smaky SM-500A Instruction Manual

Desktop mixer
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual for SM-500A Desktop Mixer
Regulatorvägen 21, S-141 49 Huddinge, Sweden
SMAKY AB
Tel+ 46 8 657 9490
Fax+ 46 8 657 8980
http://www.smakymixers.com
e-mail: info@smaky.com
CONTENTS
................................................................. P. 2
................................................................. P.3
................................................................. P. 4
................................................................. ......P. 8
................................................................. P. 8
........................................................................ P.9
................................................................. P.10
................................................................. P.10

Advertisement

loading
Need help?

Need help?

Do you have a question about the SM-500A and is the answer not in the manual?

Questions and answers

Related Manuals for smaky SM-500A

Summary of Contents for smaky SM-500A

  • Page 1: Table Of Contents

    Instruction Manual for SM-500A Desktop Mixer SMAKY AB Regulatorvägen 21, S-141 49 Huddinge, Sweden Tel+ 46 8 657 9490 Fax+ 46 8 657 8980 http://www.smakymixers.com e-mail: info@smaky.com CONTENTS Overall View of the Mixer ……………………………………….…………….… P. 2 Installation Instructions ……………………………………..………………… P.3 Operating Instructions ……………………………………….….……………...
  • Page 2 DO NOT hose down or pressure wash any part of the mixer.  NEVER bypass, alter or modify this machine. Doing so may create hazard and will void warranty. If you have any questions, please contact any local representative or SMAKY directly.

  • Page 3: Overall View Of The Mixer

    (B) Bowl Lift Handle (C) Bowl Cradle (D) Hub Attachment (E) Planetary Shaft (F) Bowl Guard (G) Stainless Steel Bowl SPECIFICATION Model SM-500A Hub Attachment 60-308 (rpm) Bowl Size 5 Liters Noise Value 77.1 dB(A) Dimensions (cm) 38 x 31 x 45.5...

  • Page 4: Installation Instructions

    You may place the mixer on bench which is capable of supporting a load of 25kg. For operation stability, please punch four holes on the table and fix SM-500A onto the table by four screws. Please see Figure 1.

  • Page 5: Operating Instructions

    Installation Instructions The minimum requirement for all electrical equipment is correct operation between air temperature of +5℃ and +40℃. Electrical equipment is capable of operating correctly when the relative humidity does not exceeding 95% at a maximum temperature of +40℃. Electrical equipment is capable of operating correctly at altitude up to 1000m.
  • Page 6 Operating Instructions TOOL SELECTION Beater: Firm mixes such as light pastry, cakes biscuits, icings The beater, whisk and spiral dough hook are tools fillings and mashed vegetables. for the work implied by their names. Do not use the beater for dough making or the whisk for anything other Spiral Dough Hook: Heavy mixes than whisking, aerating or mixing light mixtures.
  • Page 7 Operating Instructions CONTROLS A: Speed Selector Knob B: Position 0: OFF C: Position 1-3: Low speeds (Spiral Hook) D: Position 4-7: Medium speeds (Beater) E: Position 7-10: High speeds (Whip) CAPACITY Please refer to Page 10. The table shows the recommended capacities of finished weights of regular mixes.
  • Page 8 Operating Instructions THERMAL OVERLOAD PROTECTION (Automatically Reset) The thermal overload protection (circuit breaker) will shut off and stop the machine automatically. If this occurs, please turn the ON/OFF speed selector button to 0-OFF position and reduce the size of batch. After waiting 1-2 minutes machine shut off, turn the ON/OFF speed selector or button to ON position.

  • Page 9: Cleaning Instructions

    ※ Please unplug while not using the mixer. GEARBOX AND PLANETARY UNIT LUBRICANT Please use the right lubricant to re-lubricate the gearbox and planetary gear. Model Lubricant for Gear Box Lubricant for Planetary Unit SM-500A Brugarolas ”G. BESLUX ALCO H-2/MF RED” TACBECON “GL-210”...

  • Page 10: Troubleshooting

    TROUBLESHOOTING FAULT CHECK POSSIBLE REASON AND ACTION REQUIRED No power to mixer Check plug socket Mixer not plugged into a live socket or not switched on Check wiring in plug Plug incorrectly wired – rewire correctly Check fuse in plug Possible faulty fuse –...

  • Page 11: Limited Warranty

    Limited Warranty GUARANTEE SMAKY provides one year guarantee, either the date of dispatch from our factory, or the date of purchase from one of our approved distributors. We will replace any defected parts resulted from faulty design, material or workmanship, provided that no alteration, addition or repair has been carried out except by an authorized Service Agent and provided that such defective part(s) be returned to the Company’s nearest authorized representative, postage paid.
