips, roofing, and counter flash-
ing as shown. Ductwork can be secured to roof curb before unit
is set in place.
IMPORTANT: The gasketing of the unit to the roof curb
or horizontal supply roof curb is critical for a leakproof
seal. Install gasket supplied with the roof curb or hori-
zontal supply roof curb as shown in Fig. 1. Improperly
applied gasket can result in air leaks and poor unit
performance.
Roof curb must be level. This is necessary to permit unit
drain to function properly. Unit leveling tolerance is ±
per linear ft in any direction. Refer to Accessory Roof Curb or
Horizontal Supply Roof Curb Installation Instructions for addi-
tional information as required.
ALTERNATE UNIT SUPPORT - When the curb or adapter
cannot be used, support unit with sleepers using unit curb or
adapter support area. If sleepers cannot be used, support long
sides of unit with a minimum of 3 equally spaced 4-in. x 4-in.
pads on each side.
Step 2 - Rig and Place Unit -
transportation damage. File any claim with transportation
agency. Keep unit upright, and do not drop. Use spreader bars
over unit to prevent sling or cable damage. Rollers may be used
to move unit across a roof. Level by using unit frame as a refer-
ence; leveling tolerance is ±
tion. See Fig. 3 for additional information. Unit weight is
shown in Table 1.
Four lifting holes are provided in ends of unit base rails as
shown in Fig. 3. Refer to rigging instructions on unit.
POSITIONING - Provide clearance around and above unit
for airflow, safety, and service access (Fig. 4 and 5).
Do not install unit in an indoor location. Do not locate air in-
lets near exhaust vents or other sources of contaminated air.
Although unit is weatherproof, guard against water from
higher level runoff and overhangs.
ROOF MOUNT - Check building codes for weight distribu-
tion requirements.
Printed in U.S.A.
Form 50HJ-19SI
50HJ015-025

INSTALLATION

Inspect
1
/
in. per linear ft in any direc-
16
Pg 1
3-01
Replaces: 50HJ-16SI
1
/
in.
16
unit
for
