  • Page 1 12 12 12 1200 LED 00 LED 00 LED 00 LED Lighting Lighting Lighting Panel Lighting Panel Panel Panel Operations Manual Operations Manual Operations Manual Operations Manual Cool Lights USA www.CoolLights.biz Manual V1.0. Cool Lights CL-LED1200 is © Copyright 2010 CoolVideoLights.Com All Rights Reserved.

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION ..................................3 ASSEMBLY AND OPERATING PROCESS ......................... 4 LED 1200 P ........................4 EMOVE THE ANEL FROM THE BOX ............................4 UT THE PANEL ON A STAND ....................4 TTACH THE POWER SUPPLY TO PANEL INPUT ........................

  • Page 3: Introduction

    Introduction This is the operations manual for the Cool Lights USA CL-LED1200 LED Panel. The exact models available are the CL-LED120056F (5600K flood panel), the CL-LED120056S (5600K spot panel). The Bi-Color LED 1200 is covered in a separate manual. Your LED 1200 panel puts out a comparable hard light to a tungsten 1000w fresnel based on light meter readings.

  • Page 4: Assembly And Operating Process

    The panel has a 4 pin military grade DC power input on the side. This is the DC power input from whatever external power supply you may use to power the LEDs—including of course the Cool Lights AC to DC power supply that came with the panel or the optional CL- BT1200 battery interface.

  • Page 5: To Dc Power Supply Into The Ac

    2 VLock or 2 AB batteries to power the LED 1200. Warning: Do not attempt to adapt a battery to the LED 1200 using anything other than the Cool Lights CL-BT1200 LED 1200 battery interface. Any other interface risks damaging your LED 1200 as well as invalidating the warranty.

  • Page 6: Filter Panel Set

    Filter Panel Set Your LED 1200 comes with a set of 4 acrylic filter panels which can velcro attach to the front of the fixture and modify the light output in various ways. These include: ¼ minus green, ½ minus green, full CTO (color temperature orange) and diffusion all in a convenient nylon pouch as shown...

  • Page 7: Operating Specifications And Parameters

    your panel are connected in series of 5. Should one LED in the series of 5 go out, all 5 in that series will not work until the damaged or defective LED is replaced. If all trouble shooting options are exhausted, then you most likely have developed a bad switch, dimmer knob or power supply.

  • Page 8: Conclusion

    All readings in Lux taken with light meter. Conclusion This completes setup and testing of the Cool Lights CL-LED1200 1200 LED Panel. With proper care, you should get many years of service out of its sturdy and innovative construction. Thanks for your business!
