Tahmazo TL-4 Instruction Manual

TL-4 Instruction Manual
Thank you for purchasing our TL-4 Lithium Polymer battery charger, designed specially for lithium polymer battery packs
up to 4-cell pack.
Features
01 Durable and light weight aluminium case
02 Charges the lithium polymer battery pack using its latest Constant Current and Constant Voltage charging
technique to optimally charge each cell.
03 Charges each cell of the battery pack independently, eliminating the interference between cells of the battery pack.
This will ensure the proper 'balancing' of each pack after charging
04 Load polarity protection
05 Input polarity or reverse polarity protection
06 Built-in fan for maximum heat dissipation
07 Automatically cut-off charging operation when the input power supply voltage falls below 8v.
Safety Precautions
01 Do NOT attempt to charge incompatible types of rechargeable batteries. This charger is designed to only charge
Lithium Polymer battery packs.
02 Make sure to place the charger on a firm level surface for charging
03 Do not attempt to charge batteries at excessive fast charge currents above the recommended charging current.
04 Do not leave the charger unattended while charging
05 Do not allow water, moisture or foreign object into the charger
06 Do not place the battery or charger on or near a flammable object while in use.
07 Do not cover the air intake holes or the fan on the charger as this could cause the charger to overheat
08 Connect the input power supply first, then connect the battery.
09 Do not disassemble the charger

Specifications

Input Voltage
Output Voltage
Weight
Dimension
Operation of the charger
INPUT POWER
Connect the charger to a 9-15v power source (Power supply must be able to provide at least 2A stable or regulated current).
All the LEDs on the charger will light up in green colour, indicating that the charger is in good status and ready for use.
CURRENT SELECTION
Select the appropriate current setting (0.5A, 1.0A, 1.5A, 2.0A) according to the battery pack's recommended charging
current.
Tahmazo Products Pte Ltd
w:http://www.tahmazo.com
e:sales@tahmazo.com
9-15vDC
8.4v for 2-cell lithium battery pack
12.6v for 3-cell lithium battery pack
16.8v for 4-cell lithium battery pack
310g
138x89x35mm
TL-4
Lithium Polymer charger
TL-4 INSTRUCTION MANUAL - 01
©COPYRIGHT 2005 TAHMAZO PRODUCTS PTE LTD
