smaky SL-500A Instruction Manual

Desktop mixer
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual for SL-500A Desktop Mixer
CONTENTS
................................................................. P. 2
................................................................. P.3
................................................................. P. 4
................................................................. ......P. 8
................................................................. P. 8
........................................................................ P.9
................................................................. P.10
................................................................. P.10

Advertisement

loading
Need help?

Need help?

Do you have a question about the SL-500A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for smaky SL-500A

Summary of Contents for smaky SL-500A

  • Page 1: Table Of Contents

    Instruction Manual for SL-500A Desktop Mixer CONTENTS Overall View of the Mixer ……………………………………….…………….… P. 2 Installation Instructions ……………………………………..………………… P.3 Operating Instructions ……………………………………….….…………… P. 4 Cleaning Instructions …………………………………….……………….… ……P. 8 Maintenance ………………………………...……….………….… P. 8 Troubleshooting …………………………………………..…..…….………. P.9 Limited Warranty ……………………………………..………..…….… P.10 Capacity Chart Table ………………………………………………..….…...
  • Page 2 CAUTION Read before you operate the machine It is important to read this manual and following the instructions before operate the machines. This mixer is designed as a safe and efficient food processing product as long as the machine is used in accordance with the instructions in this manual and is properly maintained.

  • Page 3: Overall View Of The Mixer

    (B) Bowl Lift Handle (C) Bowl Cradle (D) Hub Attachment (E) Planetary Shaft (F) Bowl Guard (G) Stainless Steel Bowl SPECIFICATION Model SL-500A Hub Attachment 60-308 (rpm) Bowl Size 5 Liters Noise Value 77.1 dB(A) Dimensions (cm) 38 x 31 x 45.5...

  • Page 4: Installation Instructions

    You may place the mixer on bench which is capable of supporting a load of 25kg. For operation stability, please punch four holes on the table and fix SL-500A onto the table by four screws. Please see Figure 1.

  • Page 5: Operating Instructions

    Installation Instructions The minimum requirement for all electrical equipment is correct operation between air temperature of +5℃ and +40℃. Electrical equipment is capable of operating correctly when the relative humidity does not exceeding 95% at a maximum temperature of +40℃. Electrical equipment is capable of operating correctly at altitude up to 1000m.
  • Page 6 Operating Instructions TOOL SELECTION Beater: Firm mixes such as light pastry, cakes biscuits, icings The beater, whisk and spiral dough hook are tools fillings and mashed vegetables. for the work implied by their names. Do not use the beater for dough making or the whisk for anything other Spiral Dough Hook: Heavy mixes than whisking, aerating or mixing light mixtures.
  • Page 7 Operating Instructions CONTROLS A: Speed Selector Knob B: Position 0: OFF C: Position 1-3: Low speeds (Spiral Hook) D: Position 4-7: Medium speeds (Beater) E: Position 7-10: High speeds (Whip) CAPACITY Please refer to Page 10. The table shows the recommended capacities of finished weights of regular mixes.
  • Page 8 Operating Instructions THERMAL OVERLOAD PROTECTION (Automatically Reset) The thermal overload protection (circuit breaker) will shut off and stop the machine automatically. If this occurs, please turn the ON/OFF speed selector button to 0-OFF position and reduce the size of batch. After waiting 1-2 minutes machine shut off, turn the ON/OFF speed selector or button to ON position.

  • Page 9: Cleaning Instructions

    ※ Please unplug while not using the mixer. GEARBOX AND PLANETARY UNIT LUBRICANT Please use the right lubricant to re-lubricate the gearbox and planetary gear. Model Lubricant for Gear Box Lubricant for Planetary Unit SL-500A Brugarolas ”G. BESLUX ALCO H-2/MF RED” TACBECON “GL-210”...

  • Page 10: Troubleshooting

    TROUBLESHOOTING FAULT CHECK POSSIBLE REASON AND ACTION REQUIRED No power to mixer Check plug socket Mixer not plugged into a live socket or not switched on Check wiring in plug Plug incorrectly wired – rewire correctly Check fuse in plug Possible faulty fuse –...

  • Page 11: Limited Warranty

    Capacity Chart Table Maximum Product Agitator Max Speed Regular Mix (kg) Egg Whites Whip 0,35 lit. Whipped Cream Whip 2 lit. Batter Beater Mashed Potatoes Beater 1,8 kg Frosting Beater 1 kg Cookie Dough Beater Cake Beater 1,5 Kg Pie Crust Beater 1,5 kg Dough 60% AR...
