Page 1: Quick Reference
MultiView AK500 C7 Receiver Quick Reference & Setup Guide Magenta Research 128 Litchfield Road, New Milford, CT 06776 USA (860) 210-0546 FAX (860) 210-1758 www.magenta-research.com... - Page 2 New Milford, CT 06776 USA This document and the Magenta Research products to which it relates, and the copyright in each, is the property of Magenta Research. Neither the document nor the products may be reproduced by any means, in whole or in part, without the prior written permission of Magenta Research.
-
Page 3: Table Of Contents
Contents Contents Chapter Page Specifications....................2 Introduction ........…............3 2.1 Overview.....................3 2.2 Equipment You May Also Need............…..3 2.3 Compatible Cabling ................…...….3 3. Setup and Installation..........… ........….4 3.1 Data Mode Configuration................4 3.2 Cabling Considerations................4 3.3 Making the Connections........…..........4 3.3.1 Connections and Setup in General ........……..4 3.3.2 Connections on the VGA/Audio series…….……....………..…..5 3.3.3 Connections on the SA/SAP series…………….………...……….6 3.4 Video Adjustment……........….........….7... -
Page 4: Specifications
MAGENTA MULTIVIEW™ SERIES 1. Specifications Cable Required: Category 7 FTP Compliance: CE; FCC Class A, IC Class/class A Video Support: all supported VESA modes to WUXGA (2048x1536), RGBHV, RGB, Composite (NTSC, PAL, SECAM), S-Video, Component Video, widescreen modes, HDTV modes including 1080p, 1080i, 720p... -
Page 5: Introduction
This Magenta Research product is compatible with Cat 7 FTP data cabling. CatX cabling for the Magenta MultiView™ Series must be pinned to the TIA-EIA T568B wiring specification (see appendix A) We also highly recommend that all cables be pre-terminated and tested. -
Page 6: Setup And Installation
Video modes may function normally, but 4th pair options will not. At the transmitter end (refer to the transmitter user guide) : 1. Connect the source video to the Magenta MultiView Series transmitter video input port, which is an HD15 connector labeled SOURCE IN or VIDEO IN. -
Page 7: Connections On The Vga/Audio Series
CHAPTER 3: SETUP & INSTALLATION 4. Connect the CAT7 cable to the transmitter. 5. Apply power on the transmitter. The LED should light and, if there’s a local monitor attached, a video image should appear on the monitor’s screen. At the receiver end: 1. -
Page 8: Connections On The Sa/Sap Series
The MultiView™ Video System SA/SAP series supports RS-232, video and stereo audio signals over CAT5 cable. SAP offers pollable serial modes so a bi-directional serial session can be established with a receiver in a daisy chain. The Magenta MultiView T4, T5 transmitters do not support SA/SAP versions. -
Page 9: Video Adjustment
This is because the adjustments are specific to the type and length of UTP cable being used. In order to get the highest quality video signals from your MultiView AK500 C7, please follow the instructions and diagrams below: An image file is available for download at www.magenta-research.com/test to assist in these settings. -
Page 10: Troubleshooting
MAGENTA MULTIVIEW™ SERIES 4. Troubleshooting 4.1. Common Problems In most cases, nearly every issue with the MultiView™ System can be resolved by checking the CAT7 termination and making sure that it’s pinned to the TIA/EIA 568B wiring specification. However, there may be other problems that cause the system to not perform as it’s designed. - Page 11 CHAPTER 4: Troubleshooting Problem: Serial communication doesn’t work correctly. Solution: • Are the serial devices connected properly? Are the serial parameters correct for source/destination devices? • Are the serial cables terminated correctly? If a null-modem cable is used, it must be placed at the receiver end. •...
-
Page 12: Appendix A. Cabling Pinouts
MAGENTA MULTIVIEW™ SERIES Appendix A. Cabling Pinouts Table A-1. HD15 video connector. RGBHV RGBS RGsB Com- SVHS (VGA) posite (Y/C) Red + Red + Red + Green+ Green+ Green+ Blue+ Blue+ Blue+ — — — Red- Red- Red- Green- Green-... - Page 13 APPENDIX A: Cable Pinning Appendix A. Cabling Pinouts Table A-3. DB9 Male Serial connector 3 wire (SA) Simplex Ground Ground Table A-4. T568B CAT7 pinout...
-
Page 14: Appendix B. Setting Sync Signal Output Termination
MAGENTA MULTIVIEW™ SERIES Appendix B. Setting Sync Signal Output Termination In some cases, it may be necessary to disable the 75-ohm termination of the video outputs on the MultiView™ units. This can be done by opening the case of each unit and installing jumpers on the circuit board. - Page 15 NOTES...
-
Page 16: Appendix C. Ak500 C7 Configuration Settings
MAGENTA MULTIVIEW™ SERIES Appendix C. AK500 C7 Configuration Settings Note: AK500 C7 receivers are typically pre-configured at time of order and will have factory configuration indicated on the top of the unit by an X in the appropriate checkbox. The factory configuration may be changed or checked by using the following jumper location diagram as well as Table C-1 for jumper settings. - Page 17 APPENDIX C: AK500 Configuration Settings Table C-1: MultiView AK500 C7 Configuration Jumper Settings JP10 Configuration Option (all options utilize JP3 JP4 JP5 JP6 JP7 JP8 JP9 JP17 4th pair, except special configurations): JP11 RGBHV Computer Video With Left/Right Line Level Audio...
-
Page 18: Appendix D. Mounting Options
MAGENTA MULTIVIEW™ SERIES Appendix D. Rackmounting Units The Rackmount Kits include brackets for mounting a single transmitter, single receiver, or a single dual daisychainable receiver. Figure D-1 shows the 1-Unit Rackmount Bracket , which can be used to mount a single unit on a wall. Figure D-2 shows the 4-Unit Rackmount Bracket, which holds four units in a 19"... -
Page 19: Appendix E. Pollable Serial Mode
APPENDIX F: Pollable Serial Mode Appendix E. Pollable Serial Mode The SAP pollable serial daisychainable receivers with video, audio and RS232 serial feature the ability to open a bi-directional session between a pollable transmitter and a single pollable receiver in a daisychain installation. Each pollable receiver must have a unique address set first. - Page 20 MAGENTA MULTIVIEW™ SERIES Appendix F. Pollable Serial Mode Address Chart...
- Page 21 APPENDIX F: Pollable Serial Mode Appendix F. Pollable Serial Mode Address Chart (cont.)
- Page 22 MAGENTA MULTIVIEW™ SERIES NOTES...
- Page 23 NOTES...
- Page 24 MAGENTA MULTIVIEW™ SERIES Magenta Research 128 Litchfield Road, New Milford, CT 06776 USA (860) 210-0546 FAX (860) 210-1758 www.magenta-research.com PN 5310242-01, Rev 01, Feb-2010...
